AC3 Pump Info
MaximumWorkingPressure:1740psi(120bar,12MPa)
Maximumoperangtemperature:122°F/50°C
*(Notethatoperangoverthemaximumtemperaturewilleffectlifeofthepump)*
Minimumoperangtemperature:‐40°F/‐40°C(withSAE80/90Oil),5°F/‐15°C(withgrade2grease).
IPRang:IP66
Voltage:12Vor24V
PowerRang:2A
FuseRang:2A
MaxLineLengthperInjector:50(15m)
ThisprintandtheideasandprinciplesrepresentedontheprintarethepropertyofGroeneveldLubricaonSoluons.Thisprintisnottobecopiedorreproduced(evenextracts)
withoutpriorwrienconsentofGroeneveld.Everycarehasbeentakentoensuretheaccuracyoftheinformaoncontainedinthispublicaonbutnoliabilitycanbeacceptedfor
anylossordamagewhetherdirect,indirectorconsequenalarisingoutoftheuseoftheinformaoncontainedherein.

INSTALLATION
OnlyinstalltheGroeneveldACSystemifyouaresuitablyqualified.
Readtheinstallaoninstruconsinfullbeforecommencing
installaon.IfindoubtcontactGroeneveldon+1(937)2764507
PERSONAL PROTECTIVE CLOTHING
Youmustwearappropriateprotecveequipmentwhenoperang
andservicingtheequipment,thisistoprotectyoufromserious
injury.
Thisequipmentincludesbutisnotlimitedto:
Protecveeyewear.
Respirators,protecveclothingandglovesasrecommendedby
theLubricantmanufacturer.
PLASTIC PART CLEANING SOLVENT HAZARD
Manysolventscandamageplascpartsandcausethemtofail,which
couldcauseseriousinjuryorpropertydamage.
Useonlycompablecleaningproducts.
ENVIRONMENT
EnsurethatallLubricantsareresponsiblydisposedofinaccordance
withthemanufacturersMSDSsheetsandlocalregulaons.
WARNING
AC3OperaonandMaintenanceII
Installaon Warnings
Please retain these safety and operaon instrucons for future reference.

EC Declaraon Of Conformity
IIIAC3OperaonandMaintenance
EC Declaraon of Conformity
InaccordancewithISO/IEC17050‐1:2010
WeGroeneveldUK
Of85aStModwenRd,ParkwayIndustrialEstate,
Plymouth,Devon,UnitedKingdom,PL68LH.
Iherebydeclarethat:
Equipment: AC3XXX/XMul‐LineLubricaonSystem
InaccordancewiththefollowingDirecve(s):
2004/108/EC TheElectromagnecCompabilityDirecve
2006/42/EC MachineryDirecve
UNECEReg.10.05 AutomoveElectromagnecCompabilityDirecve
2011/65/EC RestriconofCertainHazardousSubstances
Hasbeendesignedandmanufacturedtothefollowingspecificaons:
97/23/EC,BSENISO50498:2008
Iherebydeclarethattheequipmentnamedabovehasbeendesignedtocomplywith
therelevantseconsoftheabovereferencedspecificaons.Theunitcomplieswith
allessenalrequirementsoftheDirecves.
Signed:
Name: RichardButler Posion: DivisionalManagingDirector
Doneat: Plymouth,UK Date: 04/01/2016
DocumentRef:ISF336Issue4

Installaon
AC3OperaonandMaintenance
Pump Clearance Requirements
AC3 pump clearance:
1
Mounng Hole Dimensions
AC3 standard mounng posions:
Select a suitable mounting point for the pump on the chassis, preferably in a position where it is protected from
debris. Ensure adequate clearance for the looming, access to the override button and refilling clearance is made
(see images on the following page).
Do not mount the pump on to ancillary equipment, such as the battery housing or cover.
Using the pump mounting template, supplied with the pump, position and drill the bracket holes (mounting —
positions detailed as above). Use bolts, nuts and spring washers supplied to securely mount the pump in position.

AC3OperaonandMaintenance
Pumping Units
Installaon
Standard Pumping Units for AC3 Pumps.
Part No. ‘F’ No. Output/stoke Color Outlet Size
78033‐PL F800091 0.010cc Red
Ø4mmOD
PushType
78034‐PL F800092 0.015cc Green
78035‐PL F800093 0.025cc Yellow
78036‐PL F800094 0.040cc Blue
78037‐PL F800095 0.060cc Grey
78038‐PL F800096 0.100cc Black
34237‐402 F800108 N/ABlankingPlug
MaximumOutputpressure
fromeachPumpingUnit 1740PSI/120Bar
Output pressure
Making the Looms
ThislubricantdistribuonlinesshouldbemadeupofGroeneveldØ4mm,semi‐rigid,nylontubing.Itisrecommendedthatthe—
tubingispre‐filledwithgreasetosaveontherequirementtoprimethesystemonceinstalled.
Fromthepumpposionestablishthemostconvenientrouteforthelubricaonlines.Itmaybepreferredtogroupthelinesinto
loomsdependingonpumplocaonandquantyandposioningofthegreasepoints.Ifgroupingthelines,intolooms,allow‐
sufficientlengthforconnecontothebulkheadoutletconnectorsandthebearings,makinganallowanceformovementonthe
machinery.Inconjunconwiththe‘Installaon Record’sheet(seepage16),fitthenumberidenficaonsleevestothelinesatthe
pumpandbearingends.Theloomshouldbeprotectedalongitslengthwiththeconduit/spiralbinding/sleevingand/ortape(for
partnumberssee‘Accessories’ onpage13).
Installaon:
Workingfromthefurthestpointfromthepump,feedthelubricaonlinesthroughthemachinefollowingexisngmachineservices,
wherepossible.Ensurethatthelubricaonlinesareposionedtofitthebearingfings.Whereabearingisonamovingpart,‐
ensurethatthelineissufficienttoallowforfullmovement.Toavoidrubbingorfriconwithmovingparts,grommetsorprotecve
sleevingshouldbeused.Also,dependingontheseverityofmovement,compressionfingsmaybepreferredatthebearingpoints.
Connecng the lines:
Cuteachlubricaonlinetolengthensuringaclean,squarecutisachieved.Connecttothebearingusingpushfitorcompression
connectors.ENSURE TUBING IS PUSHED FIRMLY INTO CONNECTOR. TEST ASSEMBLY BY PULLING FIRMLY ON THE LINE AFTER
INSTALLATION.UsingtheSystemSpecificaonSheetconnecttheloomtocorrespondingnumberedpumpingunits.When‐
runningthetubingintothepumpingunits,togivetheloomstrengthandrigidity,thetubesshouldbeclippedtogethertoforman
arrangementwithanoffsetfromthepumpof50to60mm(2”‐2‐1/2”).Thestarngpointfortheloomcanbeasrequired.
Starngwiththeboomrowofoutletsandpumpingunit“1”,theloomshouldthenrunaroundthepump,thenontoconnect
withthenextrowofpumpingunitssothattheloomtakestheformofaspiral,andsoonunlallpumpingunitsareconnected.
Tubesshouldbekepttogetherwithe‐clipsatintervalsofevery6pumpingunits.Theloom,orlooms,canthenberoutedonto
thechassisasrequired.
Note:Alldamagedpipeworkshouldbereplacedusinggenuinespareparts,failuretodosocancausesystemmalfunconsand
safetyissues.
2

AC3OperaonandMaintenance
Installaon
Wiring Informaon
InstallaonoftheACrangeofpumpsshouldideallyincorporatedirectconneconstothevehicleignionsystem.
Thisprovidesautomaclubricaonwhenevertheignionisswitchedon.
Amemory,builtintothepumpsprintedcircuitboard,removesthepossibilityofover‐lubricaononashorttrip/
mul‐dropoperaon.
2AFuse
REDToBaery+
ViaIgnion
Chassisground
Chassis
ground
ExisngVehicle
electricalcircuit(s)
3
AC3 Electrical Schemac

AC3OperaonandMaintenance
Operaon
PCB Adjustments
4
Rotaryswitchset
toposion‘0’.
24VPCB(83344‐107):
Rotary
Switch Posi-
on
Seng *(Pump runs for 1 minute 8
seconds aer delay period has
elapsed).
0* ConnuousOperaonat1.8rpm
1* ConnuousOperaonat0.9rpm
2* 3minutesdelay
3* 7minutesdelay
4* 11minutesdelay
5* 15minutesdelay
6* 19minutesdelay
7* 24minutesdelay
8* 30minutesdelay
9* 36minutesdelay
PumpCyclemesandprogrammingtable:
TheACrangeofpumpsarefactorysetto—
connuousoperaonat1.8rpm(seng0onthe
PCB),unlessotherwisespecified.However,ifthe
sengneedstoadjusteditcanbeeasilychanged
followingtheprocedurebelow:
ToaccesstheinternalPCBandadjusttherun
sengs,viatherotaryswitch.
1)Disconnectpowertothepump.
2)Removeblankingplugfrommotorhousingusing
an8mm(or5/16”)HexKey(seeFig.1and2).
MakesuretoretainO‐ringontheblankingblank.
3)AccessPCBandadjustrotaryswitchasrequired
usinga3/32”(2.4mm)flatheadscrewdriver(See
Fig.3andsee24VPCB(83344‐107)imagebelow
forrotaryswitchlocaon).
4)Re‐assemble,ensuringtheO‐ringiscorrectly
fiedontheblankingplug.Torqueto5.0Nm
(3.7lbf.).
5)Reconnectpowertothepump.
Fig.2
Fig.3
Fig.1

Fig.1A
AC3OperaonandMaintenance
Operaon
5
System Operaon and Tesng
Thesystemhasbeendesignedtobemaintenancefree,buttesngthesystemisalwaysrecommendedto
diagnoseanyfaultsortocheckthegeneralworkingcondionofthesystem.
Thelubricaonprocessstartsaereithertheignionisswitchedon(ifsettoconnuousrunmodeandthepump
isonlypoweredwhentheignionison)oraerthealloeddelayme(ofthealreadyprogrammedpump)has
elapsed.Thepumpwillrunfor1minuteand8seconds(equivalenttoonefullcamrevoluon)anddelayforthe‐
alloedmeasprogrammed.
Ifthepowerdropsoutatanymetothepumpthedelaycounterwillbestoppedandwillretainitsvalue,thus
rememberingitsposionwithinthedelaycycle.Thesystemwillthenconnuefromthatpointwhenthepower/
runsignalresumes.
Anindicaonlampislocatedonthemanualoverridebuon,onthebaseofthepump(seebelowimages).The
indicaonlightwillbelitwhenthereisaconnuouspowersupplytothecircuitandpump.Theindicaonlight
willflashslowlywhenthemotorisinoperaon.
Pressingthemanualoverridebuon(SeeFig.1B)willoperatethepumpfor1minuteand8seconds(orone‐
completecycle/onecompletecamrevoluon).
ThefollowinginspeconproceduresarerecommendedtohelpensureproperoperaonoftheACchassislubri‐
caonsystem.Oncethereservoirrefillperiodhasbeendeterminedmakecertainthattheintervalispartof
scheduledmaintenance.
A. InspectalllubricaonpointsforsignsofFRESHgrease,
B. Checkthecondionofallfingsandconnecons.Tightenorreplacelooseordamagedfings.
C. Checkalllubricaonlines;makecertainthattherearenotanybreaks.Checkforwearorchaffingthatmay
leadtoleakage.
D. ConfirmpumpoperaonbypressingManualOverridebuon(SeeFig.1B)andcheckingtheindicaonlight
flasheslocatedonthebuon.
If,duringthesechecks,anyissuesarefoundusetheLubricaon Troubleshoong Chart onpage14tohelp—
resolvethem.
Fig.1B

AC3OperaonandMaintenance
Operaon
6
Recommended Lubricants
TheACPumphasbeendevelopedspecificallytorunwithNLGIGrade000,00,0,1and2greaseandFG3,0fluid
grease.OilstoaminimumviscosityofSAE80arealsoacceptable.Donotuseheavytackifiedgreasesorgreases
containingbentone/bentonite,molybdenumand/orgraphite.
NOTE: Toensureproperoperaonofthelubricaonsystemonlyeverfillwithcleanlubricantthathasbeenina
sealedcontainerandcorrectlystored.Ifcleanlubricantisnotuseditcanresultinprematuresystemorbearing
failures.
Typical Refill Periods
TheAC3refillperiodsrangegreatly,dependingonthenumberofpumpingunits,theoutputquanes,andthe
programmeddelaymes.Duetotheaccuracyofthepumpingunitsoutputquanesandthereliabilityofpump
funconalityrefillperiodscanbesimplycalculatedtoensurethatthepumpandthebearingpointsdon’trundry.
Usethefollowingtocalculaterefillperiods:
Key:
N=NumberofPumpingUnits(P.U.)witha
parcularoutputvolume.
O1=0.010ccOutput(RedP.U.)
O2=0.015ccOutput(GreenP.U.)
O3=0.025ccOutput(YellowP.U.)
O4=0.040ccOutput(BlueP.U.)
O5=0.060ccOutput(GreyP.U.)
O6=0.100ccOutput(BlackP.U.)
A=TotalOutputAmountper1revoluon
E=NumberofrevoluonsunlEmpty
R1=2,800ccAC3Reservoir
M=1.13=Motorrunmeof1min8secs.
P=Programmeddelayme(3,7,11,15,19,
24,30or36minutes).
AC3
Pumps
Recommended Lubricants
OilsSAE80/90 000Fluid 00SemiFluid 0So 1Sff 2Hard
Minimum
operaon
Temp.
‐40°C/‐40°F ‐35°C/‐31°F ‐30°C/‐22°F ‐25°C/‐13°F ‐20°C/‐4°F ‐15°C/5°F
Maximum
operaon
Temp.
+50°C/122°Fforallpumps*
*(Motorisoperableupto60°C/140°F,butoperangatover50°C/122°Fshortensthelifeofthepump).
Calculaon:
Addupthetotaloutputfromallpumpingunits:
(NxO1)+(NxO2)+(NxO3)+(NxO4)+(NxO5)+(NxO6)=A
Dividethereservoircapacity(R1orR2)bythetotaloutput(A):
R1orR2=E
A
Mulplythenumberofrevsunlempty(E)bythepro‐
grammeddelayme(P),plustherunme(M):
Ex(P+M)=TotalRunmeinminutes(T)
T/60=TotalRunmeinhours(H)
H/24=TotalRunmeindays
Example:
AnAC3(R1)calibratedwith2RedP.U.(O1),4YellowP.U.(O3)
&6GreyP.U.(O5)programmedfora15minutedelayme:
(2x0.01)+(4x0.025)+(6x0.06)=0.48cc
2800cc/0.48cc=5833.33Revs
5833.33x(15+1.13)=87500minutesunlempty,
19531.25/60=1458.33hoursunlempty,
1458.33/24=60.76daysbetweenrefills.
*Notethatthiscalculaonisbasedonthepumphavingan
uninterruptedpowersupplyandbeinginconnuousoperaon*

AC3OperaonandMaintenance
Pump Refill Procedure
TheAC3Groeneveldmullinepumpsarefiedwithagreasenippleadaptorasstandard(see‘1’below)forfilling
withmosttypesofgreaseuptoandincludingNGLIGrade2.Usingthegreasenippleadaptorforgreasefillavoids
thepossibilityofairentrapmentandairpockets(cavitaon).
Bulkfilladaptorsarealsoavailableonspecialrequest.Thesecanbefiedasanalternavetothegreasenipplein
addiontothegreasenipple(see‘2’belowright).
IMPORTANT NOTES:
Ensurethatthegreasenippleorbulkfilladaptoriscleanbeforerefilling.Placethedustcapbackonthe
greasenippleorbulkfilladaptorwhenfinished.
DO NOT OVERFILL THE RESERVOIR. FillonlytotheMAXLevelLabel.
7
Operaon
AC3 System Output
(cc’s/grams per hour)
Timer Seng (Delay Cycle)
#0
1.8rpm
#1
0.9rpm
#2
3min
#3
7min
#4
11min
#5
15min
#6
19min
#7
24min
#8
30min
#9
36min
Red 0.53 0.3 0.15 0.07 0.05 0.04 0.03 0.024 0.019 0.016
Green 0.8 0.44 0.22 0.11 0.07 0.06 0.04 0.036 0.03 0.02
Yellow 1.33 0.74 0.36 0.18 0.12 0.09 0.07 0.06 0.05 0.04
Blue 2.12 1.18 0.58 0.3 0.2 0.15 0.12 0.1 0.08 0.06
Grey 3.19 1.77 0.87 0.44 0.3 0.22 0.18 0.14 0.12 0.1
Black 5.31 2.96 1.45 0.74 0.49 0.37 0.3 0.24 0.19 0.16
Injector
Indice
Altri manuali Groeneveld Pompa dell'acqua
Manuali Pompa dell'acqua popolari di altre marche

Sykes AmeriPumps
Sykes AmeriPumps GP100M Guida alla risoluzione dei problemi

DUROMAX
DUROMAX XP WX Series Manuale utente

BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 Manuale utente

Franklin Electric
Franklin Electric IPS Manuale utente

Xylem
Xylem e-1532 Series Manuale utente

Milton Roy
Milton Roy PRIMEROYAL Manuale utente
