Goodman GPH15M Manuale utente

SS-GPH15M www.goodmanmfg.com 12/11

Supersedes 11/11

GPH15M

Standard Features

• High-efciencycompressor

withinternalreliefvalve

• FullychargedR-410Asystem

• EEM(X-13)blowermotor

• Liquid-linelterdrier

• Convertibleairow—horizontalordownow

• Coppertube/aluminumncoils

• Electricheatkitavailableasaeld-installedoption

• AHRICertied;ETLListed

Cabinet Features

• Heavy-gaugegalvanized-steelcabinetwith

attractiveArchitecturalGraypowder-paintnish

• Fullyinsulatedair-handlingcompartment

withconvenientaccesspanels

• Louveredcondensercoilprotection

• Onefootprint;twoheights

Cooling CapaCity: 24,000 - 55,600 BtU/h

heating CapaCity: 23,400 - 56,000 BtU/h

2 to 5 tons

up to 15 SEER

up to 8.0 HSpF

paCkaged heat pUmp

*Complete warranty details available from you local dealer or at www.

goodmanmfg.com.Toreceivethe10-YearPartsLimitedWarranty,online

registrationmustbecompletedwithin60daysofinstallation.Onlinereg-

istrationisnotrequiredinCaliforniaorQuébec.

Contents

Nomenclature......................................................................... 2

ProductSpecications............................................................ 3

ExpandedCoolingData.......................................................... 4

AirowData.......................................................................... 28

ExpandedHeatingData........................................................ 30

AuxiliaryHeatingData.......................................................... 33

HeatKitElectricalSpecs........................................................ 35

Dimensions........................................................................... 36

WiringDiagrams.................................................................. 37

Accessories............................................................................ 39

Product SPecificationS Product SPecificationS

2 www.goodmanmfg.com SS-GPH15M

nomenclature

Brand Engineering

G Goodman Minor Revision

or Distinctions™

Product Category Engineering

P Packaged Unit Major Revision

Type Voltage Designator

H Heat Pump 1 208-230/1/60

C Air Conditioner 3 208-230/3/60

4 460/3/60

Efficiency Refrigerant

13 13 SEER 15 15 SEER 2 R-22

14 14 SEER 16 16 SEER 4 R-410A

Nominal Capacity Configuration

24 2 Tons 42 3½ Tons H Horizontal

30 2½ tons 48 4 Tons M Multi-position

36 3 Tons 60 5 Tons

G P H 15 36 M 4 1

121110986,74,5321

Important EnergyStar Notice: EnergyStar ratings are dependent upon

conditions beyond equipment installation. Proper sizing and instal-

lation of equipment is critical to achieve optimal performance. Split

system air conditioners and heat pumps must be matched with

appropriate coil components to meet EnergyStar criteria. Ask your

contractor for details or visit

www.energystar.gov.

prodUCt speCifiCations prodUCt speCifiCations

SS-GPH15M www.goodmanmfg.com 3

speCifiCations

GPH15

24M41A*

GPH15

30M41A*

GPH15

36M41A*

GPH15

42M41A*

GPH15

43M41A*

GPH15

48M41A*

GPH15

49M41A*

GPH15

60M41A*

Cooling Capacity

Total BTU/h 24,000 29,000 35,400 41,000 40,000 46,500 46,000 55,500

Sensible BTU/h 18,000 22,200 26,700 29,000 28,000 35,600 31,000 39,300

SEER / EER 15.0/ 12.0 14.5/ 11.5 14.5/ 12.0 15.0/ 11.0 15.0/ 12.0 15/ 11.3 15.0/ 11.7 14.0/ 10.2

Decibels 76 76 76 76 78 78 78 78

AHRI #s 4385138 4385139 4385140 4385141 4385142 4385143 4385144 4385145

Heating Capacity

BUT/h (47°F) 23,400 27,400 33,300 40,000 39,000 45,500 45,500 56,000

C.O.P (47°F) 3.5 3.6 3.4 3.5 3.75 3.4 3.6 3.3

BUT/h (17°F) 12,400 15,200 18,600 20,000 22,000 24,600 25,000 31,400

C.O.P (17°F) 2.2 2.3 2.4 2.2 2.5 2.1 2.2 2.1

HSPF 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0

Evaporator Motor

Type EEM EEM EEM EEM EEM EEM EEM EEM

Wheel (D x W) 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9

Nominal Cooling CFM 860 1,000 1,200 1,250 1,250 1,700 1,350 1,800

FLA 4.1 4.1 4.1 4.1 2.9 5.8 2.9 7.6

No. of Speeds 5 5 5 5 5 5 5 5

Horsepower - RPM ½ -1,050 ½ -1,050 ½ -1,050 ½ -1,075 ¾ - 1,050 ¾ - 1,050 ¾ - 1,050 1-1,050

Evaporator Coil

Face Area (²) 4.5 4.5 4.5 4.5 6.2 6.2 6.2 6.2

Rows Deep/ Fin per Inch 3/ 14 3/ 14 4/ 14 4/ 14 4/ 14 4/ 14 4/ 14 4/ 14

Expansion Device TXV TXV TXV TXV TXV TXV TXV TXV

Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾" ¾" ¾"

R-410A Refrigerant Charge (oz.) 113 128 174 193 233 214 214 207

Condenser Fan / Coil

Horsepower - RPM ¼ - 850 ¼ - 850 ¼ - 850 ¼ - 850 ¼ - 1,075 ⅓ - 1,075 ¼ - 1,075 ⅓ - 1,075

FLA/LRA 1.5/ 3.0 1.5/ 3.0 1.5/ 3.0 1.5/ 3.0 1.4 / 2.9 2.5/ 5.2 1.4 / 2.9 2.5/ 5.2

Fan Diameter / # Fan Blades 22 / 3 22 / 3 22 / 3 22 / 3 22 / 3 22 / 3 22 / 3 22 / 3

Face Area (²) 17.2 17.2 17.2 17.2 21.2 21.2 21.2 21.2

Rows Deep/ Fin per Inch 1 / 22 1 / 22 2 / 16 2 / 16 2 / 16 2 / 16 2 / 16 2 / 16

Compressor

Quanty 11111111

Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll

Stage Single Single Single Two Single Two Two Two

Electrical Data

Voltage/ Phase/ Hz 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60

Compressor RLA/ LRA 12.8 / 58 14.1 / 73 16.7 / 79 16.7 / 96 17.9 / 112 21.2 / 96 21.2 / 96 25.6 / 118

Indoor Blower FLA 4.1 4.1 4.1 4.1 2.9 5.8 2.9 7.6

Total Unit Amps 18.4 19.7 22.3 22.3 22.2 29.4 25.5 35.6

Min. Circuit Ampacity¹ 21.6 23.2 26.5 26.5 26.7 34.8 30.8 42.1

Max. Overcurrent Protecon² 30 35 40 40 40 50 50 60

Shipping Weight (lbs) 376 385 438 460 492 492 492 523

¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.

² May use fuses or HACR-type circuit breakers of the same size as noted.

Note: Always check the S&R plate for electrical data on the unit being installed.

prodUCt speCifiCations prodUCt speCifiCations

4 www.goodmanmfg.com SS-GPH15M

expanded Cooling data — gph1524m41a*

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

970

MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -

S/T 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.88 0.74 0.51 -

∆T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -

kW 1.60 1.63 1.68 - 1.72 1.76 1.81 - 1.82 1.86 1.92 - 1.91 1.96 2.02 - 1.99 2.04 2.10 - 2.06 2.10 2.17 -

Amps 7.5 7.7 7.9 - 8.0 8.2 8.4 - 8.5 8.7 8.9 - 9.0 9.2 9.4 - 9.5 9.7 9.9 - 9.9 10.1 10.4 -

Hi PR 216 232 245 - 242 261 275 - 275 296 313 - 314 337 356 - 353 380 401 - 390 419 443 -

Lo PR 106 113 124 - 112 120 131 - 117 124 136 - 123 131 143 - 129 137 149 - 133 142 155 -

860

MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -

S/T 0.73 0.61 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.84 0.70 0.48 - 0.84 0.70 0.49 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

kW 1.59 1.62 1.67 - 1.71 1.74 1.80 - 1.81 1.85 1.90 - 1.90 1.94 2.00 - 1.98 2.02 2.08 - 2.04 2.09 2.15 -

Amps 7.5 7.6 7.8 - 8.0 8.1 8.3 - 8.5 8.6 8.9 - 8.9 9.1 9.4 - 9.4 9.6 9.8 - 9.8 10.0 10.3 -

Hi PR 214 230 243 - 240 258 272 - 273 293 310 - 310 334 353 - 349 376 397 - 386 415 439 -

Lo PR 105 112 122 - 111 118 129 - 116 123 134 - 122 129 141 - 127 135 148 - 132 140 153 -

750

MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -

S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -

∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

kW 1.55 1.59 1.63 - 1.67 1.70 1.75 - 1.77 1.80 1.86 - 1.85 1.89 1.95 - 1.93 1.97 2.03 - 1.99 2.04 2.10 -

Amps 7.3 7.5 7.7 - 7.8 7.9 8.1 - 8.3 8.5 8.7 - 8.7 8.9 9.1 - 9.2 9.4 9.6 - 9.6 9.8 10.1 -

Hi PR 207 223 235 - 232 250 264 - 264 285 300 - 301 324 342 - 339 365 385 - 374 403 425 -

Lo PR 102 109 119 - 108 115 125 - 112 119 130 - 118 125 137 - 124 131 143 - 128 136 148 -

970

MBh 23.9 24.6 26.7 28.6 23.4 24.1 26.0 27.9 22.8 23.5 25.4 27.3 22.2 22.9 24.8 26.6 21.1 21.8 23.6 25.3 19.6 20.2 21.8 23.4

S/T 0.88 0.78 0.59 0.38 0.91 0.81 0.61 0.40 0.93 0.83 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.89 0.67 0.43 1.00 0.90 0.68 0.44

∆T 20 18 15 10 20 19 15 10 20 19 15 10 20 19 15 11 20 18 15 10 19 17 14 10

kW 1.62 1.65 1.70 1.75 1.73 1.77 1.82 1.88 1.84 1.88 1.94 2.00 1.93 1.97 2.03 2.10 2.01 2.05 2.12 2.19 2.08 2.12 2.19 2.26

Amps 7.6 7.7 7.9 8.2 8.1 8.2 8.4 8.7 8.6 8.8 9.0 9.3 9.1 9.3 9.5 9.8 9.5 9.7 10.0 10.3 10.0 10.2 10.5 10.8

Hi PR 218 235 248 258 245 263 278 290 278 299 316 330 317 341 360 375 356 383 405 422 394 424 447 467

Lo PR 107 114 125 133 114 121 132 140 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166

860

MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.2 24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7

S/T 0.84 0.75 0.57 0.36 0.87 0.77 0.59 0.38 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42

∆T 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10

kW 1.60 1.64 1.68 1.74 1.72 1.76 1.81 1.87 1.82 1.86 1.92 1.98 1.92 1.96 2.02 2.08 1.99 2.04 2.10 2.17 2.06 2.10 2.17 2.24

Amps 7.5 7.7 7.9 8.1 8.0 8.2 8.4 8.6 8.5 8.7 8.9 9.2 9.0 9.2 9.4 9.7 9.5 9.7 9.9 10.2 9.9 10.1 10.4 10.7

Hi PR 216 232 245 256 242 261 275 287 275 296 313 326 314 338 356 372 353 380 401 418 390 420 443 462

Lo PR 106 113 124 132 112 120 131 139 117 124 136 145 123 131 143 152 129 137 149 159 133 142 155 165

750

MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.5 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0

S/T 0.81 0.72 0.55 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.92 0.83 0.63 0.40

∆T 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 1.57 1.60 1.65 1.70 1.68 1.71 1.77 1.82 1.78 1.82 1.87 1.93 1.87 1.91 1.97 2.03 1.94 1.99 2.05 2.12 2.01 2.05 2.12 2.19

Amps 7.4 7.5 7.7 7.9 7.8 8.0 8.2 8.4 8.4 8.5 8.7 9.0 8.8 9.0 9.2 9.5 9.3 9.4 9.7 10.0 9.7 9.9 10.2 10.5

Hi PR 209 225 238 248 235 253 267 278 267 287 304 317 304 327 346 361 342 368 389 406 378 407 430 448

Lo PR 103 110 120 128 109 116 127 135 113 121 132 140 119 127 138 147 125 133 145 154 129 137 150 160

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

prodUCt speCifiCations prodUCt speCifiCations

SS-GPH15M www.goodmanmfg.com 5

expanded Cooling data — gph1524m41a* (Cont.)

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

970

MBh 24.3 24.9 26.6 28.4 23.8 24.3 26.0 27.7 23.2 23.7 25.3 27.1 22.6 23.1 24.7 26.4 21.5 22.0 23.5 25.1 19.9 20.4 21.8 23.3

S/T 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.63

∆T 22 21 18 15 23 21 19 15 22 22 19 15 21 22 19 15 20 21 19 15 19 19 17 14

kW 1.63 1.66 1.71 1.76 1.75 1.78 1.84 1.90 1.85 1.89 1.95 2.01 1.95 1.99 2.05 2.12 2.03 2.07 2.13 2.20 2.09 2.14 2.21 2.28

Amps 7.7 7.8 8.0 8.2 8.1 8.3 8.5 8.7 8.7 8.8 9.1 9.3 9.1 9.3 9.6 9.9 9.6 9.8 10.1 10.4 10.1 10.3 10.6 10.9

Hi PR 220 237 250 261 247 266 281 293 281 302 319 333 320 344 364 379 360 387 409 427 398 428 452 471

Lo PR 109 116 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 140 152 162 136 144 158 168

860

MBh 23.6 24.1 25.8 27.6 23.1 23.6 25.2 26.9 22.5 23.0 24.6 26.3 22.0 22.5 24.0 25.7 20.9 21.3 22.8 24.4 19.3 19.8 21.1 22.6

S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.97 0.91 0.74 0.56 1.00 0.94 0.77 0.57 1.00 0.98 0.80 0.60 1.00 0.99 0.80 0.60

∆T 23 22 19 15 23 22 20 16 23 22 20 16 24 23 20 16 22 22 19 16 21 21 18 14

kW 1.62 1.65 1.70 1.75 1.73 1.77 1.82 1.88 1.84 1.88 1.94 2.00 1.93 1.97 2.03 2.10 2.01 2.05 2.12 2.19 2.08 2.12 2.19 2.26

Amps 7.6 7.7 7.9 8.2 8.1 8.2 8.4 8.7 8.6 8.8 9.0 9.3 9.1 9.3 9.5 9.8 9.5 9.7 10.0 10.3 10.0 10.2 10.5 10.8

Hi PR 218 235 248 258 245 263 278 290 278 299 316 330 317 341 360 375 356 384 405 422 394 424 447 467

Lo PR 107 114 125 133 114 121 132 140 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166

750

MBh 21.8 22.3 23.8 25.5 21.3 21.8 23.3 24.9 20.8 21.3 22.7 24.3 20.3 20.7 22.2 23.7 19.3 19.7 21.0 22.5 17.9 18.2 19.5 20.8

S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.01 0.94 0.77 0.57 1.01 0.95 0.77 0.58

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15

kW 1.58 1.61 1.66 1.71 1.69 1.73 1.78 1.84 1.79 1.83 1.89 1.95 1.88 1.92 1.98 2.05 1.96 2.00 2.07 2.13 2.03 2.07 2.14 2.21

Amps 7.4 7.6 7.8 8.0 7.9 8.0 8.2 8.5 8.4 8.6 8.8 9.1 8.9 9.0 9.3 9.6 9.3 9.5 9.8 10.1 9.8 10.0 10.2 10.6

Hi PR 211 228 240 251 237 255 270 281 270 290 307 320 307 331 349 364 346 372 393 410 382 411 434 453

Lo PR 104 111 121 129 110 117 128 136 114 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161

970

MBh 24.8 25.2 26.4 28.2 24.2 24.7 25.8 27.6 23.6 24.1 25.2 26.9 23.0 23.5 24.6 26.2 21.9 22.3 23.4 24.9 20.3 20.7 21.6 23.1

S/T 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.93 0.76 1.00 1.00 0.96 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82

∆T 23 23 22 19 23 23 22 19 22 23 22 19 22 22 22 19 21 21 22 19 19 20 21 18

kW 1.64 1.67 1.72 1.78 1.76 1.80 1.85 1.91 1.87 1.91 1.97 2.03 1.96 2.00 2.07 2.13 2.04 2.09 2.15 2.22 2.11 2.16 2.23 2.30

Amps 7.7 7.8 8.0 8.3 8.2 8.3 8.5 8.8 8.7 8.9 9.1 9.4 9.2 9.4 9.6 9.9 9.7 9.9 10.1 10.5 10.2 10.4 10.6 11.0

Hi PR 222 239 253 264 249 268 284 296 284 305 322 336 323 348 367 383 364 391 413 431 402 432 456 476

Lo PR 110 117 127 136 116 123 135 143 120 128 140 149 126 135 147 156 133 141 154 164 137 146 159 170

860

MBh 24.0 24.5 25.7 27.4 23.5 23.9 25.1 26.8 22.9 23.4 24.5 26.1 22.4 22.8 23.9 25.5 21.2 21.7 22.7 24.2 19.7 20.1 21.0 22.4

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78

∆T 25 24 23 20 25 25 23 20 25 25 23 20 24 24 23 20 23 23 23 20 21 21 22 19

kW 1.63 1.66 1.71 1.76 1.75 1.78 1.84 1.90 1.85 1.89 1.95 2.01 1.95 1.99 2.05 2.12 2.03 2.07 2.13 2.20 2.09 2.14 2.21 2.28

Amps 7.7 7.8 8.0 8.2 8.1 8.3 8.5 8.7 8.7 8.8 9.1 9.3 9.1 9.3 9.6 9.9 9.6 9.8 10.1 10.4 10.1 10.3 10.6 10.9

Hi PR 220 237 250 261 247 266 281 293 281 302 319 333 320 344 364 379 360 387 409 427 398 428 452 471

Lo PR 109 116 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 140 152 162 136 144 158 168

750

MBh 22.2 22.6 23.7 25.3 21.7 22.1 23.1 24.7 21.2 21.6 22.6 24.1 20.6 21.0 22.0 23.5 19.6 20.0 20.9 22.3 18.2 18.5 19.4 20.7

S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.93 0.75

∆T 25 25 23 20 26 25 24 21 26 25 24 21 25 25 24 21 24 25 24 20 22 23 22 19

kW 1.59 1.62 1.67 1.72 1.71 1.74 1.79 1.85 1.81 1.85 1.90 1.96 1.90 1.94 2.00 2.07 1.98 2.02 2.08 2.15 2.04 2.09 2.15 2.22

Amps 7.5 7.6 7.8 8.0 8.0 8.1 8.3 8.5 8.5 8.6 8.9 9.1 8.9 9.1 9.4 9.6 9.4 9.6 9.8 10.1 9.8 10.0 10.3 10.6

Hi PR 214 230 243 253 240 258 272 284 273 293 310 323 310 334 353 368 349 376 397 414 386 415 438 457

Lo PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

prodUCt speCifiCations prodUCt speCifiCations

6 www.goodmanmfg.com SS-GPH15M

expanded Cooling data — gph1530m41a*

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1125

MBh 28.4 29.5 32.3 - 27.8 28.8 31.5 - 27.1 28.1 30.8 - 26.4 27.4 30.0 - 25.1 26.0 28.5 - 23.3 24.1 26.4 -

S/T 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.88 0.74 0.51 -

∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

kW 1.88 1.92 1.99 - 2.03 2.07 2.14 - 2.16 2.21 2.28 - 2.27 2.32 2.40 - 2.37 2.42 2.50 - 2.45 2.51 2.59 -

Amps 8.1 8.2 8.5 - 8.6 8.8 9.1 - 9.3 9.5 9.8 - 9.9 10.1 10.4 - 10.5 10.7 11.0 - 11.0 11.3 11.6 -

Hi PR 229 246 260 - 257 276 292 - 292 314 332 - 333 358 378 - 374 403 425 - 414 445 470 -

Lo PR 109 116 127 - 116 123 134 - 120 128 139 - 126 134 146 - 132 141 154 - 137 145 159 -

1000

MBh 27.6 28.6 31.3 - 26.9 27.9 30.6 - 26.3 27.3 29.9 - 25.7 26.6 29.1 - 24.4 25.3 27.7 - 22.6 23.4 25.6 -

S/T 0.73 0.61 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.84 0.70 0.48 - 0.84 0.70 0.49 -

∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 15 12 -

kW 1.87 1.91 1.97 - 2.01 2.06 2.12 - 2.14 2.19 2.26 - 2.25 2.30 2.38 - 2.35 2.40 2.48 - 2.43 2.49 2.57 -

Amps 8.0 8.2 8.4 - 8.6 8.7 9.0 - 9.2 9.4 9.7 - 9.8 10.0 10.3 - 10.4 10.6 10.9 - 10.9 11.2 11.5 -

Hi PR 227 244 258 - 254 274 289 - 289 311 329 - 329 355 374 - 371 399 421 - 409 441 465 -

Lo PR 108 115 126 - 114 122 133 - 119 126 138 - 125 133 145 - 131 139 152 - 135 144 157 -

875

MBh 25.5 26.4 28.9 - 24.9 25.8 28.2 - 24.3 25.2 27.6 - 23.7 24.6 26.9 - 22.5 23.3 25.6 - 20.8 21.6 23.7 -

S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -

∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -

kW 1.82 1.86 1.92 - 1.96 2.01 2.07 - 2.09 2.13 2.20 - 2.20 2.25 2.32 - 2.29 2.34 2.42 - 2.37 2.42 2.50 -

Amps 7.8 8.0 8.2 - 8.4 8.5 8.8 - 9.0 9.2 9.5 - 9.6 9.8 10.1 - 10.1 10.3 10.7 - 10.7 10.9 11.2 -

Hi PR 220 237 250 - 247 265 280 - 281 302 319 - 320 344 363 - 359 387 409 - 397 427 451 -

Lo PR 105 112 122 - 111 118 129 - 115 123 134 - 121 129 141 - 127 135 147 - 131 140 153 -

1125

MBh 28.9 29.8 32.2 34.6 28.2 29.1 31.5 33.8 27.6 28.4 30.7 33.0 26.9 27.7 30.0 32.2 25.5 26.3 28.5 30.5 23.7 24.4 26.4 28.3

S/T 0.88 0.78 0.59 0.38 0.91 0.81 0.61 0.40 0.93 0.83 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.89 0.67 0.43 1.00 0.90 0.68 0.44

∆T 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10

kW 1.90 1.94 2.00 2.07 2.05 2.09 2.16 2.23 2.18 2.22 2.30 2.37 2.29 2.34 2.42 2.50 2.39 2.44 2.52 2.61 2.47 2.53 2.61 2.70

Amps 8.1 8.3 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.8 11.1 11.5 11.1 11.4 11.7 12.2

Hi PR 231 249 263 274 259 279 295 308 295 318 335 350 336 362 382 398 378 407 430 448 418 450 475 495

Lo PR 110 118 128 137 117 124 136 144 121 129 141 150 127 136 148 158 134 142 155 165 138 147 160 171

1000

MBh 28.1 28.9 31.3 33.6 27.4 28.2 30.5 32.8 26.8 27.5 29.8 32.0 26.1 26.9 29.1 31.2 24.8 25.5 27.6 29.7 23.0 23.6 25.6 27.5

S/T 0.84 0.75 0.57 0.36 0.87 0.77 0.59 0.38 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42

∆T 22 20 16 11 22 20 16 11 22 20 16 11 22 20 17 11 22 20 16 11 20 19 15 11

kW 1.88 1.92 1.99 2.05 2.03 2.07 2.14 2.21 2.16 2.21 2.28 2.35 2.27 2.32 2.40 2.48 2.37 2.42 2.50 2.59 2.45 2.51 2.59 2.68

Amps 8.1 8.2 8.5 8.7 8.6 8.8 9.1 9.4 9.3 9.5 9.8 10.1 9.9 10.1 10.4 10.8 10.5 10.7 11.0 11.4 11.0 11.3 11.6 12.0

Hi PR 229 246 260 271 257 276 292 305 292 314 332 346 333 358 378 394 374 403 425 444 414 445 470 490

Lo PR 109 116 127 135 116 123 134 143 120 128 139 149 126 134 147 156 132 141 154 164 137 145 159 169

875

MBh 25.9 26.7 28.9 31.0 25.3 26.0 28.2 30.3 24.7 25.4 27.5 29.5 24.1 24.8 26.8 28.8 22.9 23.6 25.5 27.4 21.2 21.8 23.6 25.4

S/T 0.81 0.72 0.55 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.92 0.83 0.63 0.40

∆T 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 11 21 19 16 11

kW 1.84 1.88 1.94 2.00 1.98 2.02 2.09 2.16 2.11 2.15 2.22 2.30 2.22 2.26 2.34 2.42 2.31 2.36 2.44 2.52 2.39 2.44 2.53 2.61

Amps 7.9 8.0 8.3 8.5 8.4 8.6 8.9 9.2 9.1 9.3 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.7 11.1 10.8 11.0 11.3 11.7

Hi PR 222 239 252 263 249 268 283 295 283 305 322 336 323 347 367 383 363 391 413 430 401 432 456 476

Lo PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 159 133 141 154 164

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

prodUCt speCifiCations prodUCt speCifiCations

SS-GPH15M www.goodmanmfg.com 7

expanded Cooling data — gph1530m41a* (Cont.)

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1125

MBh 29.4 30.1 32.1 34.3 28.7 29.4 31.4 33.5 28.0 28.7 30.6 32.7 27.4 28.0 29.9 31.9 26.0 26.6 28.4 30.3 24.1 24.6 26.3 28.1

S/T 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.96 0.78 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.84 0.63

∆T 23 22 19 15 23 22 19 16 23 22 19 16 22 23 20 16 21 22 19 15 20 20 18 14

kW 1.91 1.96 2.02 2.08 2.06 2.11 2.18 2.25 2.19 2.24 2.32 2.39 2.31 2.36 2.44 2.52 2.41 2.46 2.55 2.63 2.49 2.55 2.64 2.73

Amps 8.2 8.4 8.6 8.9 8.8 9.0 9.2 9.5 9.5 9.7 10.0 10.3 10.0 10.3 10.6 11.0 10.6 10.9 11.2 11.6 11.2 11.5 11.8 12.3

Hi PR 234 251 265 277 262 282 298 311 298 321 339 353 340 365 386 402 382 411 434 453 422 454 480 500

Lo PR 112 119 130 138 118 125 137 146 123 130 142 152 129 137 149 159 135 143 157 167 140 148 162 173

1000

MBh 28.6 29.2 31.2 33.3 27.9 28.5 30.5 32.6 27.2 27.8 29.7 31.8 26.6 27.1 29.0 31.0 25.2 25.8 27.6 29.5 23.4 23.9 25.5 27.3

S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.97 0.91 0.74 0.56 1.00 0.94 0.77 0.57 1.00 0.98 0.80 0.60 1.00 0.99 0.80 0.60

∆T 24 23 20 16 24 23 20 16 24 23 20 16 24 24 20 16 23 23 20 16 21 22 19 15

kW 1.90 1.94 2.00 2.07 2.05 2.09 2.16 2.23 2.18 2.22 2.30 2.37 2.29 2.34 2.42 2.50 2.39 2.44 2.52 2.61 2.47 2.53 2.61 2.70

Amps 8.1 8.3 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.8 11.1 11.5 11.1 11.4 11.7 12.2

Hi PR 231 249 263 274 260 279 295 308 295 318 335 350 336 362 382 398 378 407 430 448 418 450 475 495

Lo PR 110 118 128 137 117 124 136 144 121 129 141 150 127 136 148 158 134 142 155 165 138 147 160 171

875

MBh 26.4 26.9 28.8 30.8 25.7 26.3 28.1 30.0 25.1 25.7 27.4 29.3 24.5 25.1 26.8 28.6 23.3 23.8 25.4 27.2 21.6 22.0 23.6 25.2

S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.01 0.94 0.77 0.57 1.01 0.95 0.77 0.58

∆T 24 23 20 16 25 24 21 16 25 24 21 17 25 24 21 17 25 24 21 16 23 22 19 15

kW 1.85 1.89 1.95 2.02 2.00 2.04 2.11 2.17 2.12 2.17 2.24 2.31 2.23 2.28 2.36 2.44 2.33 2.38 2.46 2.54 2.41 2.46 2.55 2.63

Amps 7.9 8.1 8.3 8.6 8.5 8.7 8.9 9.2 9.1 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.8 11.2 10.8 11.1 11.4 11.8

Hi PR 224 241 255 266 252 271 286 298 286 308 325 339 326 351 371 386 367 395 417 435 405 436 461 480

Lo PR 107 114 124 133 113 120 132 140 118 125 137 146 124 132 144 153 130 138 150 160 134 143 156 166

1125

MBh 29.9 30.5 31.9 34.1 29.2 29.8 31.2 33.3 28.5 29.1 30.5 32.5 27.8 28.4 29.7 31.7 26.4 27.0 28.2 30.1 24.5 25.0 26.2 27.9

S/T 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.93 0.76 1.00 1.00 0.96 0.78 1.00 1.00 1.00 0.81 1.00 1.00 1.00 0.82

∆T 24 24 23 20 24 24 23 20 23 24 23 20 23 23 23 20 22 22 23 20 20 20 21 19

kW 1.93 1.97 2.03 2.10 2.08 2.13 2.19 2.27 2.21 2.26 2.34 2.41 2.33 2.38 2.46 2.54 2.43 2.48 2.57 2.65 2.52 2.57 2.66 2.75

Amps 8.2 8.4 8.7 9.0 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.7 11.0 11.3 11.7 11.3 11.6 11.9 12.4

Hi PR 236 254 268 280 265 285 301 314 301 324 342 357 343 369 390 406 386 415 438 457 426 459 484 505

Lo PR 113 120 131 139 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 169 141 150 164 174

1000

MBh 29.1 29.6 31.0 33.1 28.4 28.9 30.3 32.3 27.7 28.2 29.6 31.6 27.0 27.6 28.9 30.8 25.7 26.2 27.4 29.2 23.8 24.2 25.4 27.1

S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78

∆T 26 25 24 21 26 26 24 21 25 26 24 21 25 25 24 21 24 24 24 21 22 22 22 19

kW 1.91 1.96 2.02 2.08 2.06 2.11 2.18 2.25 2.19 2.24 2.32 2.39 2.31 2.36 2.44 2.52 2.41 2.46 2.55 2.63 2.49 2.55 2.64 2.73

Amps 8.2 8.4 8.6 8.9 8.8 9.0 9.2 9.5 9.5 9.7 10.0 10.3 10.0 10.3 10.6 11.0 10.6 10.9 11.2 11.6 11.2 11.5 11.8 12.3

Hi PR 234 251 265 277 262 282 298 311 298 321 339 353 340 365 386 402 382 411 434 453 422 454 480 500

Lo PR 112 119 130 138 118 125 137 146 123 130 142 152 129 137 149 159 135 143 157 167 140 148 162 173

875

MBh 26.8 27.3 28.6 30.5 26.2 26.7 28.0 29.8 25.6 26.1 27.3 29.1 24.9 25.4 26.6 28.4 23.7 24.2 25.3 27.0 22.0 22.4 23.4 25.0

S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.88 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.93 0.75

∆T 26 26 24 21 26 26 25 21 26 26 25 21 26 26 25 21 25 25 24 21 23 24 23 20

kW 1.87 1.91 1.97 2.03 2.01 2.06 2.12 2.19 2.14 2.19 2.26 2.33 2.25 2.30 2.38 2.46 2.35 2.40 2.48 2.56 2.43 2.49 2.57 2.66

Amps 8.0 8.2 8.4 8.7 8.6 8.7 9.0 9.3 9.2 9.4 9.7 10.0 9.8 10.0 10.3 10.7 10.4 10.6 10.9 11.3 10.9 11.2 11.5 11.9

Hi PR 227 244 257 269 254 274 289 301 289 311 329 343 329 354 374 390 371 399 421 439 409 441 465 485

Lo PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

prodUCt speCifiCations prodUCt speCifiCations

8 www.goodmanmfg.com SS-GPH15M

expanded Cooling data — gph1536m41a*

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1350

MBh 34.6 35.9 39.3 - 33.8 35.1 38.4 - 33.0 34.2 37.5 - 32.2 33.4 36.6 - 30.6 31.7 34.8 - 28.4 29.4 32.2 -

S/T 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.48 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -

∆T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -

kW 2.26 2.31 2.38 - 2.44 2.49 2.57 - 2.59 2.65 2.73 - 2.72 2.78 2.88 - 2.84 2.90 3.00 - 2.94 3.00 3.10 -

Amps 10.8 11.0 11.3 - 11.5 11.7 12.0 - 12.3 12.5 12.9 - 13.0 13.2 13.6 - 13.7 13.9 14.3 - 14.3 14.6 15.0 -

Hi PR 228 245 259 - 256 275 290 - 291 313 330 - 331 356 376 - 372 401 423 - 411 443 468 -

Lo PR 107 114 125 - 114 121 132 - 118 126 137 - 124 132 144 - 130 138 151 - 134 143 156 -

1200

MBh 33.6 34.9 38.2 - 32.9 34.1 37.3 - 32.1 33.2 36.4 - 31.3 32.4 35.5 - 29.7 30.8 33.8 - 27.5 28.5 31.3 -

S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -

∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -

kW 2.25 2.29 2.36 - 2.42 2.47 2.55 - 2.57 2.62 2.71 - 2.70 2.76 2.85 - 2.82 2.88 2.97 - 2.91 2.98 3.08 -

Amps 10.7 10.9 11.2 - 11.4 11.6 11.9 - 12.2 12.4 12.8 - 12.9 13.1 13.5 - 13.5 13.8 14.2 - 14.2 14.5 14.9 -

Hi PR 225 243 256 - 253 272 287 - 288 310 327 - 328 353 372 - 369 397 419 - 407 438 463 -

Lo PR 106 113 124 - 112 120 131 - 117 124 136 - 123 131 142 - 129 137 149 - 133 141 154 -

1050

MBh 31.1 32.2 35.3 - 30.3 31.4 34.4 - 29.6 30.7 33.6 - 28.9 29.9 32.8 - 27.4 28.4 31.2 - 25.4 26.3 28.9 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -

∆T 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -

kW 2.19 2.24 2.31 - 2.36 2.41 2.49 - 2.51 2.56 2.64 - 2.64 2.69 2.78 - 2.75 2.81 2.90 - 2.84 2.90 3.00 -

Amps 10.5 10.7 11.0 - 11.2 11.4 11.7 - 11.9 12.2 12.5 - 12.6 12.8 13.2 - 13.2 13.5 13.9 - 13.9 14.2 14.6 -

Hi PR 219 235 249 - 245 264 279 - 279 300 317 - 318 342 361 - 358 385 406 - 395 425 449 -

Lo PR 103 110 120 - 109 116 127 - 113 121 132 - 119 127 138 - 125 133 145 - 129 137 150 -

1350

MBh 35.2 36.3 39.3 42.1 34.4 35.4 38.4 41.2 33.6 34.6 37.4 40.2 32.8 33.7 36.5 39.2 31.1 32.1 34.7 37.2 28.8 29.7 32.1 34.5

S/T 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.99 0.88 0.67 0.43 1.00 0.89 0.67 0.43

∆T 21 19 16 11 21 19 16 11 21 19 16 11 21 20 16 11 21 19 16 11 20 18 15 10

kW 2.28 2.33 2.40 2.48 2.46 2.51 2.59 2.67 2.61 2.67 2.75 2.85 2.75 2.81 2.90 3.00 2.86 2.93 3.02 3.13 2.96 3.03 3.13 3.24

Amps 10.9 11.1 11.4 11.7 11.6 11.8 12.1 12.5 12.4 12.6 13.0 13.4 13.1 13.3 13.7 14.1 13.8 14.0 14.4 14.9 14.4 14.7 15.2 15.6

Hi PR 230 248 261 273 258 278 293 306 294 316 334 348 334 360 380 396 376 405 427 446 416 447 472 493

Lo PR 109 115 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 140 152 162 136 144 158 168

1200

MBh 34.2 35.2 38.1 40.9 33.4 34.4 37.2 40.0 32.6 33.6 36.4 39.0 31.8 32.8 35.5 38.1 30.2 31.1 33.7 36.2 28.0 28.8 31.2 33.5

S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.61 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41

∆T 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 16 11 20 19 15 11

kW 2.26 2.31 2.38 2.46 2.44 2.49 2.57 2.65 2.59 2.65 2.73 2.82 2.72 2.78 2.88 2.97 2.84 2.90 3.00 3.10 2.94 3.00 3.10 3.21

Amps 10.8 11.0 11.3 11.6 11.5 11.7 12.0 12.4 12.3 12.5 12.9 13.3 13.0 13.2 13.6 14.0 13.7 13.9 14.3 14.8 14.3 14.6 15.0 15.5

Hi PR 228 245 259 270 256 275 290 303 291 313 330 345 331 356 376 392 372 401 423 441 412 443 468 488

Lo PR 107 114 125 133 114 121 132 140 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166

1050

MBh 31.6 32.5 35.2 37.8 30.8 31.8 34.4 36.9 30.1 31.0 33.6 36.0 29.4 30.2 32.7 35.1 27.9 28.7 31.1 33.4 25.8 26.6 28.8 30.9

S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40

∆T 22 20 17 11 22 21 17 12 22 21 17 12 23 21 17 12 22 20 17 12 21 19 16 11

kW 2.21 2.26 2.33 2.40 2.38 2.43 2.51 2.59 2.53 2.58 2.66 2.75 2.66 2.72 2.80 2.90 2.77 2.83 2.92 3.02 2.86 2.93 3.02 3.13

Amps 10.6 10.8 11.1 11.4 11.2 11.5 11.8 12.1 12.0 12.2 12.6 13.0 12.7 12.9 13.3 13.7 13.3 13.6 14.0 14.4 14.0 14.3 14.7 15.2

Hi PR 221 238 251 262 248 267 282 294 282 303 320 334 321 346 365 381 361 389 411 428 399 430 454 473

Lo PR 104 111 121 129 110 117 128 136 114 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

prodUCt speCifiCations prodUCt speCifiCations

SS-GPH15M www.goodmanmfg.com 9

expanded Cooling data — gph1536m41a* (Cont.)

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

1350

MBh 35.9 36.6 39.2 41.9 35.0 35.8 38.2 40.9 34.2 34.9 37.3 39.9 33.4 34.1 36.4 38.9 31.7 32.4 34.6 37.0 29.4 30.0 32.1 34.3

S/T 0.95 0.89 0.73 0.54 1.00 0.93 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.83 0.62 1.00 1.00 0.83 0.62

∆T 23 22 19 15 24 23 20 16 23 23 20 16 23 23 20 16 22 22 19 16 20 20 18 15

kW 2.30 2.35 2.42 2.50 2.48 2.53 2.61 2.70 2.63 2.69 2.78 2.87 2.77 2.83 2.92 3.02 2.89 2.95 3.05 3.15 2.99 3.05 3.16 3.26

Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.7 13.1 13.5 13.2 13.4 13.8 14.2 13.9 14.2 14.5 15.0 14.6 14.9 15.3 15.8

Hi PR 232 250 264 275 261 281 296 309 297 319 337 351 338 363 384 400 380 409 432 450 420 452 477 498

Lo PR 110 117 127 136 116 123 135 143 120 128 140 149 126 135 147 156 133 141 154 164 137 146 159 170

1200

MBh 34.8 35.6 38.0 40.6 34.0 34.8 37.1 39.7 33.2 33.9 36.2 38.7 32.4 33.1 35.4 37.8 30.8 31.4 33.6 35.9 28.5 29.1 31.1 33.3

S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.96 0.90 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 0.98 0.80 0.59

∆T 24 23 20 16 25 23 20 16 25 24 20 16 25 24 21 16 24 23 20 16 22 22 19 15

kW 2.28 2.33 2.40 2.48 2.46 2.51 2.59 2.67 2.61 2.67 2.75 2.85 2.75 2.81 ## 3.00 2.86 2.93 3.02 3.13 2.96 3.03 3.13 3.24

Amps 10.9 11.1 11.4 11.7 11.6 11.8 12.1 12.5 12.4 12.6 13.0 13.4 13.1 13.3 13.7 14.1 13.8 14.0 14.4 14.9 14.4 14.7 15.2 15.6

Hi PR 230 248 261 273 258 278 293 306 294 316 334 348 334 360 380 396 376 405 428 446 416 447 472 493

Lo PR 109 115 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 140 152 162 136 144 158 168

1050

MBh 32.1 32.8 35.1 37.5 31.4 32.1 34.3 36.6 30.6 31.3 33.5 35.8 29.9 30.5 32.6 34.9 28.4 29.0 31.0 33.1 26.3 26.9 28.7 30.7

S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.94 0.77 0.57

∆T 25 24 21 16 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 16 23 22 19 15

kW 2.23 2.27 2.35 2.42 2.40 2.45 2.53 2.61 2.55 2.60 2.69 2.77 2.68 2.74 2.83 2.92 2.79 2.85 2.95 3.05 2.89 2.95 3.05 3.15

Amps 10.7 10.9 11.1 11.5 11.3 11.5 11.8 12.2 12.1 12.3 12.7 13.1 12.8 13.0 13.4 13.8 13.4 13.7 14.1 14.5 14.1 14.4 14.8 15.3

Hi PR 223 240 254 265 250 269 285 297 285 306 324 338 324 349 369 384 365 393 415 433 403 434 458 478

Lo PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163

1350

MBh 36.5 37.2 39.0 41.6 35.6 36.3 38.1 40.6 34.8 35.5 37.1 39.6 33.9 34.6 36.2 38.7 32.2 32.9 34.4 36.7 29.9 30.4 31.9 34.0

S/T 1.00 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.99 0.80 1.00 1.00 1.00 0.81

∆T 25 24 23 20 24 25 23 20 24 24 23 20 23 24 24 20 22 22 23 20 20 21 22 19

kW 2.32 2.37 2.44 2.52 2.50 2.55 2.63 2.72 2.65 2.71 2.80 2.89 2.79 2.85 2.95 3.05 2.91 2.98 3.07 3.18 3.01 3.08 3.18 3.29

Amps 11.0 11.3 11.5 11.9 11.7 12.0 12.3 12.7 12.6 12.8 13.2 13.6 13.3 13.5 13.9 14.4 14.0 14.3 14.7 15.1 14.7 15.0 15.4 15.9

Hi PR 235 253 267 278 263 283 299 312 300 322 340 355 341 367 388 404 384 413 436 455 424 456 482 503

Lo PR 111 118 129 137 117 124 136 145 122 129 141 150 128 136 148 158 134 142 155 166 138 147 161 171

1200

MBh 35.4 36.1 37.8 40.4 34.6 35.3 36.9 39.4 33.8 34.4 36.1 38.5 33.0 33.6 35.2 37.5 31.3 31.9 33.4 35.7 29.0 29.6 31.0 33.0

S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.77 1.00 1.00 0.95 0.77

∆T 26 25 24 21 26 26 24 21 26 26 24 21 25 26 25 21 24 24 24 21 22 23 23 20

kW 2.30 2.35 2.42 2.50 2.48 2.53 2.61 2.70 2.63 2.69 2.78 2.87 2.77 2.83 2.92 3.02 2.89 2.95 3.05 3.15 2.99 3.05 3.16 3.26

Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.7 13.1 13.5 13.2 13.4 13.8 14.2 13.9 14.2 14.5 15.0 14.6 14.9 15.3 15.8

Hi PR 232 250 264 275 261 281 296 309 297 319 337 351 338 363 384 400 380 409 432 450 420 452 477 498

Lo PR 110 117 127 136 116 123 135 143 120 128 140 149 126 135 147 156 133 141 154 164 137 146 159 170

1050

MBh 32.7 33.3 34.9 37.2 31.9 32.6 34.1 36.4 31.2 31.8 33.3 35.5 30.4 31.0 32.5 34.6 28.9 29.5 30.9 32.9 26.8 27.3 28.6 30.5

S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.74

∆T 26 26 24 21 27 26 25 21 27 26 25 21 27 26 25 22 25 26 25 21 23 24 23 20

kW 2.25 2.29 2.36 2.44 2.42 2.47 2.55 2.63 2.57 2.62 2.71 2.80 2.70 2.76 2.85 2.95 2.81 2.88 2.97 3.07 2.91 2.98 3.08 3.18

Amps 10.7 10.9 11.2 11.5 11.4 11.6 11.9 12.3 12.2 12.4 12.8 13.2 12.9 13.1 13.5 13.9 13.5 13.8 14.2 14.7 14.2 14.5 14.9 15.4

Hi PR 225 243 256 267 253 272 287 300 288 310 327 341 328 353 372 388 369 397 419 437 407 438 463 483

Lo PR 106 113 124 132 112 120 130 139 117 124 136 144 123 130 142 152 129 137 149 159 133 141 154 164

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

prodUCt speCifiCations prodUCt speCifiCations

10 www.goodmanmfg.com SS-GPH15M

expanded Cooling data — gph1542m41a* – low stage

Outdoor Ambient Temperature

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71

955

MBh 26.9 27.9 30.6 - 26.3 27.3 29.9 - 25.7 26.6 29.2 - 25.1 26.0 28.5 - 23.8 24.7 27.0 - 22.1 22.9 25.1 -

S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.81 0.68 0.47 -

∆T 18 16 12 - 18 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

kW 1.80 1.84 1.90 - 1.94 1.99 2.06 - 2.07 2.12 2.19 - 2.19 2.24 2.31 - 2.28 2.33 2.41 - 2.36 2.42 2.50 -

Amps 7.7 7.9 8.1 - 8.3 8.5 8.7 - 9.0 9.2 9.5 - 9.6 9.8 10.1 - 10.1 10.4 10.7 - 10.7 11.0 11.3 -

Hi PR 218 235 248 - 245 263 278 - 278 300 316 - 317 341 360 - 357 384 405 - 394 424 448 -

Lo PR 107 114 124 - 113 120 131 - 118 125 137 - 124 131 144 - 130 138 150 - 134 143 156 -

850

MBh 26.2 27.1 29.7 - 25.6 26.5 29.0 - 24.9 25.9 28.3 - 24.3 25.2 27.6 - 23.1 24.0 26.3 - 21.4 22.2 24.3 -

S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.77 0.64 0.45 -

∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -

kW 1.79 1.82 1.88 - 1.93 1.97 2.04 - 2.06 2.10 2.17 - 2.17 2.22 2.29 - 2.26 2.31 2.39 - 2.34 2.40 2.48 -

Amps 7.7 7.8 8.1 - 8.2 8.4 8.7 - 8.9 9.1 9.4 - 9.5 9.7 10.0 - 10.0 10.3 10.6 - 10.6 10.9 11.2 -

Hi PR 216 232 245 - 242 261 275 - 276 297 313 - 314 338 357 - 353 380 401 - 390 420 443 -

Lo PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 133 141 154 -

745

MBh 24.1 25.0 27.4 - 23.6 24.4 26.8 - 23.0 23.9 26.1 - 22.5 23.3 25.5 - 21.3 22.1 24.2 - 19.8 20.5 22.4 -

S/T 0.65 0.54 0.37 - 0.67 0.56 0.39 - 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.74 0.62 0.43 -

∆T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -

kW 1.74 1.78 1.84 - 1.88 1.92 1.99 - 2.00 2.05 2.12 - 2.11 2.16 2.23 - 2.20 2.25 2.33 - 2.28 2.34 2.42 -

Amps 7.5 7.6 7.9 - 8.0 8.2 8.5 - 8.7 8.9 9.1 - 9.2 9.4 9.7 - 9.8 10.0 10.3 - 10.3 10.6 10.9 -

Hi PR 209 225 238 - 235 253 267 - 267 288 304 - 304 328 346 - 343 369 389 - 378 407 430 -

Lo PR 103 109 120 - 109 116 126 - 113 120 131 - 119 126 138 - 124 132 144 - 129 137 149 -

955

MBh 27.4 28.2 30.5 32.8 26.8 27.6 29.8 32.0 26.1 26.9 29.1 31.3 25.5 26.2 28.4 30.5 24.2 24.9 27.0 29.0 22.4 23.1 25.0 26.8

S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.59 0.38 0.91 0.82 0.62 0.40 0.92 0.82 0.62 0.40

∆T 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10

kW 1.82 1.86 1.92 1.98 1.96 2.01 2.07 2.14 2.09 2.14 2.21 2.29 2.20 2.26 2.33 2.41 2.30 2.36 2.44 2.52 2.39 2.44 2.53 2.61

Amps 7.8 8.0 8.2 8.5 8.4 8.6 8.8 9.1 9.0 9.3 9.5 9.9 9.6 9.9 10.2 10.5 10.2 10.5 10.8 11.2 10.8 11.1 11.4 11.8

Hi PR 220 237 250 261 247 266 281 293 281 303 320 333 320 345 364 380 360 388 409 427 398 428 452 472

Lo PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167

850

MBh 26.6 27.4 29.7 31.8 26.0 26.8 29.0 31.1 25.4 26.1 28.3 30.3 24.8 25.5 27.6 29.6 23.5 24.2 26.2 28.1 21.8 22.4 24.3 26.1

S/T 0.76 0.68 0.52 0.33 0.79 0.71 0.54 0.34 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.88 0.78 0.59 0.38

∆T 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 12 21 19 16 11

kW 1.80 1.84 1.90 1.96 1.95 1.99 2.06 2.13 2.07 2.12 2.19 2.27 2.19 2.24 2.31 2.39 2.28 2.33 2.42 2.50 2.36 2.42 2.50 2.59

Amps 7.7 7.9 8.1 8.4 8.3 8.5 8.8 9.1 9.0 9.2 9.5 9.8 9.6 9.8 10.1 10.4 10.1 10.4 10.7 11.1 10.7 11.0 11.3 11.7

Hi PR 218 235 248 259 245 263 278 290 278 300 316 330 317 341 360 376 357 384 405 423 394 424 448 467

Lo PR 107 114 124 133 113 120 131 140 118 125 137 146 124 131 144 153 130 138 150 160 134 143 156 166

745

MBh 24.6 25.3 27.4 29.4 24.0 24.7 26.7 28.7 23.4 24.1 26.1 28.0 22.8 23.5 25.5 27.3 21.7 22.3 24.2 26.0 20.1 20.7 22.4 24.0

S/T 0.74 0.66 0.50 0.32 0.76 0.68 0.52 0.33 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.84 0.76 0.57 0.37

∆T 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11

kW 1.76 1.79 1.85 1.91 1.90 1.94 2.00 2.07 2.02 2.07 2.14 2.21 2.13 2.18 2.25 2.33 2.22 2.27 2.35 2.43 2.30 2.36 2.44 2.52

Amps 7.5 7.7 7.9 8.2 8.1 8.3 8.5 8.8 8.7 8.9 9.2 9.5 9.3 9.5 9.8 10.2 9.9 10.1 10.4 10.8 10.4 10.7 11.0 11.4

Hi PR 212 228 240 251 237 256 270 281 270 291 307 320 308 331 350 365 346 372 393 410 382 411 434 453

Lo PR 104 111 121 129 110 117 128 136 114 121 133 141 120 128 139 148 126 134 146 155 130 138 151 161

IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power

High & low pressures are measured at the liquid & sucon access ngs. Amps = outdoor unit amps (comp.+ fans)

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Goodman Pompa di calore

Goodman

Goodman GPH13 Istruzioni operative

Goodman

Goodman R-410A Manuale utente

Goodman

Goodman RP-526A Manuale per l'uso e la cura

Goodman

Goodman CPC036XXX3BXJXBA Manuale per l'uso e la cura

Goodman

Goodman GSC140481A Documento tecnico

Goodman

Goodman ComfortNet ASXC160**1AA Series Istruzioni operative

Goodman

Goodman PC Manuale utente

Goodman

Goodman DSZ180601A Series Manuale utente

Goodman

Goodman GSH130181A Series Documento tecnico

Goodman

Goodman CPLE090 Manuale

Goodman

Goodman GPH1336M43 Series Manuale utente

Goodman

Goodman GPH1424H41AB Manuale per l'uso e la cura

Goodman

Goodman ComfortNet ASXC Series Istruzioni operative

Goodman

Goodman Condencing Unit Manuale utente

Goodman

Goodman GPH1624M41 Manuale utente

Goodman

Goodman ACNF Guida di riferimento rapido

Goodman

Goodman CPH COMMERCIAL SS-CPH90-150 Manuale utente

Goodman

Goodman DSX16 Manuale utente

Goodman

Goodman GPH16 M Series Manuale utente

Goodman

Goodman SS-CPKF50 SS-CPKF50 Manuale utente

Goodman

Goodman GSZ16 Manuale utente

Goodman

Goodman *PH 16 Istruzioni operative

Goodman

Goodman SS-GPH13MC Manuale utente

Goodman

Goodman *SZC 16 SEER Manuale utente

Manuali Pompa di calore popolari di altre marche

MICROWELL

MICROWELL HP 1000 GREEN Manuale utente

Sanyo

Sanyo SAP120FCH Manuale utente

Daikin

Daikin EHYHBH05AA Manuale utente

Panasonic

Panasonic WH-SDF03E3E5 Guida

Bryant

Bryant 544B Manuale utente

Airxcel

Airxcel 45000 Series Manuale

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manuale utente

Dimplex

Dimplex LI 16I-TUR Guida utente

Carrier

Carrier WSHP Open v3 Guida rapida alla configurazione

TGM

TGM CTV14CN018A Manuale utente

Carrier

Carrier 38MGQ Series Manuale utente

Kokido

Kokido K2O K880BX/EU Guida alla risoluzione dei problemi

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guida rapida

Carrier

Carrier 48EZN Manuale utente

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Istruzioni operative

Ariston

Ariston NIMBUS Manuale utente

Weishaupt

Weishaupt WWP L 7 Guida utente

GE Zoneline AZ85H09EAC Manuale utente
