H3C MSR Series Manuale utente

H3C MSR Series Routers

Terminal Access Command Reference(V7)

Hangzhou H3C Technologies Co., Ltd.

http://www.h3c.com

Software version: MSR-CMW710-R0007

Document version: 6W100-20140320

No part of this manual may be reproduced or transmitted in any form or by any means without prior

written consent of Hangzhou H3C Technologies Co., Ltd.

Trademarks

H3C, , H3CS, H3CIE, H3CNE, Aolynk, , H3Care, , IRF, NetPilot, Netflow,

SecEngine, SecPath, SecCenter, SecBlade, Comware, ITCMM and HUASAN are trademarks of

Hangzhou H3C Technologies Co., Ltd.

All other trademarks that may be mentioned in this manual are the property of their respective owners

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

Preface

The H3C MSR documentation set includes 15 command references, which describe the commands and

command syntax options available for the H3C MSR Series Routers.

The Terminal Access Command Reference(V7) describes the Terminal Access configuration commands.

This preface includes:

•Audience

•Conventions

•About the H3C MSR documentation set

•Obtaining documentation

•Technical support

•Documentation feedback

These configuration guides apply to the following models of the H3C MSR series routers:

Model

MSR 2600 •MSR 26-30

MSR 3600

•MSR 36-10

•MSR 36-20

•MSR 36-40

•MSR 36-60

•MSR3600-28

•MSR3600-51

MSR 5600

•MSR 56-60

•MSR 56-80

Audience

This documentation is intended for:

•Network planners

•Field technical support and servicing engineers

•Network administrators working with the routers

Conventions

This section describes the conventions used in this documentation set.

Command conventions

Convention Descri

tion

Boldface Bold text represents commands and keywords that you enter literally as shown.

Italic Italic text represents arguments that you replace with actual values.

[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.

{ x | y | ... }

Braces enclose a set of required syntax choices separated by vertical bars, from which

you select one.

[ x | y | ... ]

Square brackets enclose a set of optional syntax choices separated by vertical bars, from

which you select one or none.

{ x | y | ... } *

Asterisk marked braces enclose a set of required syntax choices separated by vertical

bars, from which you select at least one.

[ x | y | ... ] *

Asterisk marked square brackets enclose optional syntax choices separated by vertical

bars, from which you select one choice, multiple choices, or none.

&<1-n> The argument or keyword and argument combination before the ampersand (&) sign can

be entered 1 to n times.

# A line that starts with a pound (#) sign is comments.

Symbols

Convention Descri

tion

WARNING An alert that calls attention to important information that if not understood or followed can

result in personal injury.

CAUTION An alert that calls attention to important information that if not understood or followed can

result in data loss, data corruption, or damage to hardware or software.

IMPORTANT An alert that calls attention to essential information.

NOTE An alert that contains additional or supplementary information.

TIP An alert that provides helpful information.

Port numbering in examples

The port numbers in this document are for illustration only and might be unavailable on your device.

About the H3C MSR documentation set

The H3C MSR documentation set includes:

Cate

Documents

Pur

oses

Product description and

specifications Marketing brochures Describe product specifications and benefits.

Cate

Documents

Pur

oses

Hardware specifications

and installation

Installation guide Provides a complete guide to hardware installation

and hardware specifications.

MSR Series Routers

Interface Module Manual

Provide the hardware specifications of cards.

Software configuration

MSR Series Routers

Configuration guides(v7)

Describe software features and configuration

procedures.

MSR Series Routers

Command references(v7)

Provide a quick reference to all available

commands.

Operations and

maintenance Release notes

Provide information about the product release,

including the version history, hardware and software

compatibility matrix, version upgrade information,

technical support information, and software

upgrading.

Obtaining documentation

You can access the most up-to-date H3C product documentation on the World Wide Web

at http://www.h3c.com.

Click the links on the top navigation bar to obtain different categories of product documentation:

[Technical Support & Documents > Technical Documents]—Provides hardware installation, software

upgrading, and software feature configuration and maintenance documentation.

[Products & Solutions]—Provides information about products and technologies, as well as solutions.

[Technical Support & Documents > Software Download]—Provides the documentation released with the

software version.

Technical support

servic[email protected]

http://www.h3c.com

Documentation feedback

You can e-mail your comments about product documentation to info@h3c.com.

We appreciate your comments.

Contents

POS terminal access commands································································································································· 1

backup app·······························································································································································1

caller-number enable················································································································································1

description·································································································································································2

display posa connection terminal···························································································································3

display posa statistics app ······································································································································4

display posa statistics terminal································································································································5

display posa status app···········································································································································6

display posa status terminal ····································································································································7

hello enable ······························································································································································8

ip ················································································································································································9

mode······································································································································································· 10

posa app································································································································································ 11

posa bind app ······················································································································································· 12

posa bind terminal ················································································································································ 13

posa map ······························································································································································· 14

posa server enable················································································································································ 15

posa statistics caller-id ·········································································································································· 16

posa statistics caller-ip ·········································································································································· 17

posa terminal ························································································································································· 17

posa terminal description ····································································································································· 18

reset posa connection terminal ···························································································································· 19

reset posa statistics················································································································································ 19

snmp-agent trap enable posa ······························································································································ 20

source ip································································································································································· 21

source port ····························································································································································· 22

tcp keepalive·························································································································································· 22

tcp linking-time······················································································································································· 23

timer hello······························································································································································· 24

timer quiet ······························································································································································ 24

tpdu-change ··························································································································································· 25

Index ············································································································································································· 1

POS terminal access commands

backup app

Use backup app to specify a backup POS application template.

Use undo backup app to remove the backup POS application template.

Syntax

backup app app-id

undo backup app

Default

No backup application template is configured.

Views

POS application template view

Predefined user roles

network-admin

Parameters

app-id: Specifies a backup POS application template by its ID, in the range of 1 to 31.

Usage guidelines

This command is applicable only to TCP-based POS application templates. If the specified application

template does not exist or is not TCP type, the command can be configured but it does not take effect.

If the FEP corresponding to an application template is unreachable, the router initializes a TCP

connection to the FEP that corresponds to the backup application template.

Examples

# Create TCP-based application template 1.

<Sysname> system-view

[Sysname] posa app 1 type tcp

# Create TCP-based application template 2, and specify its backup application template as application

template 1.

<Sysname> system-view

[Sysname] posa app 2 type tcp

[Sysname-posa-app2] backup app 1

Related commands

timer quiet

caller-number enable

Use caller-number enable to enable sending of the caller number in packets sent to the FEP.

Use undo caller-number enable to disable sending of the caller number.

Syntax

caller-number enable

undo caller-number enable

Default

Sending of the caller number is disabled.

Views

POS application template view

Predefined user roles

network-admin

Usage guidelines

This function is supported only for AM POS terminal devices.

This function takes effect only when the application template is configured in temporary TCP connection

mode.

Examples

# Configure POS application template 1 in TCP mode. Enable sending of the caller number.

<Sysname> system-view

[Sysname] posa app 1 type tcp

[Sysname-posa-app1] mode temporary

[Sysname-posa-app1] caller-number enable

description

Use description to set a description for a POS application template.

Use undo description to delete the description.

Syntax

description text

undo description

Default

No description is set for a POS application template and the POS application template is displayed on

the MIB management platform as an empty string.

Views

POS application template view

Predefined user roles

network-admin

Parameters

text: Specifies a description, a case-sensitive string of 1 to 32 printable characters except question marks

(?).

Examples

# Create a TCP-based POS application template and set the description as ChinaBank1.

<Sysname> system-view

[Sysname] posa app 1 type tcp

[Sysname-posa-app1] description ChinaBank1

display posa connection terminal

Use display posa connection terminal to display connection information for TCP-based POS terminals.

Syntax

display posa connection terminal [ terminal-id ]

Views

Any view

Default command level

network-admin

network-operator

Parameters

terminal-id: Specifies a POS terminal template by its ID, in the range of 1 to 255. If no terminal template

is specified, the command displays connection information for all TCP-based terminals.

Examples

# Display connection information for all TCP-based terminals.

<Sysname> display posa connection terminal

TerminalID SourceIP SourcePort DestinationPort DestinationIP

1 192.168.100.1 1319 3000 192.168.100.236

1 192.168.100.1 1320 3000 192.168.100.236

5 192.168.100.2 1323 4000 192.168.100.236

5 192.168.100.2 1324 4000 192.168.100.236

Table 1 Command output

Field Descri

tion

TerminalID ID of the POS terminal template.

SourceIP Source IP address of the connection.

SourcePort Source port of the connection.

DestinationPort Destination port of the connection.

DestinationIP Source IP address of the connection.

display posa statistics app

Use display posa statistics app to display POS application template statistics.

Syntax

display posa statistics app [ app-id ]

Views

Any view

Predefined user roles

network-admin

network-operator

Parameters

app-id: Specifies a POS application template by its ID, in the range of 1 to 31. If no application template

is specified, the command displays statistics for all POS application templates.

Usage guidelines

The statistics will be deleted if you perform one of the following tasks:

•Delete an application.

•Restart the router.

•Execute reset posa statistics command.

Statistics collection for an application template applies to all instances that use the application template.

Examples

# Display all POS application template statistics.

<Sysname> display posa statistics app

ID Received Sent PktErr DisErr InDiscarded OutDiscarded

1 100 100 0 0 0 3

2 60 70 0 0 0 0

3 100 10 0 0 0 0

Table 2 Command output

Field Descri

tion

ID ID of the POS application template.

Received Number of packets received from FEPs (including PktErr and DisErr, not including

InDiscarded).

Sent Number of packets sent to FEPs (not including OutDiscarded).

PktErr Number of packets in incorrect format.

DisErr Number of packets failed to be distributed to POS terminal templates.

InDiscarded Number of incoming packets discarded due to a full buffer.

OutDiscarded Number of outgoing packets discarded due to link failures.

Related commands

reset posa statistics

Altri manuali per MSR Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali H3C Router di rete

H3C

H3C H3C S3600 Series Manuale utente

H3C

H3C MSR 2600 Manuale operativo e di manutenzione

H3C

H3C H3C S3600 Series Istruzioni per l'installazione

H3C

H3C S3610 Series Istruzioni per l'installazione

H3C

H3C H3C S5100-SI Manuale utente

H3C

H3C SR6604 Manuale utente

H3C

H3C HIM-8FE Manuale utente

H3C

H3C MSR3600-28-X1 Manuale utente

H3C

H3C AR 18-2 Series Manuale utente

H3C

H3C MSR Series Manuale utente

H3C

H3C RA5300 Manuale utente

H3C

H3C S3100-52P Manuale utente

H3C

H3C s5820x series Manuale utente

H3C

H3C H3C S7500E Series Manuale utente

H3C

H3C S12500R Series Manuale utente

H3C

H3C SecPath M9000-S NSQM2MPUD0 Manuale utente

H3C

H3C H3C S3600 Series Manuale utente

H3C

H3C S12508CR Manuale operativo e di manutenzione

H3C

H3C SR6600 Series Manuale utente

H3C

H3C MSR 20-20 Manuale di installazione

H3C

H3C S5500-SI Series Manuale utente

H3C

H3C MSR3600-28 Manuale utente

H3C

H3C H3C S3600 Series Manuale utente

H3C

H3C S3100-52P Manuale utente

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
