GUDIMALIGHT SANI UV-C Manuale utente
The present data is to be considered as informational documentation and might vary due to design advancement and future state-of-art from
the scientic community and/or new legislation.
The look and specications of the SANI UV-C might change due to design advancements, at any moment without notice. For more information get in touch at
[email protected] or visit the download page at www.gudimalight.eu
GUDIMA LIGHT Ltd Kuklensko shose 17 blvd.Plovdiv 4004/ Bulgaria tel.+359 885 224222/+359 876 651650
USER MANUAL
SANI UV-C
INTRODUCTION
Congratulations for your purchase of the new portable SANI UV-C sanitizer by GUDIMALIGHT. Your choice went for a high-quality device.
The instructions are an essential part to best the usage of this product with important safety instructions for handling and disposal. Before
beginning to use the sanitizer, it is important to gain familiarity with all the instructions for usage and safety. Use the sanitizer only accordingly
to the recommended instructions and for the intended purposes. When the SANI UV-C by GUDIMALIGHT is given to third parties, it must be
provided with the included documentation.
COMPLIANT USE
The battery powered SANI UV-C sanitizer is suitable for sanication surfaces of different nature, in the modality described in the present
document. Any other usage must be considered not conform to the intended purpose. The maker is not entitled of any responsibility for
damages caused by any use not conform to this document, wrong operation, wrong handling, device manumission or modication.
PART LIST
Reporting: Carry out immediately after the purchase of items that are part of the supply. Be aware that all objects are present and that they are
not defects.
• Portable battery powered SANI UV-C ( model UV-C 190520 450 / model UV-C 190520 700 )
• USB charging cable USB-A/Micro USB
• Instruction and Safety Manual
DATASHEET
Model code UV-C 190520 450 UV-C 1905 700
Dimensions 400x40mm 650x40 mm
Weight 324g 406g
LED Type UVC + UVA UVC + UVA
Power 6W 8W
Optimal Surface Distance from 10 to 30 mm
Lifetime 2,5h*
Charging System micro USB-B 5V
Temperature range for storage and use 0-50°C
Photobiological risk RG3
*duration assumed based on continuous use
1. Handler with included battery and charging port
2. Push button for activation
3. UV-C and UV-B LEDs
4. Micro-USB Charging port
5
3
4
1
2
USER MANUAL
SANI UV-C
The present data is to be considered as informational documentation and might vary due to design advancement and future state-of-art from
the scientic community and/or new legislation.
The look and specications of the SANI UV-C might change due to design advancements, at any moment without notice. For more information get in touch at
[email protected] or visit the download page at www.gudimalight.eu
GUDIMA LIGHT Ltd Kuklensko shose 17 blvd.Plovdiv 4004/ Bulgaria tel.+359 885 224222/+359 876 651650
! SAFETY INSTRUCTIONS !
• Before using the SANI UV-C, the operator must wear the personal protective equipment PPE accordingly
to the applicable law.
• DO NOT point the activated SANI UV-C against people or animals
• The operator must employ the SANI UV-C at least 1meter away from people or animals
• Besides the personal protective equipment PPE, for a safe use, all the prescriptions enlisted in the
present document must be duly noted and followed.
• Any operator appointed to use the SANI UV-C must read the present document.
• Maximum care and attention must be use during the operation of the SANI UV-C in order to avoid harmful
consequences to people, goods and the device itself.
• Operate the SANI UV-C device only for the indented purposed here described: surface sanication.
• DO NOT alter or damage the SANI UV-C device.
• Keep the SANI UV-C device away from children
! WARNING !
The SANI UV-C device emits high energy Ultraviolet radiation
that can cause harm to eyes and skin.
The safety instructions present in this document must be
followed rigorously.
Avoid direct exposition of the activated LED UV-C to
the eyes and skin. Keep it away from children.
Model: UV-C 190520 700
Model: UV-C 190520 450
40
400 mm.
150 250
18
40
150 500
650 mm.
18
The present data is to be considered as informational documentation and might vary due to design advancement and future state-of-art from
the scientic community and/or new legislation.
The look and specications of the SANI UV-C might change due to design advancements, at any moment without notice. For more information get in touch at
[email protected] or visit the download page at www.gudimalight.eu
GUDIMA LIGHT Ltd Kuklensko shose 17 blvd.Plovdiv 4004/ Bulgaria tel.+359 885 224222/+359 876 651650
USER MANUAL
SANI UV-C
! PRECAUTIONS FOR CLEANING, STORAGE AND DISPOSAL !
• Keep the SANI UV-C in a dry environment protected from impacts
• Keep the SANI UV-C in an environment between 0°C and +50°C
• DO NOT use ammable material in the proximity of the SANI UV-C
• Keep the SANI UV-C away from heat sources
• Do not touch the SANI UV-C with wet hands or wet gloves
• Clean the SANI UV-C only with a dry cloth
• For the SANI UV-C disposal, it must be handled as RAEE item, normed by D.LGS. 49/2014
OPERATING INSTRUCTIONS
1. Employ all the personal protective equipment PPE (gloves and safety glasses with UV-C protection) dictated by the
current legislation.
2. Make sure no people without personal protective equipment is within 1 meter form the SANI UV-C in operation.
3. Hold rmly the SANI UV-C by its grip and direct the UV LED towards the surface to be treated.
4. Activate the SANI UV-C with the Push Button for the duration of the operation.
5. Keep the SANI UV-C parallel to the treated surface at a distance between 10mm and 30mm.
6. Move the SANI UV-C along the surface at 10mm per second and repeat the procedure multiple times to achieve
the desired level of sanication.
7. To end the SANI UV-C operation release the push button .
10/30mm
1cm/1sec.
1cm/1sec.
USER MANUAL
SANI UV-C
The present data is to be considered as informational documentation and might vary due to design advancement and future state-of-art from
the scientic community and/or new legislation.
The look and specications of the SANI UV-C might change due to design advancements, at any moment without notice. For more information get in touch at
[email protected] or visit the download page at www.gudimalight.eu
GUDIMA LIGHT Ltd Kuklensko shose 17 blvd.Plovdiv 4004/ Bulgaria tel.+359 885 224222/+359 876 651650
BATTERY SYSTEM
Nominal discharge capacity 2,500mAh
Charge: 1.25A, 4.20V,CCCV 125mA cut-off,
Discharge: 0.2C, 2.5V discharge cut-off
Nominal voltage 3.6V
Standard charge CCCV, 1.25A, 4.20 ± 0.05 V, 125mA cut-off
Rapid charge CCCV, 4A, 4.20 ± 0.05 V, 100mA cut-off
Charging time Standard charge : 180min / 125mA cut-off
Rapid charge: 60min (at 25°C) / 100mA cut-off
Max. continuous discharge (Continuous) 20A(at 25°C), 60% at 250 cycle
Discharge cut-off voltage End of discharge 2.5V
Cell weight 45.0g max
Cell dimension Height : 64.85 ± 0.15mm
Diameter : 18.33 ± 0.07mm
Operating temperature (surface temperature) Charge : 0 to 50°C
(recommended recharge release < 45°C)
Discharge: -20 to 75°C
(recommended re-discharge release < 60°C)
Storage temperature (Recovery 90% after storage) 1.5 year -30~25°C(1*)
3 months -30~45°C(1*)1 month -30~60°C(1*)
RECHARGE INSTRUCTIONS
Hold the SANI UV-C portable battery sanitizer rmly.
1. Plug the provided USB cable to a USB 5V charger .
2. Plug the micro USB connector, from the provided USB cable, into the micro USB socket at the base of the grip of
the SANI UV-C.
3. Once the charging cycle is over (aprox. 3h) unplug the USB cable from the grip.
1
2
3
5V 1.25A
