GTRS S800 Manuale utente

GTRSIntelligentGuitar

Owner'sManual

IntelligentGuitar

www.gtrs.tech

LAYOUT------------------------------------------------------------------------01

QUICK TOUR-------------------------------------------------------------------02

INSTRUCTIONS-----------------------------------------------------------03-04

GWF-4WIRELESSFOOTSWITCH--------------------------------------------05

CONTENT

www.gtrs.tech

GTRScontrolknob

6.35mmguitarline/headphoneoutput

USBType-Cport

Batterycompartment（ Utilizeneedletoopen

thebatterycompartment）

Lithium-ionbattery(GLP-1)（ Pleaseensurethe

GTRSlogoisplacedasshownwhenplacing

battery）

CostomGu itars

LAYOUT

www.gtrs.tech

QUICKTOUR

02 www.gtrs.tech

Step1:ConnectyourGTRSguitartoampliﬁerorheadphones

Step2:RotatetheGTRScontrolknobclockwisetoturntheguitaron.The

knobLEDwillindicateon/oﬀstatus

Step3:PresstheGTRScontrolknobtoswitchbetweendiﬀerentpreset

tones

Step4:RotatetheGTRSknobtoadjusttheoutputvolumeleveltoyour

preference

INSTRUCTIONS

03 www.gtrs.tech

GTRSAPP

TheGTRSAppfunctionsastheeditorsoftwarefortheGTRSguitar.Users

caneasilyselecteﬀectsandcreatepresetsfortheGTRSsystem,

downloadandsharetonestothecloud,andupdatetheﬁrmwareof

theirGTRSguitar.Severaltoolsforpracticeareincludedintheappas

well.

1.GettheGTRSAPP

DownloadtheGTRSAppfromtheAppStore(iOS)orGooglePlay(Android).

2.Activation

OpentheBluetoothmenuofyoursmartphoneortabletandsearchfor“ GTRS”

toconnectyourguitarviaBluetooth.Afterconnecting,aQRcodescannerwill

displayintheapp.UsetheAPPtoscanthebarcodeonthelastpageofyour

owner'smanual,orthebarcodeonthepackage,toﬁnishactivationand

registration.TheserialnumberandwarrantyofyourGTRSguitarwill

automaticallyberegisteredaspartoftheactivationprocess.

*Notice:ThisprocedureisonlyforGTRSguitarswhichhavenotyetbeen

activated.Anactivatedguitarwillskipthisprocedure.Pleaseensurethe

GTRSguitarisonandyoursmartphonenetworkconnectionisstableduring

activation.

3.Guide

Clickthe“ ?”iconinthetoprightcorneroftheappscreentoaccessthequick

guide/manualoftheGTRSApp.

GTRScontrol

Presetswitch.YoucanassignthefunctionoftheGTRSknobwhilepressingit

shortly.

Presetswitch.YoucanassignseparatefunctionsandpresetsfromtheGTRSApp

bypressingandholdingdowntheknobforashorttime.

1.PresetMode

Presstoswitchbetweenfourdiﬀerenttonepresets.ThecoloroftheLEDwill

changeinorderofdarkblue,purple,orange,andskyblue.

其他功能

Lowbatteryalert

Toprovidethebestexperienceforusers,theGTRSknobwillblinkslowlywhen

thebatterylevelisgettinglow.PleasechargeyourGTRSbatteryassoonas

possibletomaintainthebatterylifeofyourunit.

Charging

Thelithium-ionbatteryintheGTRSsystemcanbechargedthroughtheType-C

USBportfromthepowersupply.Whilecharging,theGTRSknobLEDwillturnred

nomatterwhichmodeitisin.AgreenLEDindicatesafullcharge.

04 www.gtrs.tech

Tuner

WhentheAPPorwirelessfootswitchisconnected,pressandholdtheGTRSknob

toaccessthetuner.TheGTRSknobLEDwillturnyellow.Presstheknobagainto

exitthetuner.

Charging Chargingcomplete

2.GuitarSimulationMode

Presstoswitchtheguitarsimulationon.ThepurpleLEDindicatestheguitar

simulationisonwhileskyblueindicatestheguitarsimulationisturnedoﬀ.

3.TheguitarwillbegininPresetModebydefault.Youcanassigndefaults

through:GTRSAPP‒Settings‒Global-GTRScontrol.

INSTRUCTIONS

05 www.gtrs.tech

Wirelessfootswitch(purchasedseparately)

ThewirelessfootswitchcanbeusedwithGWF-4forbettercontrolofpresets

duringliveperformance.Pleaseseethewirelessfootswitchmanualformore

information.

Bluetooth

OpentheBluetoothmenuofyoursmartphoneortabletandsearchfor“ GTRS”

toconnectviaBluetooth.UserscanusetheBluetoothfunctiontoplayaudio

tracksfromamobiledevicemixedwiththeGTRSguitarsignalandsendthat

signalthroughthemainoutputoftheGTRSguitar.

LiveStream/DirectRecording

Toprovidethebestexperienceforusers,theGTRSknobwillblinkslowlywhen

thebatterylevelisgettinglow.PleasechargeyourGTRSbatteryassoonas

possibletomaintainthebatterylifeofyourunit.

TraditionalGuitarMode

IfGTRSisoﬀ,orifthebatterylifeislow,theoutputsignaloftheguitarwillswitch

totruebypassandfunctionasatraditionalguitarwould.Onlythevolumeknob,

toneknob,andpickupswitchcanaﬀectthetoneoftheguitar.Inthismode,the

guitarcannotsupportheadphoneoutput.

GWF-4WIRELESSFOOTSWITCH

www.gtrs.tech

FCC Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of

the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modifications to this device not explicitly approved

by manufacturer could void your authority to operate this equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including

interference that may cause undesired operation.

The device has been evaluated to meet general RF exposure requirement.

The device can be used in portable exposure condition without restriction.
