Gtec GT804M Manuale utente

GT804M

USER MANUAL

4 CHANNEL

DIGITAL VIDEO RECORDER

INSTRUCTION MANUAL

To obtain the best performance and ensure device function correctly, please read this

instruction manual carefully and completely.

INSTRUCTION MANUAL

To obtain the best performance and ensure device function correctly, please read this instruction manual

carefully and completely.

FCC Compliance

USER-INSTALLER CAUTION: YOUR AUTHORITY TO OPERATE THIS FCC VERIFIED EQUIPMENT

COULD BE VOIDED IF YOU MAKE CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY

THE PARTY RESPONSIBLE FOR COMPLIANCE TO PART 15 OF THE FCC RULES.

NOTE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A

CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE

DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN

THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES,

USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO

RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL

INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE

AT HIS OWN EXPENSE.

THIS CLASS A DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN

INTERFERENCE-CAUSING EQUIPMENT REGULATIONS.

WARNINGS, CAUTIONS & COPYRIGHT

WARINGS

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR

MISTURE.

DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.

CAUTION

Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert

the user to the presence of insinuated "dangerous voltage" within the products enclosure

that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral rhombus is intended to alert the user to the

presence of important operating and maintenance (servicing) instruction in the literature

accompanying the product.

USERS OF THE SYSTEM ARE RESPONSIBLE FOR CHECKING AND COMPLYING WITH ALL FEDERAL,

STATE, AND LOCAL LAWS AND STATUTES COIPCERNING THE MONITORING AND RECORDING OF

VIDEO AND AUDIO SIGNALS. ULTRAK SHALL NOT BE HELD RESPONSIBLE FOR THE USE OF THIS

SYSTEM IN VIOLATION OF CURRENT LAWS AND STATUTES.

THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED TO THEIR

RESPECTIVE COMPANIES.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

TABLE OF CONTENTS

1INTRODUCTION.......................................................................................................................4

1.1 FEATURE.......................................................................................................................4

1.2 SPECIFICATION...........................................................................................................4

2HARDWARE OVERVIEW.......................................................................................................7

2.1 FRONT PANEL.............................................................................................................7

2.2 BACK PANEL ...............................................................................................................9

2.3 EXTERNAL ALARM(reserved)...............................................................................10

2.4 IR REMOTE CONTROL(Optional)..........................................................................12

2.5 RS-485 CONTROLLER (reserved).........................................................................13

2.6 PTZ (PAN, TILT AND ZOOM) CAMERA & JOYSTICK CONTROLLER

(reserved)................................................................................................................................13

2.7 VGA OUTPUT(reserved)..........................................................................................15

2.8 NETWORK...................................................................................................................15

3SYSTEM SETUP.....................................................................................................................16

3.1 MENU SETUP INTERFACE(GUI)............................................................................16

3.2 LIVE VIEWING AND POP-UP MENU.....................................................................18

3.3 CAMERA SETUP......................................................................................................19

3.4 MOTION SETUP.......................................................................................................21

3.5 RECORD SETUP......................................................................................................21

3.6 ALARM SETUP.........................................................................................................22

3.7 HARD DISK SETUP.................................................................................................23

3.8 NETWORK SETUP...................................................................................................24

3.9 BACKUP SETUP......................................................................................................25

4DVR PLAYBACK....................................................................................................................27

4.1 TIME SEARCH............................................................................................................27

4.2 EVENT SEARCH ........................................................................................................28

5DVR & USB BACKUP PLAYBACK....................................................................................29

5.1 MAIN SCREEN SETTING.........................................................................................29

5.2 PLAYER USER INTERFACE...................................................................................30

6NETWORK VIEWING & PLAYBACK.................................................................................32

6.1 IP ADDRESS SETUP ON PC SITE..............................................................................32

6.2 OPTIONAL MICROSOFT INTERNET EXPLORER SETUP:...................................33

6.3 LOGIN................................................................................................................................34

6.4 LIVE VIEWING..................................................................................................................35

6.5 CONFIGURE.....................................................................................................................36

APPENDIX A: RECORDING TIME LAPSE ...............................................................................44

APPENDIX B: HDD/ USB DRIVE COMPATIBLE TABLE.......................................................46

APPENDIX C: HARD DISK INSTALLATION.............................................................................47

1 INTRODUCTION

1.1 FEATURE



MPEG-4 Video Compression.

Resolution: Real-time

720×480 ( NTSC )/ 720×576 ( PAL )

Recording

720x240 ( NTSC )/ 720x288 ( PAL )

Audio Backup / Audio Streaming.

Internal SATA Hard Disk Support.

Graphic User Interface ( GUI ).

Mouse/ IR Remote Controller Support.

USB Back Up/ Firmware Update

Compact Size, Easy Space Arrangement

Support Smart Phone and PDA.

1.2 SPECIFICATION

VIDEO

MODE Triplex

IMAGE SYSTEM NTSC PAL

LIVE-TIME RESOLUTION 720×480 720×576

LIVE-TIME DISPLAY RATE 4 × 30 Frame / Sec 4 × 25 Frame / Sec

SPLIT SCREEN 1, 4

VIDEO INPUT BNC × 4

VIDEO LOOPING No

VIDEO OUTPUT (BNC) BNC × 1

VIDEO OUTPUT (VGA) Yes (Option)

AUDIO

AUDIO INPUT RCA × 1

AUDIO OUTPUT RCA × 1

AUDIO BACKUP Yes

AUDIO STREAMING Yes

RECORDING

COMPRESSION TYPE MPEG-4

RECORDING RESOLUTION

720×240, 360x240 720×288, 360x288

RECORDING RATE (CIF)

360 x 240 up to 120 PPS

360 x 288 up to 100 PPS

RECORDING RATE (FIELD)

720 x 240 up to 30 PPS 720 x 288 up to 25 PPS

COMPRESSION RATE

Low ：2K Bytes

Medium ：4.2K Bytes

High ：6.2K Bytes

Bes

：

K Bytes

RECORDING MODE 12 Manual / Schedule

PLAYBACK & SEARCH

PLAYBACK SPEED

Fast Forward X 2 X 8 X 16 X32 X64

Fast Backward X32

field by field Playback

Pause

Slow Motion Playback X1/2 X1/4

TIME SEARCH Yes

EVENT SEARCH Yes

EVENT LIST 3000 records per H.D.D (Maximum)

OSD & CONTROL INTERFACE

TITLE 8 Characters

ON SCREEN DISPLAY & SETUP Time / Date / Setup Menu

GRAPHIC USER INTERFACE (GUI) Yes

DVR CONTROL PANEL Yes

MOUSE Yes (Option)

IR REMOTE CONTROLLER Yes (Option)

IE BROWSER Yes

PLAYER F4 Viewer

STORAGE & BACKUP DEVICE

INTERNAL HDD SUPPORT SATA HDD x 1

USB BACKUP Yes

NETWORK

ETHERNET Yes

ETHERNET COMPRESSION FORMAT

MPEG-4

DDNS Yes

E-MAIL & FTP Yes

NETWORK IP Static/ Dynamic/ PPPoE

MULTI-REMOTE CLIENT Yes ( 5 Clients at the same time available)

PDA/ CELL PHONE SUPPORT Yes

ALARM

MOTION DETECTION Yes

MOTION DETECTION AREA 30 x 24 grids

MOTION DETECTION SENSITIVITY 1-100

VIDEO LOSS DETECTION Yes

ALARM RECORDING Yes

BUZZER Yes

SETUP & OTHER FUNCTIONS

PASSWORD CONTROL

Two levels, one for system and the other for HDD format

KEY-LOCK Yes

MULTI-LANGUAGE Yes

FIRMWARE UPDATE USB Host

OTHERS

POWER INPUT DC 12V

POWER CONSUMPTION (W) 17W

DIMENSIONS (W x H x D) 218mm (W) × 44mm (H) × 202mm (D)

WEIGHT (kg) 1.4kg

OPERATION TEMPERATURE 0 - 45 ℃

ATTENTION：

：：

：

A. PLEASE format the hard disk before changing the recording resolution.

Different record resolution cannot be stored in the same hard disk.

Failing to do so may cause data lost or hard disk damage!!

B. DVR needs to STOP recording before processing USB backup function.

C. DVR needs to STOP recording before processing USB firmware update

function.

D. DVR system will reboot after changing recording quality setup.

2 HARDWARE OVERVIEW

2.1 FRONT PANEL

DVR OPERATION

NO.

ITEM DVR Function

1 POWER Power status LED.

2 REC Recording status LED.

3 PLAY Playback status LED.

4 H.D.D H.D.D. LED.

5 O IR Sensor for remote control.

6 USB connector.

7 ▲Move upward or increase the number.

8 ▼Move downward or decrease the number.



Press MENU to enter or exit MENU.

10 ◄Move leftward or decrease the number.

11 ►Move rightward or increase the number.

REC

Recording button.

Rew

Fast Backward x 32.

STOP

Press STOP to stop playback or recording.

Pause Pause & Field by Field Forward.

F.Fwd

Fast Forward ×2, ×8, ×16, x32, ×64.

PLAY

PLAY button & Get into Quick Time Search.

Channel One Full Screen & Number: One.

2 Channel Two Full Screen & Number: Two.

3 Channel Three Full Screen & Number: Three.

4 Channel Four Full Screen & Number: Four.

Quad

Quad screen: All cameras are displayed.

23 Confirmation and Backup.

FRONT PANEL KEY COMBINATION

Auto Swap：Press “Quad”, then press “>>” within 5 seconds.

Zoom Function：Press”Enter” while in the single channel mode.

HDD Information：Press ”Enter” while in the Quad mode.

2.2 BACK PANEL

NO.

ITEM FUNCTION

1 MOUSE Mouse interface.

2 CAMERA IN Camera 1 video input with BNC connector.

3 CAMERA IN Camera 2 video input with BNC connector.

4 CAMERA IN Camera 3 video input with BNC connector.

5 CAMERA IN Camera 4 video input with BNC connector.

6 MONITOR OUT Video output with monitor

7 Audio IN Audio input.

8 Audio OUT Audio output.

9 Ethernet RJ-45 Ethernet network interface.

10 VGA OUT

D-SUB Reserved.

RS-485 Reserved.

ALARM IN Reserved.

Relay Out Reserved.

12 Power DC 12V /3A.

2.3 EXTERNAL ALARM(reserved)

There are three types of alarms that the system can be configured, such as Motion

Detection Alarm, External Alarm, and Video Loss Alarm.

Motion Detection Alarm and External Alarm：

When Motion Detection or External Alarm was triggered, there are 5 possible

actions will be taken.

a. Recording speed changed from normal to alarm recording.

b. If Alarm Display Mode of Alarm Setup is ON, when the alarm is triggered, the

corresponding full screen alarm channel will be displayed automatically;

however, if the alarm is triggered and the setup is done within five seconds,

the corresponding full screen alarm channel won’t be displayed.

c. It’s optional to activate Relay.

d. Motion Detection and External Alarm both will be recorded in the event list.

In Motion Detection Record of Alarm Setup, the user can set up ON or OFF

to record the motion event or not.

e. When Motion Detection was triggered, the color of camera title will be

transformed into yellow. In addition, when External Alarm was triggered,

“ALARM” text will be displayed on the screen.

Indice

Altri manuali Gtec Registratore digitale

Gtec

Gtec GT804HD Manuale utente

Manuali Registratore digitale popolari di altre marche

FLIR

FLIR M3100E Series Manuale utente

VTRACKPRO

VTRACKPRO FPRO300 Manuale utente

Swann

Swann NVR-7085 models Manuale utente

XtendLan

XtendLan DVR-1670C Manuale utente

urmet domus

urmet domus 1093/004AHD Manuale utente

Holux

Holux M1 Manuale utente

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuale utente

Whistler

Whistler D16VRS Manuale utente

Defender Security

Defender Security 82-20235 Manuale utente

MISUMI

MISUMI MP-WF100M Manuale utente

Speco

Speco D8HU Manuale utente

UST

UST DDR-E04AA Istruzioni per l’uso

Consolidated

Consolidated Digital Video Recorder Manuale utente

Mace

Mace DVR0404RW Guida rapida

RCA

RCA RTD315W Manuale utente

FSM

FSM Colibri Grande PRO Manuale utente

Hauppauge

Hauppauge HD PVR 2 Manuale utente

Identivision

Identivision ICR-PH161i PIONEER Manuale utente
