prodUCt speCifiCations prodUCt speCifiCations
SS-CPC36-72 www.goodmanmfg.com 3
prodUCt speCifiCations — CpC036
CPC036
XXX1DXXXB
CPC036
XXX3DXXXB
CPC036
XXX3BXXXB
CPC036
XXX4BXXXB
CPC036
XXX7BXXXB
Total BTU/h 34,600 34,600 34,600 34,600 34,600
Sensible BTU/h 25,600 25,600 25,600 25,600 25,600
SEER / EER 13 / 11.0 13 / 11.0 13 / 11.0 13 / 11.0 13 / 11.0
Decibels 78 78 78 78 78
ARI Reference #s 4385050 4385051 4385051 4385052 4397604
Motor Type Direct Drive Direct Drive Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 1,200 1,200 1,200 1,200 1,200
Motor Speed Tap (Cooling) Low Speed Low Speed --- --- ---
Indoor motor FLA (Cooling) 2.50 2.50 3.8 1.9 2.3
Horsepower - RPM ⅓ - 890 ⅓ - 890 1.0 - 1725 1.0 - 1725 1.5 - 1725
Piston Size (Cooling) 0.068 0.068 0.068 0.068 0.068
Filter Size (Qty) (1) 24" x 24" x 2" (1) 24" x 24" x 2" (1) 24" x 24" x 2" (1) 24" x 24" x 2" (1) 24" x 24" x 2"
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge (oz.) 83 83 83 83 125
Evaporator Coil Face Area (²) 5.4 5.4 5.4 5.4 5.4
Rows Deep/ Fins per Inch 3 / 16 3 / 16 3 / 16 3 / 16 3 / 16
Standard Direct Drive (D x W) HP (10" X 9") ½ (10" X 9") ½ --- --- ---
Standard Belt Drive (D x W) HP --- --- (11" X 10") 1 (11" X 10") 1 (11" X 10") 1½
High-Stac Belt Drive (D x W) HP --- --- (11" X 10") 1½ (11" X 10") 1½ (11" X 10") 1½
# of Wheels (D x W) --- --- 1 (11" x 10") 1 (11" x 10") 1 (11" x 10")
Motor Sheave --- --- 1VL40 X ⅝ 1VL40 X ⅝ 1VL40 X ⅝
Blower Sheave / Belt --- --- AK69 x 1 / AX55 AK69 x 1 / AX55 AK69 x 1 / AX55
Quanty of Condenser Fan Motors 11111
Horsepower - RPM ¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ - 890 ¼ - 1,075
Fan Diameter/ # Fan Blades 22 / 4 22 / 4 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 3,800 3,800 3,800 3,800 3,800
Face Area (²) 17.0 17.0 17.0 17.0 13.0
Rows Deep/ Fins per Inch 1 / 24 1 / 24 1 / 24 1 / 24 2 / 16
Quanty / Type 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single Single Single
Compressor RLA / LRA 16.7 / 79.0 10.5 / 73.0 10.5 / 73.0 5.8 / 38.0 3.8 / 36.5
Voltage-Phase-Frequency 208/230-1-60 208/230-3-60 208/230-3-60 460-3-60 575-3-60
Indoor Blower HP / FLA ⅓ / 2.5 ⅓ / 2.5 1 / 3.8 1 / 1.9 1.5 / 2.3
Outdoor Fan HP / FLA ¼ / 1.4 ¼ / 1.4 ¼ / 1.4 ¼ / 0.8 0.60
Total Unit Amps 20.57 14.35 15.65 8.47 6.68
Min. Circuit Ampacity¹ 25 17 18 10 8
Max. Overcurrent Protecon (amps)² 40 25 25 15 15
Power Supply Conduit Hole 1.125" 1.125" 1.125" 1.125" 1.125"
Low Voltage Conduit Hole ½" ½" ½" ½" ½"
500 500 500 500 500
525 525 525 525 525
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
