Goodmans GV101YRH32 Manuale utente
GV101YRH Series
HD Digital TV Recorder
User Guide
IMPORTANT: Please read all instructions carefully before use and keep for future reference.
2
Thank you for buying this HD Digital TV Recorder.
You may already be familiar with using a similar unit, but please take time to read
these instructions. They are designed to familiarise you with the unit’s many features
and to ensure you get the very best from your purchase.
In this manual the HD Digital TV Recorder will be referred to as the ‘digital box’.
You will also need
To use your digital box you will also need the following:
Rooftop aerial
It is recommended that you use a wideband rooftop aerial for your digital box to work
properly.
TV
A TV equipped with an HDMI socket is recommended. If your TV does not have an
HDMI socket, a SCART cable can be used. In this case you will need a SCART cable
(not supplied).
Freeview coverage
For more information about Freeview and to check reception in your area, visit
www.freeview.co.uk
Introduction
Safety is important
Use of any electrical equipment should be undertaken with care. Please read
the safety section on pages 37 before using this digital box. This appliance is for
household use only.
A digital box lets you access the free
digital channels that are broadcast
in the UK. It uses a digital signal
received through your normal aerial
and lets you watch through your
existing television.
A FREEVIEW digital box gives you
digital TV channels and digital radio
stations, without a subscription or
contract. For more information about
FREEVIEW and to check reception in
your area, visit www.freeview.co.uk
This product is capable of receiving
and decoding Dolby Digital Plus.
Manufactured under license from
Dolby Laboratories. Dolby and the
double-D symbol are trademarks
of Dolby Laboratories.
3
What’s in the box?
01
02
03
04
Your HD DigitalTV Recorder .......4
Getting started .......................... 6
Daily use .................................14
Advanced features .................. 19
Settings...................................28
Troubleshooting.......................35
Specifications..........................36
Warnings.................................37
Guarantee ...............................38
05
06
07
08
09
Contents
HD Digital TV Recorder
Quick Start Guide
The above images are for illustrative purposes only and may differ to the items
supplied.
Remote Control
FAV
ONLINE
Power supply
2 x AAA batteries
HDMI cable
RF cable
4
Your HD Digital TV Recorder01
Front view
Rear view
1
2. A
RF IN RF OUT NETWORK USB HDMI TV SCART AUX SCART S/PDIF DC IN
SCART FOR AUX
EQUIPMENT
RF IN
RF OUT SCART FOR TV
USB
NETWORK
(ETHERNET)
DC IN
(12VDC)
HDMI
S/PDIF
0000
4-DIGIT LED DISPLAYPOWER ON OFF INDICATOR
POWER ON OFF SWITCH
CHANNEL CHANGE BUTTON
REMOTE CONTROL SENSOR
5
Your HD Digital TV Recorder 01
Remote control
FAV
ONLINE
SWAP: Switches between
previous and currently
watched TV channels
0 – 9: Numerical keys
AD: Set Audio Description on/off AUD: Select audio
language (if available)
BACK: Return to previous menu
CH LIST (Channel List): Display
the list of stored channels
P+, P- (Change Channel):
Changes your TV channels
RED, GREEN, YELLOW, BLUE
Coloured Buttons: quick keys
EXIT: Exit the menu and
return to live TV
FAST FWD: (1) Fast
Forward at variable speeds
(2) Step through menu bars
GUIDE: Display the TV
programme guide
i (Information):
Displays information about
programmes and recordings
LIBRARY: Displays a library of
previously recorded programming
MENU: Display the Main Menu
MUTE: Turns your TV
sound on/off
Navigation:
Navigate up/down/left/right
in menus/on screen displays
OK: Press to confirm
current selection
ONLINE: Display the online menu
PLAY/PAUSE: Toggle action for
recordings and Live Pause TV
R (RECORD):
(1) Record a programme
(2) Set a future recording
REWIND:
(1) Fast Rewind at variable speeds
(2) Step through menu bars
STOP:
Stops recording or live paused TV
SUB: Set subtitles on/off
Volume (V+ V-):
Changes your TV volume
TEXT: Load text services
available on some channels
FAV (Favourites List):
Displays the list of your
favourite channels
POWER: Switches the main
unit to standby
HOME: Press
to return to BBC1 at any time
6
Connecting up to your TV
Your digital box may be connected to your TV via an HDMI connection or
by a SCART connection. Connecting via HDMI is recommended as this
will give better results.
There are three cables to be connected as shown below.
Cable 1.1. Connect the aerial cable between the RF IN socket on your
digital box and your external aerial wall socket.
Cable 2.2. (HDMI). Connect the HDMI cable between the HDMI socket
on the back of your digital box and an HDMI socket on your HD Ready
TV.
Cable 2.3. (SCART). Connect the SCART cable (not included) between
the TV SCART socket on the back of your digital box and the SCART
socket on your TV.
Cable 3.4. Connect the power supply to the DC IN connection on the
back of your digital box and connect the 3 pin plug to a mains power
socket, see step 3 on the next page.
Getting Started02
1
1
3
2
HDMI
1
3
2
SCART
7
Getting Started 02
2Connecting up your digital box to your DVD player
Connecting via DVD player
Cables 1, 2 and 3.1. First follow the set up instructions as shown in
panel 1 of this section for HDMI,
Cable 4.2. Connect a SCART cable (not included) between your digital
box AUX SCART socket and the SCART socket on the DVD player.
DON’T FORGET! Connecting via SCART cable will not allow you
to view high definition picture quality.
DON’T FORGET! DVD content played through the digital box via
the SCART cable will be standard definition picture quality. If you
have a DVD-R player, any recorded content through the digital box
will be in standard definition.
1
2
3
4
DVD player
8
Connecting Power
Before connecting power to the digital box, check that the mains voltage
on the rating plate is the same as the voltage in your area. Plug the
power connector on the power supply into the DC IN connector on the
rear panel of the digital box. Plug the power supply into the wall socket
and switch on the mains power.
The power indicator LED on the digital box front panel will light up
green and the 4-digit display will display ‘ boot ‘ while it
is initialising. After, it will display the currently selected
channel number. When the POWER ON/OFF button is
pressed once the digital box goes to standby mode and the
power indicator LED changes to red. The time of day now
appears on the 4-digit display. Press the button again to
return to the active state. The unit is now ready for use.
4
Connecting up your digital box to your router
You will need an internet broadband router.
If you are not ready to complete this stage of the setup at this time,
you can skip this step and continue with setting up your digital box.
Connecting to the internet enables you to use smart services.
Cables 1, 2 and 3.1. First follow the set up instructions as shown in
panel 1 of this section for HDMI or SCART as required.
Cable 4.2. Connect an Ethernet cable (not included) to the NETWORK
connection on your digital box. Connect the other end of the Ethernet
cable to a free Ethernet socket on the back of your router.
3
1
3
4
2
Router
Getting Started
02
9
Fitting the batteries in the remote
Alkaline batteries are recommended for best performance.
Referring to the diagram below, unclip the battery compartment lid and
lift it away. Fit the two type AAA batteries supplied into the battery
compartment, observing the polarity shown below and embossed in the
base of the compartment.
Battery Disposal
Dispose of used batteries with regard to the recycling regulations in your
area.
DO NOT short circuit batteries or throw them into water, general rubbish
or in a fire.
Weak batteries can leak and damage the remote control. Replace them in
good time!
5
CLIP
BATTERIES
TYPE AAA
BATTERY
COMPARTMENT
BATTERY
COMPARTMENT
LID
Getting Started 02
10
Installation
Easy install (recommended)
When you first connect your digital box to a TV and turn it on, the ‘First
Time Installation’ screen will be displayed.
Easy install is the recommended option as it will attempt to find the
optimal settings for your TV and digital box.
‘First Time Installation’ will scan for TV and Radio channels and store
the results on the digital box. This process will take approximately 8-10
minutes to complete.
You can press the BACK Button at any time to return to the previous
step.
If multiple TV regions are available in your area, you will be prompted to
choose a region during the installation process.
Easy install may not always provide the optimum setting level for your TV.
If you know the screen size (aspect ratio) of your display you can set this
manually by following the Advanced install set-up process.
The Installer screen will be displayed. If ‘Easy’ is not already selected,1.
press the Button on your remote control to select it.
2. Press the OK Button to begin.
The ‘Easy Setup’ screen will be displayed with the ‘TV Setup’ function3.
selected. How your digital box is connected to your TV will also be
shown on screen (HDMI or SCART).
Getting Started02
6
DON’T FORGET! Remember to make a note of your PIN for later
use. The default PIN setting is 0000, if you choose to skip the ‘Set
PIN’ stage, this will remain the Parental PIN number until changed.
If you change your PIN, write it here: .......................
