6. Fully tighten the thumbscrew

using a Phillips-head

screwdriver to secure the

Camera’s position on the

mount.

5. Insert thumbscrew and hand

tighten.

4. Place Picatinny mount onto the

base of the Camera, ensuring

that screw holes are aligned.

1. Remove Camera from

packaging. Camera will come

equipped with a pre-installed

plastic mount.

3. Open Picatinny mounting kit

and take out the thumbscrew

and Picatinny mount.

2. Remove plastic mount from

the Camera by removing the

thumbscrew and mount from

the base of the Camera.

HD Action Camera

Installation Guide

D00133 Rev. A

INSTALLATION

To install the HD Action Camera on an LRAD’s Picatinny rail, perform the following steps.

NOTE: Prior to installation on LRAD, insert memory card and fully charged battery into Camera

genasys.com

TEL: 8586761112 | +1 855 GENASYS | SALESGENASYS.COM

16262 WEST BERNARDO DRIVE  SAN DIEGO, CA 92127 USA

Genasys products are available for purchase through multiple channels including: GSA Advantage, Federal and State

grants, FEMA RKB Standardized Equipment List (SEL), and others. More information: [email protected]

HD Action Camera

Installation Guide

Genasys - The Critical Communications Company

Genasys is a global provider of critical communications systems

and solutions to help keep people safe. Genasys systems are in

service in 72 countries and in more than 450 U.S. cities in diverse

applications, including public safety, emergency warning, mass

notification, critical event management, defense, law enforcement,

homeland security and many more.

For more information, visit genasys.com.

D00133 Rev. A

INSTALLATION

7. Loosen mounting screw and

extend the mount. This will

allow the mount to fit around

the Picatinny rail.

8. Place mounted Camera onto

the Picatinny rail and hand

tighten the mounting screw.

9. Fully tighten the mounting screw

using a flat-head screwdriver

to secure the mount to the

Picatinny rail.

For instructions on charging and

accessing the battery, recording

video, and more, consult the user

manual.

User manual can be found online

at: https://gopro.com/help/

productmanuals
