Compass TRO

™

Owner’s Manual

Compass TRO ™

Center-Wheel Drive Power Chair

GP615 SS/GP615 CC

401 Bridge Street, Old Forge PA 18518

Tel: (800) 624-6374 Fax: (800) 628-5165

www.goldentech.com

YOUR LIFE IN MOTION

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

FOR YOUR RECORDS

Please fill in your Compass TRO™information below. This

information will be useful in the event that you ever need to

contact Golden Technologies, Inc. concerning your power chair.

Your Compass TRO

Model __________________ Serial Number _______________

Date of Purchase _______ Body Color __________________

Options ________________

Your Golden Technologies, Inc. representative or dealer

Name ____________________________________

Company ________________________________

Address _________________________________

Please remember to fill in and return your warranty registration card.

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

CONTENTS

INTRODUCTION …………………………………………………… 4

SAFETY..............................................................……….. 5-8

EMI/RFI ........................................................…….…….. 9

SPECIFICATIONS…………………………………………………… 10

ASSEMBLY…………………………………………………………… 11-15

COMFORT SETTINGS…………………………………………….. 16-21

OPERATION/DIAGNOSTICS ……………………………………. 22-27

BATTERY CHARGING ……………………………………………. 28

CARE AND MAINTENANCE …………………………………….. 29

DISASSEMBLY ……………………………………………………… 30

WARRANTY …………………………………………………………. 31

REGISTRATION CARD …………………………………………… 33

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

INTRODUCTION

Congratulations on the purchase of your new Compass TRO™ power chair. The Center-

wheel drive Compass TRO™combines cutting-edge technology with an attractive design

that is also highly functional in today’s world. We at Golden Technologies, Inc. know

that you have chosen a power chair that will give you years of dependable operation

and also will enhance the quality of your life by providing you with the mobility to

experience an active daily lifestyle.

Even though your new Compass TRO™is both user-friendly and designed for

maximum maneuverability in even the tightest spaces, we ask that you please read,

understand and follow all of the instructions and suggestions in this manual before

you operate your Compass TRO™for the first time. The safe use of your new power

chair is very important to us.

If you feel that you do not understand the instructions and suggestions presented in

this owner’s manual, or if, for any reason, you do not feel capable of performing the

activities necessary to assemble, disassemble, operate, or maintain your Compass

TRO™please contact your local Golden Technologies, Inc. representative or call Golden

Technologies, Inc. Technical Support Services at (800) 624-6374.

Golden Technologies, Inc. cannot be held responsible for personal injury or property

damage resulting from the unsafe or the improper use of any of our broad range of

health and personal mobility products. Our Research and Development Department,

our Quality Control Department, and our Engineering Department have used the latest

product specifications and the latest product design information to produce this

owner’s manual. Golden Technologies, Inc. reserves the right to implement changes

into our product lines when those changes become desirable or necessary. If changes

are implemented into our product line, there may be minor differences between the

product you purchased and the illustrations and instructions in this owner’s manual.

The Compass TRO™ can be fitted with a tilt seating system by Motion Concepts.

This manual is specifically for the Compass TRO™ fitted with Golden

Technologies seating. Motion concepts will provide an operator’s manual with

the purchase of their seating system.

Please fill out and mail the enclosed warranty registration card on page 33. We at

Golden Technologies, Inc. would appreciate hearing about the dependability of your

Compass TRO™and about the convenience of mobility it has provided for you. We

would also appreciate hearing about the service you received from your local Golden

Technologies, Inc. representative.

Golden Technologies, Inc. Phone: (570) 451-7477

401 Bridge Street Fax: (570) 451-7494

Old Forge, PA 18518 Toll free:

(800) 624-6374

Web Site: www.goldentech.com

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

SAFETY

Your Compass TRO™ is a battery-operated personal mobility vehicle. Please exercise

caution and consideration when you are operating it. Driving your Compass TRO™

carefully and thoughtfully will help ensure your personal safety and the safety of other

people.

NOTE: Before learning to operate your Compass TRO™, have your Golden

Technologies, Inc. representative determine if it is advisable for you to

practice getting on and off your Compass TRO™and operating it in the

presence of an attendant.

BEFORE GETTING ON YOUR Compass TRO™

♦Check to be certain that the power is turned off. See “Operation” on page 22. This

will eliminate the possibility of accidentally activating the joystick and causing

injury to yourself or to others.

♦Check to be certain that your Compass TRO™is not in freewheel mode. See the

“Operation” section on page 26.

♦Flip up the armrests.

♦If your chair is equipped with leg rests, move them to the sides.

♦If your chair is equipped with a footrest, flip it to the “up” position.

GETTING ON YOUR Compass TRO™

♦While being careful not to entangle yourself in the leg rests or the footrest, seat

yourself comfortably and securely on the seat.

♦Adjust the leg rests or flip down the footrest.

♦Flip down the armrests.

♦Fasten the lap belt, if your chair is so equipped.

GETTING OFF YOUR Compass TRO™

♦Make certain that the power is turned off.

♦Unfasten the lap belt, if your chair is so equipped.

♦Flip up the armrests.

♦Flip up the footrest, or move the leg rests to the sides.

♦While being careful not to entangle yourself in the leg rests or the footrest,

carefully stand and step away from the chair.

MAXIMUM WEIGHT

Your Compass TRO™has been rated to a maximum payload (passenger and anything

else being carried on the Compass TRO™)of 300 pounds. Exceeding the maximum

weight rating will void the warranty.

Exceeding the maximum weight rating will void your warranty and may result in

injury to yourself or to others.

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

SAFETY

DRIVING ON AN INCLINE

♦Drive with caution when attempting to negotiate any incline, even handicap access

ramps.

♦Always climb or descend a gradient by driving straight up or straight down the face

of the slope.

♦Do not traverse or drive across the face of a gradient.

♦Do not attempt to negotiate an incline that is covered with snow, ice, cut or wet

grass, leaves, or any other potentially hazardous material.

♦Do not back down an incline.

♦Try to keep your Compass TRO™moving when climbing an incline. If you do come

to a stop, restart and accelerate slowly and carefully.

♦Do not try to descend or climb an incline that is greater than the maximum incline

stated in the specifications section of this manual.

If, while you are driving down a slope, your chair starts to move faster

than you feel is safe, gently release the joystick and allow your

Compass TRO™to come to a stop. When you feel that you again have

control of your power chair, adjust the speed control to a lower

setting then push the joystick forward and continue safely down the

remainder of the slope.

MEDICATION

Always check with your physician to determine if any of the medications you are taking

may affect your judgment and/or your ability to operate your Compass TRO™.

Do not connect or allow anyone except an authorized Golden

Technologies, Inc. representative to connect any electrical or

mechanical device to your Compass TRO™. Unauthorized accessories

will void the warranty and may cause injury.

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

SAFETY

♦Do not attempt to use your Compass TRO™on an escalator. Always use an

elevator.

♦Do not carry passengers on your power chair.

♦Do not operate your Compass TRO™ if it is not functioning properly.

♦Use caution when driving on soft or uneven surfaces such as grass, gravel, and on

decks where there is no railing.

♦Never drive on the roadway, except when you must cross the street.

♦Always cross streets at intersections and use the most direct route, making sure

that your path is clear and that you are visible to motor traffic.

♦Never drive your Compass TRO™up or down a step or curb that is higher than 1

1/2 inches.

♦Never back up or down a step or curb.

♦Never operate your Compass TRO™while you are under the influence of alcohol.

♦Do not operate or store your power chair where it will be exposed to rain, snow,

mist, and below freezing temperatures.

♦Do not operate your power chair on slippery, icy or salted surfaces.

♦Never sit on your power chair when it is in freewheel mode and on an incline or

decline.

♦Do not sit on your power chair when it is freewheel mode without the presence of a

trained assistant.

♦Do not modify your power chair in any way that is not authorized by Golden

Technologies.

♦Do not disassemble the tire. If disassembly is required, have your authorized

Golden Compass TRO dealer perform any necessary maintenance or repair.

♦Do not attempt to inflate the tires of your Golden Compass TRO™. Your Golden

Compass TRO™ is equipped with foam-filled flat free tires that do not require

inflation.

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

SAFETY

Please be sure to follow this important warning when transferring onto or off of the

Golden Compass TRO power wheelchair:

NEVER TRANSFER ONTO OR OFF OF THIS POWER WHEELCHAIR USING THE

SEAT BACKREST FOR SUPPORT DURING TRANSFER. THE SEAT BACK MAY

FOLD DOWN AND MAY CAUSE YOU TO LOSE YOUR BALANCE AND COULD

RESULT IN PERSONAL INJURY.

NEVER TRANSFER ONTO OR OFF OF THIS POWER WHEELCHAIR USING THE

SEAT ARMRESTS FOR SUPPORT DURING TRANSFER. DOING SO MAY RESULT IN

PERSONAL INJURY OR DAMAGE.

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

EMI/RFI

The rapid development of electronics, especially in the area of communications, has

saturated our environment with electromagnetic (radio) waves that are emitted by

television transmitters, cellular phones, citizen’s band radios (CBs), amateur radios

(ham radios), wireless computer links, microwave transmitters, paging transmitters,

etc. These electromagnetic (EM) waves are invisible and increase in strength the closer

one gets to the source of transmission. When these energy waves act upon electrical

devices and cause them to malfunction or to function in an erratic or uncontrolled

manner, they are referred to as Electromagnetic Interference (EMI) or Radio Frequency

Interference (RFI).

EMI/RFI AND YOUR Compass TRO™

All electrically powered vehicles, including power chairs are susceptible to EMI/RFI.

This interference could result in abnormal, unintended movement of a power

wheelchair.

The FDA has determined that each make and model of power chair can resist EMI/RFI

to a certain level. The higher the level of immunity, the greater the degree of protection

from EMI/RFI measured in volts per meter (V/m). The FDA has also determined that

current technology is capable of providing 20 V/m of immunity to EMI/RFI, which

would provide useful protection against common sources of interference.

Based on that determination, the FDA has written to the manufacturers of power

wheelchairs and asked them to test their new products to be certain that they provide a

reasonable degree of immunity to EMI/RFI. The FDA suggests that power chairs

should have an immunity level of 20 V/m.

The immunity level of the Compass TRO™ is unknown.

EMI/RFI RECOMMENDATIONS

♦Do not turn on or use hand-held personal electronic communication devices such as

cellular phones, walkie-talkies, and CB radios while your power chair is turned on.

♦Be aware of any nearby transmitters (radio, television, microwave, etc.) on your in-

tended route and avoid operating your chair close to any of those transmitters.

♦Turn off the power if your Compass TRO™is going to be in a stationary position for

any length of time.

♦Be aware that adding accessories or components or modifying your power chair

may make it more susceptible to EMI/RFI.

♦If unintended movement or brake release occurs, turn your power chair off as soon

as it is safe to do so.

♦Report all incidents of unintended movement or brake failure to your Golden repre-

sentative or to Golden Technologies, Inc. at (800) 624-6374.

Turn off your power chair as soon as it is safely possible if

unintended or uncontrollable motion occurs or if unintended brake

release occurs.

Compass TRO Owner’s Manual – Models GP615SS, GP615CC Revised 02/13/09

SPECIFICATIONS

GP615 SS GP615 CC

Weight

Base 90 lbs 90 lbs

Seat w/arms (18 X 18 Solid Pan Seat) 47 lbs

Seat w/arms (18 X 18 Captain's Chair Seat) 49 lbs

Batteries (each)

. 2 needed to operate Compass TRO NF22 - 39 lbs NF22 - 39 lbs

Total Weight with NF22 Batteries 215 lbs 217 lbs

Seat w/arms (18 X 18 Motion Concepts Tilt Seating

.System) 115 lbs

Total Weight for GP615 with Motion Concepts Seat 283 lbs

Dimensions

Length 39.8” 39.8”

Width (outside of tires) 25” 25”

Maximum Incline 6 degrees 6 degrees

Maximum Speed 6.47 mph 6.47 mph

Maximum Load Capacity 300 lbs 300 lbs

Turning Radius 21.95” 21.95”

Wheel Sizes

Drive Wheels (2) 10" X 3.5" 10" X 3.5"

Casters (4) 6" X 2" 6" X 2"

Maximum Seat Back Angle 115 degrees 115 degrees

Armrest Width (Adjustable) Width of Seat

+6" Width of Seat

+6"

Armrest Height (Adjustable)

.(Measured from seat cushion) 8", 9". & 10" 8", 9". & 10"

Seat Heights (Ground to Top of Seat)

Minimum Seat Height (NF22 Batteries) 20" 20"

Maximum Seat Height (NF22 Batteries) 23" 23"

Seat Back Heights (Ground to Top of Headrest)

Headrest Not Extended (Solid Pan or Captain's

Chair)* 37" - 41" 37" - 41"

Headrest Extended (Solid Pan or Captain's Chair)* 42" - 46" 42" - 46"

Without Headrest (Solid Pan or Captain's Chair)* 30" - 34" 30" - 34"

Footrest (Adjustable Height)

.(Measured from top of footrest to ground)

5", 5 5/8",

6 1/4", 6 7/8",

7 1/2"

5", 5 5/8",

6 1/4", 6 7/8",

7 1/2"

Footrest (Adjustable Angle) -4 degrees to

17 degrees -4 degrees to

17 degrees

Controller - Programmable Dynamic

Shark

75 Amp

Dynamic

Shark

75 Amp

Charger - Off Board 110 VAC 60 Hz,

5 Amp 110 VAC 60

Hz, 5 Amp

Battery Types (recommended) (2) NF22 (2) NF22

Shroud Colors Red, Blue, Green, Onyx

Specifications for the Motion Concept Tilt Seating System to be provided by Motion Concepts.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Golden Technologies sedia a rotelle

Golden Technologies

Golden Technologies GP620 SS Manuale utente

Golden Technologies

Golden Technologies MAXICOMFORT MODELS Manuale utente

Golden Technologies

Golden Technologies Compass TRO GP615 SS Manuale utente

Golden Technologies

Golden Technologies GP205 Manuale utente

Golden Technologies

Golden Technologies Alero GP-50 Manuale utente

Golden Technologies

Golden Technologies ALERO GP52 Manuale utente

Golden Technologies

Golden Technologies PR-401 Manuale utente

Golden Technologies

Golden Technologies Alante Jr GP 200 Manuale utente

Golden Technologies

Golden Technologies Compass GP600 SS Manuale utente

Golden Technologies

Golden Technologies Alante GP201SS Manuale utente

Golden Technologies

Golden Technologies Compass Sport GP605 Manuale utente

Golden Technologies

Golden Technologies Compass Sport GP605 SS Manuale utente

Golden Technologies

Golden Technologies Alante DX Manuale utente

Golden Technologies

Golden Technologies GP160 Manuale utente

Golden Technologies

Golden Technologies GP162 Manuale utente

Golden Technologies

Golden Technologies Stride GP301 Manuale utente

Golden Technologies

Golden Technologies GA 541 Manuale utente

Golden Technologies

Golden Technologies Compass GP600 SS Manuale utente

Golden Technologies

Golden Technologies GP162 Manuale utente

Golden Technologies

Golden Technologies LiteRider Envy Manuale utente

Golden Technologies

Golden Technologies Cricket GP302 Manuale utente

Golden Technologies

Golden Technologies MAXICOMFORT Manuale utente

Golden Technologies

Golden Technologies GP204 Manuale utente

Manuali sedia a rotelle popolari di altre marche

Otto Bock

Otto Bock Skippi plus Manuale utente

Invacare

Invacare Action 4NG series Manuale utente

SORG

SORG LoopSORG 802 Manuale utente

Designability

Designability WizzyBug Istruzioni per l'installazione

Vermeiren

Vermeiren RAPIDO Manuale utente

Excel

Excel G5 KIDS 0285 Manuale utente

M. Bartels

M. Bartels SA-3 Manuale utente

nino robotics

nino robotics NIno Manuale utente

Vermeiren

Vermeiren Turios Manuale utente

Invacare

Invacare MK5 EX Manuale utente

Invacare

Invacare Solara Spree GT Manuale

Nova

Nova TKW-12 Manuale utente

BCW

BCW Advantage Manuale utente

You-Q

You-Q Luca Manuale utente

interco

interco Ortolight Standard Manuale di istruzioni

Nova

Nova 7190L Manuale utente

Vermeiren

Vermeiren EZ1 Manuale utente

PaceSaver

PaceSaver Scout M-300 Manuale utente
