1. Operate the machine at a very low speed to prevent the
bit from slipping off the starting point. Increase the speed
as the drill bit bites into the material.
2. When drilling through holes, put a piece of wood behind
the workpiece to prevent ragged or splintered edges on
the back side of the hole.
METAL DRILLING
For maximum performance, use high speed steel bits for
metal or steel drilling.
1. Operate the machine at a very low speed to prevent the
bit from slipping off the starting point.
2. Hold consistent speed and pressure to avoid overheating
the bit. Applying too much pressure can: Overheat the
drill; Wear the bearings; Bend or burn bits; and Produce
off-center or irregular-shaped holes.
3. When drilling large holes in metal, start with a small bit,
then finish with a large bit. Also, lubricate the bit with oil
to improve drilling action and increase bit life.
5 MAINTENANCE
CAUTION
Do not let brake fluids, gasoline, petroleum-based materials
touch the plastic parts. Chemicals can cause damage to the
plastic, and make the plastic unserviceable.
CAUTION
Do not use strong solvents or detergents on the plastic
housing or components.
WARNING
Remove the battery pack from the machine before
maintenance.
5.1 REMOVE THE CHUCK
The chuck may be removed and replaced by a new one.
NOTE
Note: before remove the chuck, lock the switch trigger by
placing the direction of rotation selector in center position
and remove the battery pack.
• Lossen the chuck jaws securely and insert a cross
screwdriver into the chuck of the drill to remove the
screw in a clockwise direction.
• The chuck body can now be unscrewed by hand in a
counterclockwise direction.
5.2 RETIGHTEN A LOOSE CHUCK
• Aline the chuck hole to the drill spindle and tighten the
chuck in a clockwise direction until the chuck engages
completely with a continuous click. At this time, the
chuck jaw is closed.
• Use a dexterous strength to loosen the chuck jaw
counterclockwise. Aline the screw with the hole of
spindle and insert a screwdriver into the chuck to tighten
the crew counterclockwise.
6 CLEAN THE MACHINE
CAUTION
The machine must be dry. Humidity can cause risks of
electrical shocks.
• Clear the unwanted material out of the air vent with a
vacuum cleaner.
• Do not spray the air vent or put the air vent in solvents.
• Clean the housing and the plastic components with a
moist and soft cloth.
7 TECHNICAL DATA
Voltage 24 V
No load speed 0-380 / 0-1450 min-1
Chuck 13 mm Keyless
Clutch 18 Positions + Drill
Torque 35 Nm
Weight without battery 1.03 kg
Battery model G24B2 / G24B4 and other
BAG series
Charger model 2913907 and other CAG ser-
ies
Measured sound pressure
level
76.3 dB(A), KpA= 5 dB(A)
Measured sound power level 87.3 dB(A), KwA= 5 dB(A)
Vibration < 2.5 m/s2,K = 1.5 m/s2
The recommended ambient temperature range:
Item Temperature
Appliance storage tempera-
ture range
32°F (0°C) - 113°F (45°C)
Appliance operation temper-
ature range
32°F (0°C) - 113°F (45°C)
Battery charging temperature
range
39°F (4°C) - 104°F (40°C)
Charger operation tempera-
ture range
39°F (4°C) - 104°F (40°C)
Battery storage temperature
range
32°F (0°C) - 113°F (45°C)
Battery discharging tempera-
ture range
32°F (0°C) - 113°F (45°C)
