TILE SAW

MODEL H3118

PARTS LIST

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

PRINTED IN CHINA

ONLINE PARTS LIST DISCLAIMER

THESE PARTS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CONFIGURATION

CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS

LIST MAY NOT EXACTLY DEPICT YOUR MACHINE. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFER-

ENCES. PREVIOUS PARTS LIST VERSIONS ARE NOT AVAILABLE ONLINE.

-18- H3118 Tile Saw



































































  











































 











Parts Breakdown

H3118 Tile Saw -19-

REF PART # DESCRIPTION REF PART # DESCRIPTION

1 PS38M PHLP HD SCR M4-.7 X 10 30 PH3118030 RUBBER WASHER

2 PW05M FLAT WASHER 4MM 31 PW01M FLAT WASHER 8MM

3 PH3118003 LOWER BLADE COVER 32 PH3118032 CLAMP LEVER

4 PH3118004 LOWER GUARD PLATE 33 PRP02M ROLL PIN 3 X 16

5 PN31M HEX NUT M12-1.5 34 PLW02M LOCK WASHER 4MM

6 PH3118006 OUTER FLANGE 35 PH3118035 GROUND WIRE CONNECTION

7 PH3118007 BLADE 36 PTLW01M EXT TOOTH WASHER 4MM

8 PH3118008 INNER FLANGE 37 PH3118037 POWER CORD 110V, W/5-15 PLUG

9 PS09M PHLP HD SCR M5-.8 X 10 38 PH3118038 MOTOR 1HP 110V

10 PW02M FLAT WASHER 5MM 38-1 PH3118038-1 CAPACITOR COVER

11 PH3118011 HANDLE 38-2 PH3118038-2 CAPACITOR 20M 250V 1-1/2 X 2-5/8

12 PH3118012 RIVING KNIFE 38-3 PH3118038-3 FAN COVER

13 PFH19M FLAT HD SCR M4-.7 X 10 38-4 PH3118038-4 FAN

14 PH3118014 KNOB M5-.8 39 PH3118039 CORD STORAGE

15 PH3118015 BLADE GUARD 40 PHTEK11M TAP SCREW M3 X 8

16 PN06M HEX NUT M5-.8 41 PH3118041 STRAIN RELIEF

17 PH3118017 MITER GUARD 42 PN04M HEX NUT M4-.7

18 PH3118018 TABLE 43 PH3118043 FIXED CLAMP

19 PH3118019 REAR COVER 44 PS38M PHLP HD SCREW M4-.7 X 10

20 PS07M PHLP HD SCR M4-.7 X 8 45 PH3118045 SWITCH ASSEMBLY

21 PH3118021 CLAMP ROD 46 PH3118046 KNOB M6-1

22 PH3118022 MOVING CLAMP 47 PW03M FLAT WASHER 6MM

23 PH3118023 SQUARE SPACER 48 PB02M HEX BOLT M6-1 X 12

24 PH3118024 COMPRESSION SPRING 49 PH3118049 FRAME

25 PH3118025 FENCE 50 PH3118050 RUBBER FOOT

26 PB96M HEX BOLT M5-.8 X 10 51 PLN03M LOCK NUT M6-1

27 PLW01M LOCK WASHER 5MM 52 PH3118052 SPECIAL NUT M4-.7

28 PH3118028 LOCKING LEVER 53 PH3118053 WATER TRAY

29 PH3118029 CONNECTION PIN 54 PS40M PHLP HD SCR M5-.8 X 16

Parts List

-20- H3118 Tile Saw

101

102

103

104

105

Label Placement and List

Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine

MUST maintain the original location and readability of the labels on the machine. If any label is

removed or becomes unreadable, REPLACE that label before using the machine again. Contact

Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.

REF PART # DESCRIPTION REF PART # DESCRIPTION

101 PLABEL-14 ELECTRICITY LABEL 104 PH3118104 UNPLUG LABEL

102 PLABEL-11 SAFETY GLASSES 2" X 3 5/16" 105 PH3118105 MACHINE ID/WARNING

103 PH3118103 BLADE GUARD WARNING
