INSTRUCTION MANUAL
999 9579.4 IM 1051 REV 2 3/98
© 1998 Greenlee Textron
Read and understand this
material
before operating or
servicing this
equipment. Failure to understand how
to safely operate this tool could result in an accident
causing serious injury or death.
5700
PHASE SEQUENCE
INDICATOR
Phase Sequence Indicator
2Greenlee Textron / Subsidiary of Textron Inc.
SAVE THESE INSTRUCTIONS
Additional copies of this manual are available upon
request at no charge.
The symbol above is used to call your attention
to instructions concerning your personal safety.
Watch for this symbol. It points out important
safety precautions. It means “ATTENTION!
Become alert! Your personal safety is involved!”
Read the message that follows and be alert to the
possibility of personal injury or death.
SAFETY ALERT
SYMBOL
Immediate hazards which, if not avoided, WILL
result in severe personal injury or death.
Hazards or unsafe practices which, if not avoided,
COULD result in severe personal injury or death.
Hazards or unsafe practices which, if not avoided,
COULD result in minor personal injury or property
damage.
IMPORTANT SAFETY
INSTRUCTIONS
Phase Sequence Indicator
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
3
A person who has not read an does not
understand all operating instructions is
not qualified to operate this tool.
Failure to read and understand
safety
instructions may result in injury or death.
SAVE THESE INSTRUCTIONS
Additional copies of this manual are available
upon request at no charge.
IMPORTANT SAFETY
INSTRUCTIONS
Electric shock hazard. Contact with live
circuits can result in severe injury or
death.
Do not connect the leads to more than 700 VAC.
Electric shock can result.
Do not use the test instrument if it is wet
or damaged. Electric shock can result.
Phase Sequence Indicator
4Greenlee Textron / Subsidiary of Textron Inc.
• Do not expose this test instrument to high
temperature (more than 135°F or 57°C) or
high humidity (more than 80% relative
humidity). Failure to observe this precaution
can result in damage to the instrument.
• Do not attempt to repair this test instrument.
It contains no user-serviceable parts.
• Remove the battery when storing the test
instrument for more than seven (7) days.
Battery leakage may damage the test
instrument.
Failure to observe these precautions can result
in injury and can damage the instrument.
Do not open the case while the test leads
are connected to the circuit or while the
test instrument is ON. Electric shock or
damage to the device can result.
Failure to observe these warnings can
result in severe injury or death.
SAVE THESE INSTRUCTIONS
Additional copies of this manual are available
upon request at no charge.
IMPORTANT SAFETY
INSTRUCTIONS
Phase Sequence Indicator
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
5
Description
The 5700 Phase Sequence Indicator will indicate the
presence and phase sequence of 3-phase power, to
ensure correct wiring.
Purpose
This instruction manual is intended to familiarize
operators with the safe operation of the Greenlee
5700 Phase Sequence Indicator.
Specifications
Application: ...................................... 3-Phase Circuits
Phase Indication: .................................. 100V – 700V
Test Current: ..............................8 mA on each phase
Phase Sequence:......................................70V – 700V
Frequency Range: ................................40 Hz – 60 Hz
Phase Sequence Indicator
6Greenlee Textron / Subsidiary of Textron Inc.
Features
1. Phase Indicator LED’s: Indicate the presence of
each phase of power.
2. CORRECT LED: Indicates correct 3-phase wiring
3. INCORRECT LED: Indicates incorrect 3-phase
wiring
2
1
3
Phase Sequence Indicator
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
7
2. Connect the leads to the 3-phase circuit. Apply
power.
3. All three Phase Indicator LED’s should illuminate.
Note: If all three of the Phase Indicator LED’s do
not illuminate, shut off and lock out the
power. Have the wiring corrected by a
qualified electrician.
Note: One of the Phase Sequence LED’s should be
lit. If the CORRECT LED is lit, the phases
have been correctly identified. If the
INCORRECT LED is lit, disconnect and lock
out power. Switch any two leads, apply
power and retest.
4.
Disconnect power to the circuit. Disconnect the test
instrument from the circuit. Apply power to the
circuit.
Do not connect the phase sequence leads to
more than 700 VAC. Electric shock can result.
Operation
1. Disconnect and lock out power.
Do not attempt to repair this test instrument.
It contains no user-serviceable parts.
Maintenance
Keep the test instrument clean and dry. Replace
leads that are worn or damaged.
Lifetime Limited Warranty
Greenlee warrants to the original purchaser of these
goods for use that these products will be free from
defects in workmanship and material for their useful life,
excepting normal wear and abuse. This warranty is
subject to the same terms and conditions contained in
Greenlee’s standard one year limited warranty.
For all Test Instrument repairs, ship units Freight
Prepaid to:
Greenlee Textron at 4411 Boeing Drive, Rockford, IL
61109-2932 USA.
Mark all packages: Attention TEST INSTRUMENT
REPAIR. For items not covered under warranty (such as
dropped, abused, etc.), repair cost quote available upon
request.
Note: Prior to returning any test instrument, please
check replaceable batteries or make sure the
battery is at full charge.
Greenlee Textron
Subsidiary of Textron Inc.
4455 Boeing Drive Rockford, IL 61109-2988 USA
Customer Service (International): 815/397-7070
Fax: 815/397-1391
Customer Service (North America): 800/435-0786
Fax: 800/451-2632, 815/397-1865
Canada Fax: 800/524-2853
Printed in the U.S.A.
MANUAL DE INSTRUCCIONES
999 9579.4 IM 1051 REV 2 3/98
© 1998 Greenlee Textron
5700
INDICADOR DE
SECUENCIA DE FASES
Lea y entienda este documento antes
de manejar o dar servicio a este equipo.
Utilizarlo sin comprender cómo
manejarlo de manera segura podría
ocasionar un accidente, y como
resultado de éste, graves lesiones o incluso la muerte.
Indicador de secuencia de fases
10 Greenlee Textron / Filial de Textron Inc.
GUARDE ESTAS INSTRUCCIONES
Puede solicitar copias adicionales de este manual
de manera gratuita, previa solicitud.
Este símbolo se utiliza para llamar su atención hacia
las instrucciones sobre seguridad personal. Ponga
atención cuando lo vea ya que le indica importantes
precauciones que debe tomar para su propia
seguridad. Significa: “¡ATENCIÓN! ¡Póngase alerta
o podría atentar contra su propia seguridad!” Lea
el mensaje que aparece enseguida y esté consciente
de que puede sufrir lesiones o incluso la muerte.
SÍMBOLO DE
ALERTA SOBRE
SEGURIDAD
Peligro inmediato que, de no evitarse, OCASIONARÁ
graves lesiones personales o la muerte.
Peligro o prácticas peligrosas que, de no evitarse,
PODRÍAN ocasionar lesiones de menor gravedad o
daño a la propiedad.
IMPORTANTES INSTRUCCIONES
SOBRE SEGURIDAD
Peligro o prácticas peligrosas que, de no evitarse,
PODRÍAN ocasionar graves lesiones personales o la
muerte.
