Goodmans IPHONE MICRO1468I Manuale utente

MICRO1468I CD Micro System for iPhone/iPod

Instruction Manual

IMPORTANT!

Pleasereadallinstructionscarefully

before use and keep for future reference.

MICRO1468I.book Page 1

Introduction

Thank you for choosing this Goodmans Micro System.

Not only does it play CD’s and receive radio stations, but you can also

listen to your favourite tracks on your iPhone/iPod whilst charging it.

It’s really easy to use; you can save your favourite radio stations to memory and program your CD

tracks in an order to suit you. You can also fully operate your iPhone/iPod from the remote control.

IMPORTANT!

Use of any electrical equipment should be undertaken with care. Please read the

safety section on page 17 before using your Micro System. This appliance is for household use

only.

An audio system that allows docking

of an iPhone / iPod and which fully

supports the iPhone / iPod menu system.

MICRO1468I.book Page 2

What’s in the box

1 x Goodmans MICRO1468I unit

2 x External speakers

1 x Remote control (not shown)

6 x iPod dock adaptors (not shown)

1 x Mains adaptor - 10V DC (not shown)

(CD and iPod not included)

Contents

Getting started

Using the radio

Using the iPhone/iPod dock

Using the CD

Using the clock and timer

Other functions

Troubleshooting

Specifications

MICRO1468I.book Page 3

Your Micro System

Front view

1 STANDBY button 8 PLAY / PAUSE button

2 FUNCTION button 9 OPEN / CLOSE button

3 C.ADJ / MEMORY button 10 iPhone/iPod compartment

4 TUNER / SEARCH - Button 11 Speaker unit

5 Volume Control 12 CD door

6 TUNER / SEARCH + Button 13 IR sensor

7 STOP Button 14 LCD display

MICRO1468I.book Page 4

11 1 2 3 4

12 13 14

5 6 7 8 9 10 11

Your Micro System

Top Panel

21 20 15161819 1722

Speaker output left 19 Subwoofer output

16 Speaker output right 20 AUX input left

17 Reset button 21 AUX input right

18 DC input 10V 22 FM antenna

MICRO1468I.book Page 5

Your Micro System

1 STOP button 11 ENTER / FOLDER + button

2 STANDBY button 12 MEMORY button

3 OPEN / CLOSE button 13 M-DOWN / REPEAT button

4 FILE +10 / IPOD UP button 14 M-UP / RANDOM button

5 PLAY / PAUSE button 15 PRESET EQ button

6 MENU / INFO button 16 TIMER / C.ADJ button

7 SKIP / TUNE - Button 17 SLEEP button

8 SKIP / TUNE + Button 18 VOLUME - button

9 FILE -10 / IPOD DOWN button 19 MUTE button

10 FUNCTION button 20 VOLUME + button

MICRO1468I.book Page 6

RemoteControl

Getting started

The remote control battery

To preserve the battery life prior to first use,

there is a small plastic tab inserted between the

battery and the terminal inside the remote

control. Please remove this tab before using the

remote control. To remove the tab, pull it in the

direction of the arrow in the illustration below.

If the operation of the remote control becomes

intermittent or unsatisfactory, replace the original

battery with a new 3-volt lithium battery.

DON’T FORGET!

When replacing the battery,

always ensure the same size and type is used.

Make sure that the battery polarity is

observed. Inserting the battery incorrectly

could result in battery leakage or damage to

the unit.

Connecting to power

Before switching on make sure that the voltage

of your electricity supply is the same as that

indicated on the rating plate. For your own safety

read the following instructions carefully before

attempting to connect this unit to the mains.

Mains (AC) operation

This unit is designed to operate on AC 100-240V

50/60Hz mains supply using the mains adaptor

supplied.

Connect the mains adaptor to the DC input

socket (18) on the rear of the unit

DON’T FORGET!

Use only the mains adaptor

supplied with this Micro System. Using

adaptors not designed for this unit, or that

have a different specification to the one

supplied, may cause damage to the unit.

MICRO1468I.book Page 7

Using the support stand

If the unit is to be operated on a desk or table,

extend the support stand (located on the

underside of the unit). If the unit is to be wall

mounted, return the support stand to the closed

position.

Using the radio

Basic operation

Press the

STANDBY

button on the main

unit or remote control to power on the unit.

Press the

FUNCTION

button on the unit or

on the remote control to select Tuner

mode.

Tune to the station you want by pressing

either of the

SKIP / TUNE

buttons.

To turn off the unit, press the

STANDBY

button.

Manual and automatic tuning

To manually tune in a station, briefly press

either of the

SKIP / TUNE

buttons.

To start automatic tuning, press and hold

either of the

SKIP / TUNE

buttons for

more than 2 seconds.

DON’T FORGET!

The unit will automatically

search for the first available station with a

strong signal.

Saving radio stations to memory

DON’T FORGET!

You need to use the remote

control to save radio stations to memory.

Tune in to the station you want by

pressing either of the

SKIP / TUNE

buttons on the remote control.

Press the

MEMORY

button on the remote

control, “MEMORY” will flash in the display

and a preset number “1” will also show on

the display.

Press the

M-UP

M-DOWN

buttons on

the remote control to select the preset

station number where you want to save

the station.

Press the

MEMORY

button again to store

the station into the chosen preset number.

DON’T FORGET!

Repeat the above steps to

save all of your other stations.

Selecting a saved station

Press the

M-UP

M-DOWN

buttons on

the remote control to choose the saved

station that you want to listen to.

Antenna

DON’T FORGET!

For optimum FM reception

there is a built-in FM antenna wire on the back

of the unit. Move the wire around to get the

best reception.

FM and FM Stereo reception

When the unit is tuned in to a stereo broadcast

with a good signal, "STEREO" will be shown in

the display.

If an FM station is received, but has interference,

it is recommended to switch to Mono mode using

the

ST/MO

button on the remote control.

MICRO1468I.book Page 8 Tues

You can save up to 20 FM radio stations to the

memory.

Using the iPhone/iPod Dock

Inserting and removing your iPhone/iPod

Press the Power / Standby Button.

Press the FUNCTION Button to select

iPhone/iPod mode.

Press the OPEN / CLOSE Button to open

the CD door.

Playback and charging your iPod

Select iPod mode using the

FUNCTION

button.

Insert your iPod into the dock and press

the

PLAY/PAUSE

button to start playback.

Press the

PLAY/PAUSE

button to pause

playback. Press this button again to

resume playback.

When your iPod is docked in the unit, the

internal battery will be charged.

Carefully push the lever to the right and then

back to the original position.

DON'T FORGET! The CD door will NOT close if

the lever is not returned to the original postion.

DON'T FORGET! Menu navigation will not

work on iPhone or iPod Touch when they

are in LOCK mode.

Using the iPhone/iPod menu system

Carefully insert your iPhone/iPod unit into the

dock.

Press the

button once on the

remote control to enter the iPod menu

system.

Press “ ”, and “ ” on the remote control

MICRO1468I.book Page 9

Select IPod mode using the FUNCTION button.

to navigate the various features of the iPod

menu system as you would when using the

iPod control buttons.

Carefully push the iPod dock lever to the

right then forward. The dock connector will

tilt upwards to enable the iPod/iPhone to

be easily connected.

Insert your iPod/iPhone securely into the

dock. You can also use the correct dock

adaptor supplied with your iPod

Press the OPEN/CLOSE button to close the CD

door.

Press the ENTER button on the remote control

to confirm your selection.

Using the CD

Handling CDs

To remove a disc from its storage case, press

down on the centre of the case and lift the disc

out, holding it carefully by the edges.

Fingerprints and dust should be carefully wiped

off the disc’s recorded surface with a soft cloth

before use.

DON’T FORGET!

Never use chemicals such

as record sprays, antistatic sprays, benzene,

or thinners to clean compact discs. These

chemicals can damage the disc’s surface.

Loading and unloading CD’s

Press the

STANDBY

Button to turn on the

unit.

Select CD mode.

Open the disc compartment by pressing

the

OPEN / CLOSE

button.

When the disc compartment has opened,

remove a disc from its case and place it

carefully onto the spindle with the label

side facing outwards.

DON’T FORGET!

Do not put anything except

a compact disc into the compartment. Other

objects may damage the unit.

Press the

OPEN / CLOSE

button to close

the disc compartment.

When the compartment is fully closed, the

disc will be read automatically.

DON’T FORGET!

Keep the disc compartment

closed when not in use to prevent dirt and dust

from entering the mechanism. Never place

more than one disc into the disc compartment

at any time.

Playing CD’s

Select CD mode with the Function button.

Press the

PLAY / PAUSE

button once to

begin playback of the CD from the first

track.

Press the

PLAY / PAUSE

button once to

pause playback of the CD; the elapsed

time will flash in the display.

To resume playback, press the

PLAY /

PAUSE

button again.

To stop playback, press the

STOP

button.

Selecting a different CD track

Press the

SKIP / TUNE

buttons to skip

forwards or backwards through the tracks

on the CD.

Press and hold the

SKIP/TUNE

buttons to

fast forwards or backwards through the

current track.

When the desired part of the track is

reached, release the button and playback

will resume.

MICRO1468I.book Page 10

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Goodmans Impianto stereo

Goodmans

Goodmans GMC 1034DAB Manuale utente

Goodmans

Goodmans MICRODAB16BT Manuale utente

Goodmans

Goodmans GMC1042MP3 Manuale utente

Goodmans

Goodmans 336723 Manuale utente

Goodmans

Goodmans 6160 Manuale utente

Goodmans

Goodmans MICRO 1930DVD Manuale utente

Goodmans

Goodmans 335105 Manuale utente

Goodmans

Goodmans MICRO1470DABI Manuale utente

Goodmans

Goodmans 4160AV Manuale utente

Goodmans

Goodmans MICRO1109IP Manuale utente

Goodmans

Goodmans 4214 Manuale utente

Goodmans

Goodmans MICRODAB16BT Manuale utente

Goodmans

Goodmans 4225MP3 Manuale utente

Goodmans

Goodmans Micro 1455 Manuale utente

Goodmans

Goodmans GSR85DAB Manuale utente

Goodmans

Goodmans MICRODAB18BT Manuale utente

Goodmans

Goodmans MICRO 1109 Manuale utente

Goodmans

Goodmans GMN10040MP3 Manuale utente

Goodmans

Goodmans GSPK30IP Manuale utente

Goodmans

Goodmans GDVX702 Manuale utente

Goodmans

Goodmans 329582 Manuale utente

Goodmans

Goodmans MICRO1467I Manuale utente

Goodmans

Goodmans MICRODAB10 Manuale utente

Goodmans

Goodmans MICRO1103 Manuale utente

Manuali Impianto stereo popolari di altre marche

LG CM3330B Manuale utente

Sony

Sony SS-CEP50 Manuale utente

Cetacea Sound

Cetacea Sound CVS-II Manuale utente

Aiwa

Aiwa XR-H66MD Manuale utente

Denon

Denon UCD-250 Manuale utente

Sanyo

Sanyo DC-MX41i Manuale utente

Sharp

Sharp CD-ES600V Manuale utente

Exibel

Exibel BDX600-UK Manuale utente

Sanyo

Sanyo DC-F320 Manuale utente

Philips

Philips FWM583X Manuale utente

Sharp

Sharp CD-C462 Manuale utente

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manuale utente

Aiwa

Aiwa XR-EM70 Manuale utente

Cyrus

Cyrus Lyric Manuale utente

Philips

Philips MCM159/98 Manuale utente

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manuale utente

RCA

RCA RS3965SB Manuale utente

Sharp

Sharp XL-UH240 Manuale utente
