Gorenje WA744 Manuale tecnico

DETAILED

INSTRUCTIONS

FOR USE OF WASHING

MACHINE

www.gorenje.com

679870en.indd 1679870en.indd 1 12. 04. 2023 13:51:5112. 04. 2023 13:51:51

Life is complicated today. Let's make laundry care simple! Your

new WaveActive washing machine uses innovative technology

and latest achievements in laundry care to help you simplify

your daily household chores. WaveActive technology offers

the gentlest care for any garment, with minimum creasing.

At the same time, your washing machine will be easy on the

environment, owing to its highly efficient use of power, water and

detergent.

This washing machine is intended solely for household use.

Please do not use it for any laundry labelled as not suitable for

machine washing.

The following symbols are used throughout the manual and they have the following meanings:

Information, advice, tip, or recommendation

Warning – general danger

Warning – danger of electric shock

Warning – danger of hot surface

Warning – danger of fire

It is important that you carefully read the instructions.

679870en.indd 2679870en.indd 2 12. 04. 2023 13:52:0512. 04. 2023 13:52:05

679870

4 SAFETY PRECAUTIONS

10 WASHING MACHINE DESCRIPTION

11 Technical specifications

12 Control unit

14 INSTALLATION AND CONNECTION

14 Removing the blocking rods

15 Moving and transport after installation

16 Selecting the room

16 Adjusting the washing machine feet

17 Washing machine placement

19 Connecting to water supply

21 Aqua - stop

21 Total aqua - stop

22 Connecting and securing the water discharge hose

24 Connecting the appliance to the power mains

25 BEFORE USING THE APPLIANCE FOR THE FIRST TIME

26 WASHING PROCESS, STEP BY STEP (1–7)

26 Step 1: Heed the labels on the laundry

27 Step 2: Preparing the washing process

30 Step 3: Choosing the washing programme

34 Step 4: Choosing the settings

40 Step 5: Selecting additional functions

44 Step 6: Starting the washing programme

45 Step 7: Change of washing programme or manual (physical) cancellation

46 Step 8: End of the washing programme

47 INTERRUPTIONS AND CHANGING THE PROGRAMME

51 MAINTENANCE & CLEANING

51 Cleaning the dispenser tray

52 Cleaning the water supply hose, detergent dispenser housing, and rubber

door gasket

53 Cleaning the pump filter

54 Cleaning the washing machine exterior

55 TROUBLESHOOTING

55 What to do ...?

56 Troubleshooting and error table

60 Servicing

61 RECOMMENDATIONS FOR WASHING AND ECONOMIC USE YOUR

WASHING MACHINE

65 Stain removal tips

67 DISPOSAL

68 PROGRAM DURATION AND SPINNING RATE TABLE

STEPS OF

THE WASHING

PROCESS

WASHING

MACHINE

CLEANING AND

MAINTENANCE

INTRODUCTION

TROUBLE-

SHOOTING

PREPARING

THE WASHING

MACHINE

BEFORE FIRST

USE

MISCELLANE-

OUS

CONTENTS

679870en.indd 3679870en.indd 3 12. 04. 2023 13:52:1012. 04. 2023 13:52:10

679870

Carefully read the instructions for use before using the

washing machine.

Please, do not use the washing machine without reading

and understanding these instructions or use first.

These instructions for use of a washing machine are

supplied with different types or models of washing

machines. Therefore, they may include descriptions

of settings or equipment that are not available in your

washing machine.

Failure to observe the instructions for use or inappropriate

use of the washing machine may result in damage to the

laundry or the appliance, or injury to the user. Keep the

instruction manual handy, near the washing machine.

Instructions for use are available on our website at

www.gorenje.com.

Your washing machine is intended solely for household

use. If the washing machine is used for professional,

for-profit purpose or purpose exceeding normal use in a

household, or if the washing machine is used by a person

who is not a consumer, the warranty period shall be equal to

the shortest warranty period required by relevant legislation.

SAFETY PRECAUTIONS

679870en.indd 4679870en.indd 4 12. 04. 2023 13:52:1012. 04. 2023 13:52:10

679870

Follow the instructions for correct installation of the Gorenje

washing machine and connection to the water and power

mains (see chapter »INSTALLATION AND CONNECTION«).

Connection to water and power supply has to be executed

by an adequately trained technician or expert.

Any repair and maintenance pertaining to safety or

performance should be done by trained experts.

To avoid danger, a damaged power cord may only be

replaced by the manufacturer, a service technician, or an

authorized person.

Before connecting the washing machine to the power

mains, wait for at least 2 hours until it reaches room

temperature.

In case of a defect, only use approved spare parts by

authorized manufacturers.

In case of incorrect washing machine connection, incorrect

use, or servicing by an unauthorized person, the user shall

bear the cost of any damage as such damage shall not be

covered by warranty.

The washing machine may not be connected to the power

mains using an extension cord.

Do not connect the washing machine to power mains using

an external switching device such as a programme timer, or

connect it to power mains that is regularly switched on and

off by the power supply provider.

679870en.indd 5679870en.indd 5 12. 04. 2023 13:52:1012. 04. 2023 13:52:10

679870

Do not connect the washing machine to an electrical outlet

intended for an electric shaver or hair dryer.

Do not install the washing machine in a room where the

temperature can drop to below 5°C, as washing machine

parts may be damaged in case of water freezing.

Place the washing machine on a level and stable solid

(concrete) base.

If the washing machine is placed on an elevated stable base,

the washing machine has to be additionally secured against

tipping.

Before the first use of the washing machine, remove the

blocking rods, as switching on a blocked washing machine

can result in serious damage (see chapter »INSTALLATION

AND CONNECTION/Removing the blocking rods«). Warranty

shall be void in cases of such damage.

To connect the washing machine to water supply, make

sure to use the supplied water supply hose and gaskets.

Water pressure has to be between 0.05 and 0.8 MPa (0.5 – 8

bar).

Always use a new water supply hose to connect the washing

machine to water supply; do not reuse an old water supply

hose.

The end of the water discharge hose should reach into a

water drain line.

Before the start of the washing cycle, press the door on the

679870en.indd 6679870en.indd 6 12. 04. 2023 13:52:1012. 04. 2023 13:52:10

679870

indicated spot until it locks into place. The door cannot be

opened during washing machine operation.

We recommend removing any impurities from the

washing machine drum before the first wash using the

Cotton 90°C programme (see PROGRAMME TABLE).

After the washing cycle, close the water tap and pull out

the washing machine plug from the power socket.

Clean the pump filter whenever the symbol appears on the

display unit.

Only use the washing machine for washing laundry, as

described in the instruction manual. The machine is not

intended for dry cleaning.

Only use agents for machine washing and care of

laundry. We shall not be responsible for any damages or

discolouration of gaskets and plastic parts resulting from

incorrect use of bleaching or colouring agents.

When descaling, only use descaling agents with added

anti-corrosion protection. (Only use non-corrosive descaling

agents.) Follow the manufacturer's instructions. Finish the

descaling process with several rinse cycles or by running the

Steril tub (Self-cleaning programme) in order to remove any

residual acid (e.g. vinegar etc.).

Do not use detergents that contain solvents as this could

lead to release of poisonous gases, damage to the washing

machine, and risk of fire and explosion.

679870en.indd 7679870en.indd 7 12. 04. 2023 13:52:1012. 04. 2023 13:52:10

679870

No silver ions are released during the washing programme.

The washing machine is not intended for use by persons

(including children) with physical or mental impairments,

or persons with lacking experience and knowledge. These

persons should be instructed about the use of the washing

machine by a person responsible for their safety.

The warranty does not cover consumables, minor

deviations in colour, increased noise that results from

appliance age and which does not affect the functionality of

the appliance, and aesthetic defects on components, which

do not affect the functionality and safety of the appliance.

CHILD SAFETY

Before closing the washing machine door and running the

programme, make sure there is nothing except laundry in the

drum (e.g. if a child climbed into the washing machine drum

and closed the door from the inside).

Keep the detergent and conditioner out of reach of children.

Activate the child lock. See chapter »CHOOSING THE

SETTINGS/Child lock«.

Do not let children younger than three years come

near the appliance, unless they are under constant

supervision.

The washing machine is made in compliance with all

relevant safety standards.

This washing machine may be used by children aged 8

years and above and by persons with reduced physical,

679870en.indd 8679870en.indd 8 12. 04. 2023 13:52:1212. 04. 2023 13:52:12

679870

sensory or mental capabilities or lack of experience and

knowledge, but only if they are supervised during the use of

the washing machine, if they have been provided relevant

instructions regarding safe use of the washing machine, and

if they understand the hazards of inappropriate use. Make

sure children do not play with the appliance. Children may

not clean the washing machine or perform any maintenance

tasks without supervision.

DANGER OF HOT SURFACE

At higher washing temperatures, the door glass will heat up.

Be careful to avoid burns. Make sure children do not play

near the door glass.

WATER OVERFLOW PROTECTION (WITH WASHING

MACHINE SWITCHED ON)

If the water level in the appliance rises above normal level,

then the excess water level protection will be activated. It will

shut off the water supply and start pumping out the water.

The program is interrupted and an error is reported (see

TROUBLESHOOTING TABLE).

TRANSPORT/TRANSPORT AFTER INSTALLATION

If you intend to move the washing machine after it has

been installed, then it should be blocked by inserting at

least one blocking rod (see chapter »INSTALLATION AND

CONNECTION/Moving and transport«). Before inserting the

blocking rods, disconnect the washing machine from the

power mains!

679870en.indd 9679870en.indd 9 12. 04. 2023 13:52:1212. 04. 2023 13:52:12

679870

BACK

1 Water supply hose

2 Power cord

3 Water discharge hose

4 Adjustable feet

FRONT

1 Control unit

2 Start/pause button

3 Programme selector knob

4 On/off/reset button

5 Dispenser tray

6 Door

7 Rating plate

8 Pump filter

34 25

6 87

WASHING MACHINE DESCRIPTION

679870en.indd 10679870en.indd 10 12. 04. 2023 13:52:1212. 04. 2023 13:52:12

Indice

Altri manuali Gorenje Rondella

Gorenje

Gorenje WA63080 Guida utente

Gorenje

Gorenje WS53101 Manuale utente

Gorenje

Gorenje WEI74SDS Manuale utente

Gorenje

Gorenje W 72ZY2/R Manuale utente

Gorenje

Gorenje WE723 Manuale tecnico

Gorenje

Gorenje W8624H Manuale operativo e di manutenzione

Gorenje

Gorenje WS41121 Manuale utente

Gorenje

Gorenje WEI823 Manuale operativo e di manutenzione

Gorenje

Gorenje WS53125 Manuale utente

Gorenje

Gorenje WS41091 Manuale utente

Gorenje

Gorenje WS967LN Manuale utente

Gorenje

Gorenje PWM110WIT Manuale operativo e di manutenzione

Gorenje

Gorenje WA843S Manuale tecnico

Gorenje

Gorenje 7014D Manuale utente

Gorenje

Gorenje W8844H Manuale operativo e di manutenzione

Gorenje

Gorenje WP60S3 Manuale tecnico

Gorenje

Gorenje WF2N00260 Manuale utente

Gorenje

Gorenje WT 51062 Manuale operativo originale

Gorenje

Gorenje WT62113 Manuale utente

Gorenje

Gorenje W9865E Manuale operativo e di manutenzione

Gorenje

Gorenje WA614SYW Manuale utente

Gorenje

Gorenje Simplicity WA74SY2W Manuale utente

Gorenje

Gorenje W8543LR Manuale tecnico

Gorenje

Gorenje WS43140 Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
