Grizzly G5049Z Manuale utente

COMBINATION SANDER

MODEL G5049Z

PARTS LIST

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

OCTOBER, 1997. PRINTED IN TAIWAN

DISCONTINUED MACHINE PARTS LIST DISCLAIMER

THESE PARTS REPRESENT THE LAST CONFIGURATION OF THE MACHINE BEFORE IT WAS DISCONTINUED. MACHINE CONFIGURATIONS MAY HAVE

CHANGED AS PRODUCT IMPROVEMENTS WERE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS LIST MAY NOT

EXACTLY DEPICT YOUR MACHINE. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES. PREVIOUS PARTS

LIST VERSIONS ARE NOT AVAILABLE ONLINE.

-2- G5049Z Combination Sander

G5049Z Combination Sander -3-

-4- G5049Z Combination Sander

G5049Z Combination Sander -5-

-6- G5049Z Combination Sander

G5049Z Combination Sander -7-

REF PART # DESCRIPTION REF PART # DESCRIPTION

36 P5049036 SCALE

37 P5049037 STOP BAR

38 P5049038 SPACER

39 P5049039 BRACE, SHORT

40 P5049040 BRACE, LONG

41 P5049041 STEEL BLOCK

42 P5049042 CENTER PIN

43 P5049043 SPECIAL SETSCREW

44 P5049044 HEX BOLT

45 P5049045 FLAT WASHER

46 P5049046 LOCK WASHER

47 P5049047 CAP SCREW

48 P5049048 CAP SCREW

49 P5049049 ROLL PIN

50 P5049050 ROLL PIN

51 P5049051 MOTOR CORD

52 P5049052 KEY

53 P5049053 SCREW

54 P5049054 ROLL PIN

55 P5049055 FLAT HEAD SCREW

56 P5049056 SCREW

57 P5049057 HEX BOLT

58 P5049058 DIRECTION ARROW

59 P5049059 WASHER

60 P5049060 KNOB

61 P5049061 GUARD

62 P5049062 V-BELT

63 P5049063 KNOB

64 P5049064 KNOB

65 P5049065 ON / OFF SWITCH

66 P5049066 POWER CORD

67 P5049067 GRAPHITE PAD

68 P5049068 CAP SCREW

69 P5049069 HEX BOLT

70 P5049070 HEX NUT

01 P5049001 MAIN BODY

02 P5049002 TRUNNION,LEFT

03 P5049003 TRUNNION,RIGHT

04 P5049004 DISC TABLE

05 P5049005 BRACKET HOUSING

06 P5049006 STOP BLOCK

07 P5049007 BELT TABLE

08 P5049008 CAST IRON DISC

09 P5049009 LOWER GUARD

10 P5049010 UPPER GUARD

11 P5049011 STAND, TOP

12 P5049012 MOUNTING BRACKET

13 P5049013 COVER, LOWER

14 P5049014 COVER

15 P5049015 COVER, UPPER

16 P5049016 BELT FRAME

17 P5049017 SPACER

18 P5049018 POINTER

19 P5049019 GIB

20 P5049020 KNOB

21 P5049021 WASHER

22 P5049022 MITER BODY

23 P5049023 SCREW

24 P5049024 POINTER

25 P5049025 MITER BODY

26 P5049026 12'' SANDING DISC

27 SEE CAT 6'' X 48'' SANDING BELT

28 P5049028 CARRIAGE BOLT

29 P5049029 WASHER

30 P5049030 HEX NUT

31 P5049031 FOOT

32 P5049032 BOLT

33 P5049033 LEG

34 P5049034 DRIVE SHAFT

35 P5049035 SCALE

-8- G5049Z Combination Sander

REF PART # DESCRIPTION

71 P5049071 WASHER

72 P5049072 STRAIN RELIEF

73 P5049073 DUST COVER

74 P5049074 SNAP RING

75 P5049075 BEARING

76 P5049076 SNAP RING

77 P5049077 SPACER

78 P5049078 DRIVE DRUM

79 P5049079 SETSCREW

80 P5049080 BEARING

81 P5049081 SNAP RING

82 P5049082 IDLER DRUM

83 P5049083 IDLER SHAFT

84 P5049084 SLIDING BAR

85 P5049085 ROCKER PLATE

86 P5049086 LOCK WASHER

87 P5049087 CAP SCREW

88 P5049088 FENDER WASHER

89 P5049089 HEX BOLT

90 P5049090 HEX BOLT

91 P5049091 WASHER

92 P5049092 ECCENTRIC

93 P5049093 SPACER

94 P5049094 ROCKER ARM

95 P5049095 HEX NUT

96 P5049096 LEVER, SHORT

97 P5049097 LEVER, LONG

98 P5049098 KNOB

99 P5049099 JAM NUT

100 P5049100 KNOB

101 P5049101 PULLEY

102 P5049102 BRACKET

103 P5049103 BEARING BLOCK

104 P5049104 JACK SHAFT

105 P5049105 DRIVE DISC

106 P5049106 TIRE

107 P5049107 BLOCK

REF PART # DESCRIPTION

108 P5049108 CAP SCREW

109 P5049109 SPRING

110 P5049110 LOCK WASHER

111 P5049111 MOTOR

112 P5049112 MOUNTING BLOCK

113 P5049113 ARM

114 P5049114 THREADED SHAFT

115 P5049115 STUD

116 P5049116 BRACKET

117 P5049117 HEX BOLT

118 P5049118 WHEEL

119 P5049119 HUB, LEFT

120 P5049120 HUB, RIGHT

121 P5049121 SPECIAL NUT

122 P5049122 MOTOR BRACKET

123 P5049123 SCALE

124 P5049124 RIVET

125 P5049125 KEY

126 P5049126 SNAP RING

127 P5049127 HEX BOLT

128 P5049128 LOCK WASHER

129 P5049129 CAP SCREW

130 P5049130 KNOB

131 P5049131 SETSCREW

132 P5049132 SETSCREW

133 P5049133 SCREW

134 P5049134 HEX NUT

135 P5049135 ALLEN WRENCH

136 P5049136 CAP SCREW

137 P5049137 ROUND THING

138 P5049138 WASHER

139 P5049139 JAM NUT

142 P5049142 CHART

143 P5049143 POINTER

144 P5049144 SETSCREW

145 P5049145 WASHER
