GXP2135 Enterprise IP Phone
Quick Installation Guide
Content
English...............................................................................1
简体中文..........................................................................7
Español............................................................................13
Français...........................................................................19
Deutsch............................................................................25
Italiano.............................................................................31
Русскй.............................................................................37
Português....................................................................... 43
Polski............................................................................. 49
1 2
The GXP2135 is not pre-congured to support or
carry emergency calls to any type of hospital, law
enorcement agency, medical care unit (“Emergency
Service(s)”) or any other kind oEmergency Service.
You must make additional arrangements to access
Emergency Services. It is Your responsibility to pur-
chase SIP-compliant Internet telephone service, prop-
erly congure the GXP2135 to use that service, and
periodically test your conguration to conrm that it
works as You expect. IYou do not do so, it is Your re-
sponsibility to purchase traditional wireless or landline
telephone services to access Emergency Services.
GRANDSTREAM DOES NOT PROVIDE CON-
NECTIONS TO EMERGENCY SERVICES VIA THE
GXP2135. NEITHER GRANDSTREAM NOR ITS
OFFICERS, EMPLOYEES OR AFFILIATES MAY
BE HELD LIABLE FOR ANY CLAIM, DAMAGE, OR
LOSS, AND YOU HEREBY WAIVE ANY AND ALL
SUCH CLAIMS OR CAUSES OF ACTION ARISING
FROM OR RELATING TO YOUR INABILITY TO USE
THE GXP2135 TO CONTACT EMERGENCY SER-
VICES, AND YOUR FAILURE TO MAKE ADDITION-
AL ARRANGEMENTS TO ACCESS EMERGENCY
SERVICES IN ACCORDANCE WITH THE IMMEDI-
ATELY PRECEDING PARAGRAPH.
EN
GXP2135 is a next generation enterprise IP Phone eaturing 8 dual-color line keys
(can be digitally programmed as up to 32 provisionable BLF/ast-dial keys), 2.8
inch TFT color LCD, 4 programmable context-sensitive sot keys, dual Gigabit net-
work ports, integrated PoE and Bluetooth, 5-way conerence, and Electronic Hook
Switch(EHS). The GXP2135 delivers superior HD audio quality on the handset
and speakerphone, rich and leading edge telephony eatures, personalized in-
ormation and customizable application service, automated provisioning or easy
deployment, advanced security protection or privacy, and broad interoperability
with most 3rd party SIP devices and leading SIP/NGN/IMS platorms.
PACKAGE CONTENTS:
OVERVIEW:
WARNING: Please DO NOT power cycle the GXP2135 during system boot
up or rmware upgrade. You may corrupt rmware images and cause the unit to
malunction.
1 x Phone Main Case 1 x Handset
1 x Phone Cord1 x Ethernet Cable 1 x High Stand
1 x 12V Power adapter
1 x Quick Installation Guide/
1 x GPL license
1 x Wall Mount
PRECAUTIONS:
WARNING: Use only the power adapter included in the GXP2135 package.
Using an alternative non-qualied power adapter may possibly damage the unit.
12V
3 4
PHONE SETUP:
Installing the phone (Wall Mount):
1. Attach the wall mount spacers to the slot or wall mount spacers on the back
of the phone.
2. Attach the phone to the wall via the wall mount hole.
3. Pull out the tab rom the handset cradle (See gure below).
4. Rotate the tab and plug it back into the slot with the extension up to hold the
handset while the phone is mounted on the wall (See gure below).
Tab with extension up
Handset Rest
Tab with extension down
To setup the GXP2135, ollow the steps below:
1. Connect the handset and main phone case with the phone cord.
2. Connect the LAN port othe phone to the RJ-45 socket oa hub/switch or a
router (LAN side othe router) using the Ethernet cable.
3. Connect the 12V DC output plug to the power jack on the phone; plug the power
adapter into an electrical outlet.
4. The LCD will display provisioning or rmware upgrade inormation. Beore con-
tinuing, please wait or the date/time display to show up.
5. Using the phone embedded web server or keypad conguration menu, you can
urther congure the phone using either a static IP or DHCP.
For installing the phone on the table with the phone stand, attach the phone stand
to the bottom othe phone where there is a slot or the phone stand. (Upper hal,
bottom part).
Installing the phone (Phone Stand) :
CONNECTING THE PHONE:
Slots for the
wall mount and
phone stand
DC12PC LAN
HEADSET HANDSET
PC Port LAN Port Power Headset Port Handset Port
DC12PC LAN
HEADSET HANDSET
65
1. To access the MENU, press the round MENU button.
2. Navigate the menu by using the UP/DOWN and LEFT/RIGHT buttons.
3. Press the round MENU button to conrm a menu selection.
4. The phone automatically exits MENU mode when there is an incoming call, the
phone goes o-hook or when the MENU mode is let idle or 60 seconds.
Tips For Using the Keypad:
1. Ensure your phone is powered up and connected to the Internet.
2. Press the UP button to see the IP address.
3. Type the phone’s IP address in your PC browser. (See Figure in next page)
4. The deault administrator username and password are “admin”; the deault end-
user username is “user“ and the password is “123”.
1. Make sure the phone is idle.
2. Press the MENU button to access the keypad MENU to congure the phone.
3. Select MENU-> Phone-> SIP-> Account to congure settings or SIP Proxy,
Outbound Proxy, SIP User ID, SIP Auth ID and SIP Password.
4. Follow MENU options to congure the basic eatures othe phone. For ex-
ample: the IP address iusing a static IP. For details, please check GXP2135
User Manual.
5. Please contact your ITSP or additional settings that may be necessary to con-
gure the phone.
Confgure the GXP2135 using the Keypad:
PHONE CONFIGURATION:
Confgure the GXP2135 using a Web Browser:
Send
Volume
Speaker
Line keys
Soft keys
Standard keypad
Menu/OK key
Navigation keys
Message Waiting
Indicator
Message
Transfer
Conerence
Hold
Headset
Mute
Note: For the detailed user manual, please download rom:
