Ground Zero RADIOACTIVE GZRW 8FL Manuale utente

RADIOACTIVE-SERIES

WOOFER

ANLEITUNG / OWNER’S MANUAL

GZRW 8FL

Ausstattungsmerkmale / Features

xHochfeste, extrem flache IMPP Membrane

xAluminium Staubschutz-Kalotte

x36 mm Kupfer Schwingspule

xExtra flach 55 mm

xBreitbandige Wiedergabe 30 – 600 Hz

xNutzbar als Subwoofer oder leistungsstarker

Kickwoofer in Tür oder Free-Air Anwendungen

oHigh-strength, extremely flat IMPP Cone

oAluminum dust cap

o36 mm / 1.42” Copper Voice Coil

oExtra flat 55 mm / 2.17"

oWide band performance 30 – 600 Hz

oUsable as subwoofer or powerful kick woofer

in door and free air applications

TECHNICAL SPECIFICATIONS

Cone (Dome) IMPP

Cone color Black

Surround High-roll foam

Dustcap Aluminum

Basket / Frame material Steel

Basket / Frame color Black

Terminal Zinc-plated soldering terminal

Magnet 1 x Neo [PP´[´

Voice coil PP´copper round wire

Voice coil former Kapton

RE 1.6 Ohm

SPL 85 dB

FS 45.3 Hz

QMS 12.224

QES 1.016

QTS 0.938

VAS 17.6L / 0.62 cu.ft

MMS 45.317 Gr

BL 4.5 N/A

RMS 1.055 kg/s

CMS 0.273 mm/N

LE 0.232 mH

Linear excursion +/- PP´

X max PP´

Frequency response 30 Hz ²600 Hz

Powerhandling 150 / 250 W

Outer diameter 204 mm / µ

Mounting diameter 178 mm / µ

Mounting depth 55 mm / µ

GZRW 8FL

GROUND ZERO GmbH ²Erlenweg 25 ²85658 Egmating ²Germany

www.ground-zero-audio.com

info@ground-zero-audio.com

GroundZeroAudioCom

A PPµ

B PPµ

C PPµ

D PP´

E PP´

DIMENSIONS

GZRW 8FL

GROUND ZERO GmbH ²Erlenweg 25 ²85658 Egmating ²Germany

www.ground-zero-audio.com

info@ground-zero-audio.com

GroundZeroAudioCom

In 70 liter geschlossen mit 30 cm Mikrofonabstand auf Achse gemessen /

Measured on axis in 70 liter ( 2.47 cu.ftZLWKFPµPLFURSKRQHGLVWDQFH

FREQUENCY RESPONSE

POWER RECOMMENDATION

ENCLOSURE RECOMMENDATION

GZRW 8FL

GROUND ZERO GmbH ²Erlenweg 25 ²85658 Egmating ²Germany

www.ground-zero-audio.com

info@ground-zero-audio.com

GroundZeroAudioCom

60 ²350 Liter netto / 2.12 ²12.36 cu.ft. net

Minimum Volume

(Schwarz / Black)

60 Liter netto / Min. 2.12 cu.ft. net

Türmontage / Door installation

Qtc / F3 1.05 / 39 Hz

Maximum Volume

(Blau / Blue)

350 Liter netto / Max. 12.36 cu.ft. net

Heckablagenmontage / Parcel shelf installation

Qtc / F3 0.96 / 37 Hz

INSTALLATION

GZRW 8FL

GROUND ZERO GmbH ²Erlenweg 25 ²85658 Egmating ²Germany

www.ground-zero-audio.com

info@ground-zero-audio.com

GroundZeroAudioCom

INSTALLATION RECOMMENDATION

Perfect for 3 Way setups with front and parcel shelf installation in:

Mercedes

Porsche

Volkswagen

Audi

BMW (Underseat)

MINI (Underseat)

Rolls Royce (Underseat)

DQGDOORWKHUFDUVZLWKFP´IURQWDQGUHDUVSHDNHUV

Die Gewährleistung entspricht der gesetzlichen Regelung. Eine Rücksendung kann nur nach vorheriger Absprache und in der

Originalverpackung erfolgen. Bitte unbedingt einen maschinell erstellten Kaufbeleg und eine Fehlerbeschreibung beilegen.

Von der Gewährleistung ausgeschlossen sind Defekte, die durch Überlastung, unsachgemäße Behandlung oder bei Teilnahme

an Wettbewerben entstanden sind. Wir behalten uns das Recht vor, zukünftig nötige Änderungen oder Verbesserungen an dem

Produkt vorzunehmen ohne den Kunden darüber zu informieren.

Limited warranty - defective products must be returned in original packaging - please add a copy of the original purchasing invoice showing

the purchasing date and a detailed description of the failure. Failure caused by overload, misuse or by using the product for competition

purpose are not covered by the warranty. We reserve the right to make needed change or improvement to the product without informing

customer about this in advance.

De Garantie bepalingen van alle door ground zero geleverde producten is volgens wettelijke

bepalingen geregeld, Een retourzending kan alleen na duidelijke afspraak en in de originele

verpakking plaatsvinden.SVP een aankoopbon en een duidelijke storingsomschrijving bijvoegen.Van garantie uitgesloten zijn defecten door

overbelasting, onkundig gebruik, of door deelname aan wedstrijden (SPL) ontstaan zijn. Wij behouden ons het recht om de nodige

veranderingen of verbeteringen aan het product door te voeren zonder de klant hierover te informeren.

La garantie est conforme aux droits légaux. Un retour du produit défectueux doit être dans son

emballage d'origine sur présentation du reçu ou de la facture indiquant la description du defaut.La présente Garantie n'est pas applicable

lorsque le produit a été endommagé en raison: Mauvaise alimentation, Trop de puissance (HP,Subwoofer) Accident, Installation ou

Utilisation non conforme aux normes Technique (Concours SPL etc). Nous nous réservons le droit d'entreprendre à l'avenir nécessairement

des modifications ou des

améliorations au produit sans informer le client.
