Goji GMWLTQ15 Manuale utente
Egg Mouse
Instruction Manual
GMWLTQ15 / GMWLPP15 / GMWLRD15
GMWLWHT15 / GMWLOR16
Contents
Safety Warnings...............................................................4
Unpacking........................................................................5
Product Overview............................................................6
Top View............................................................................................ 6
Bottom View.................................................................................... 6
System Requirements .....................................................7
Installing the Batteries....................................................7
Connecting the Nano Dongle .........................................8
Activating the Wireless Mouse .......................................8
DPI Button........................................................................9
Hints and Tips...................................................................9
Specications.................................................................10
4
Safety Warnings
Wireless Devices:
• Before boarding any aircraft or packing a wireless
device in luggage that will be checked in, remove the
batteries from the wireless device.
• Wireless devices can transmit radio frequency (RF)
energy, whenever batteries are installed and the
wireless device is turned on (If it has an On/O switch).
Battery-Powered Devices:
• Improper use of batteries may result in battery uid
leakage, overheating, or explosion.
• Released battery uid is corrosive and may be toxic.
It can cause skin and eye burns, and is harmful if
swallowed.
To Reduce the Risk of Injury:
• Keep batteries out of the reach of children.
• Do not heat, open, puncture, mutilate, or dispose of
batteries in re.
• Do not mix new and old batteries or batteries of
dierent types.
• Do not allow metal objects to touch the battery
terminals on the device; they can become hot and
cause burns.
5
Thank you for purchasing your new
Mouse.
We recommend that you spend some time
reading this instruction manual in order that you
fully understand all the operational features it
oers. You will also nd some hints and tips to
help you resolve any issues.
Read all the safety instructions carefully before
use and keep this instruction manual for future
reference.
Unpacking
Remove all items from the packaging. Retain the
packaging. If you dispose of it please do so according
to local regulations.
The following items are included:
• Main Unit (with Nano Dongle)
• AAA Size Battery x 2
• Instruction Manual
6
Product Overview
Top View
Right Click
Left Click
Scroll Wheel
LED Indicator Battery
Compartment
Nano Dongle
ON/OFF Switch
Hardware Reset Button
(This button is for factory use only.)
DPI Button
Battery Cover
Release Button
Bottom View
7
System Requirements
Operating Systems: Microsoft® Windows®7 / 8 /10
MAC® OS X 10.7 or later
Hardware: 1 available USB port
Installing the Batteries
When battery is low, the LED indicator will flash.
1. Press and lift the battery cover.
2. Insert 2 x AAA battery.
3. Close the battery cover.
Please ensure the batteries’ polarities (+ / -)
match the battery compartment’s polarities.
8
Connecting the Nano Dongle
Remove the Nano Dongle from the mouse and then
plug the Nano Dongle directly into your computer’s
USB port.
Dongle
To save energy, switch the ON/OFF button
to the o position to turn o the mouse and
disconnect the mouse and the Nano Dongle.
Activating the Wireless Mouse
Switch the ON/OFF button to
power on the mouse and then the
mouse will automatically connect
to the Nano Dongle plugged into
your computer.
9
DPI Button
Press the DPI button to adjust the resolution:
1. 800 dpi - LED indicator ashes once.
2. 1600 dpi (default) - LED indicator ashes twice.
Hints and Tips
Mouse not working:
1. Check that the power switch is in the on position.
2. Make sure the Nano Dongle is plugged into a USB
port and the computer is on or try the Nano Dongle
in a dierent USB port.
3. Check battery installation. Replace battery if needed.
4. If mouse performance is slow or intermittent around
a wireless network, unplug the Nano Dongle from
the USB port and then reinsert it. To reactivate the
mouse, switch it on, o and on again using the ON/
OFF switch on the bottom of the mouse.
5. Repeat the connection procedure. You can also try
moving the mouse closer to the Nano Dongle.
6. If the mouse is moving erratically, change the
working surface which the mouse is operating on.
10
Specications
Model GMWLTQ15 / GMWLPP15 /
GMWLRD15 / GMWLWHT15
GMWLOR16
Power
Consumption
3V 6mA
Wireless
Frequency
2.4 GHz
Operating Range 8 m
Resolution 800 / 1600 dpi
Frequency
Band(s)
2403 – 2479 MHz
Max. Radio
Frequency Power
Transmitted
1 dBm
Dimension
(L) x (W) x (H)
83 x 56 x 39.5 mm
Net Weight 53 g
Features and specications are subject to change
without prior notice.
