Hach MP-Dock Manuale utente
DOC022.53.80073
MP-Dock and MP DataLink
Computer Interface
USER MANUAL
October 2009, Edition 1
© Hach Company, 2009. All rights reserved. Printed in the USA hh/dk
2
3
Table of Contents
Section 1 General information ....................................................................... 5
1.1 Safety information ....................................................................................... 5
1.1.1 Precautionary labels ......................................................................... 5
1.2 Specifications .............................................................................................. 5
1.3 Overview ..................................................................................................... 5
1.4 System requirements .................................................................................. 6
Section 2 MP DataLink installation .............................................................. 7
2.1 Uninstall previous versions ......................................................................... 7
2.1.1 Windows users ................................................................................. 7
2.1.2 Mac OS X users ............................................................................... 7
2.2 Windows installation ................................................................................... 7
2.2.1 Install the executable and support files ............................................ 7
2.2.2 USB serial converter installation ..................................................... 10
2.2.3 USB port driver installation ............................................................. 14
2.2.4 Installation without an internet connection ...................................... 15
2.3 Mac OS X installation ................................................................................ 15
2.3.1 Install executable and support files ................................................ 16
2.3.2 Install the MP-Dock device driver ................................................... 19
Section 3 Enable data transfer .................................................................... 25
3.1 Launch MP DataLink software .................................................................. 25
3.1.1 Windows launch ............................................................................. 25
3.1.2 Mac OS X launch ............................................................................ 26
3.2 Select port preference .............................................................................. 26
3.3 Enable MP series meter communication .................................................. 27
3.4 Access to MP DataLink commands .......................................................... 28
Section 4 MP DataLink menus .................................................................... 29
4.1 File menu .................................................................................................. 29
4.1.1 Load (Ctrl/Command Key + L) ........................................................ 29
4.1.1.1 Current data ......................................................................... 30
4.1.2 Clear Data (Ctrl/Command Key + D) .............................................. 31
4.1.3 Save (Ctrl/Command Key + S) ....................................................... 31
4.1.4 Save As .......................................................................................... 32
4.1.4.1 CSV data format for spreadsheet applications ..................... 32
4.1.5 Print (Ctrl/Command Key + P) ........................................................ 33
4.1.6 Quit (Ctrl/Command Key + Q) ........................................................ 34
4.2 Edit menu .................................................................................................. 34
4.2.1 Preferences .................................................................................... 35
4.2.1.1 Preferences buttons ............................................................. 36
4.2.2 Reference Information .................................................................... 36
4.3 MP Commands menu ............................................................................... 36
4.3.1 Download Data ............................................................................... 37
4.3.2 Set Date and Time .......................................................................... 39
4.3.3 Erase Memory ................................................................................ 39
4.3.4 Disconnect ...................................................................................... 40
Table of Contents
4
4.4 Help menu .................................................................................................40
Section 5 Troubleshooting ............................................................................41
Section 6 Contact Information ....................................................................43
Section 7 Limited Warranty ...........................................................................45
5
Section 1 General information
In no event will the manufacturer be liable for direct, indirect, special, incidental or
consequential damages resulting from any defect or omission in this manual. The
manufacturer reserves the right to make changes in this manual and the products it
describes at any time, without notice or obligation. Revised editions are found on
the manufacturer’s website.
1.1 Safety information
Please read this entire manual before unpacking, setting up or operating this
equipment.
Make sure that the protection provided by this equipment is not impaired, do not
use or install this equipment in any manner other than that specified in this manual.
1.1.1 Precautionary labels
1.2 Specifications
Specifications are subject to change without notice.
1.3 Overview
The MP-Dock allows the user to transfer data (stored in the MP series meter) to the
MP DataLink application. The MP series meter sits on top of the MP-Dock
(Figure 1). Data is transferred through an infra red (IR) port on the bottom of the MP
series meter (refer to document DOC022.XX.80072). The data moves through the
MP-Dock to the computer USB port.
Note: Install the MP DataLink software before the MP-Dock is connected to the computer.
Electrical equipment marked with this symbol may not be disposed of in
European public disposal systems after 12 August of 2005. In conformity with
European local and national regulations (EU Directive 2002/96/EC), European
electrical equipment users must now return old or end-of life equipment to the
Producer for disposal at no charge to the user.
Note: For return for recycling, please contact the equipment producer or supplier
for instructions on how to return end-of-life equipment, producer-supplied
electrical accessories, and all auxiliary items for proper disposal.
MP-Dock specifications Details
Dimensions 207.01 x 76.20 x 39.37 mm
(8.15 x 3.0 x 1.55 in.)
Length of attached USB cable 787.4 mm
(31 in.)
Weight 285.76 g
(10.08 oz.)
Warranty Two years from date of shipment (see Section 7 on
page 45)
General information
6
Features of the MP-Dock:
•Uses an infra red (IR) port to transfer data in a simple and reliable way.
•Uses the software application that is available from a CD or from
www.hach.com.
•Operates the MP DataLink application on the following systems: Windows XP,
Windows Vista and Macintosh (Mac) OS X 10.0–10.4.11.
•Organizes data by record number, parameter, value, measurement unit,
temperature and date/time stamp.
•Exports to Microsoft®Office software through universal formatting (.csv) files.
•Allows the user to set the MP meter time and date through the MP DataLink
software.
•Clears meter memory through the MP DataLink software.
•Receives power through a USB port (no batteries are needed).
1.4 System requirements
Requirements are subject to change without notice.
Figure 1 MP series meter and MP-Dock configuration
System requirements
Computer operating system Microsoft Windows®XPTM, Windows VistaTM or
Mac OS X 10.0–10.4.11
Note: Windows Vista does not save the user settings.
7
Section 2 MP DataLink installation
Perform the following steps to install the MP DataLink computer interface.
2.1 Uninstall previous versions
If applicable, uninstall previous versions of the software before this version is
installed.
Note: Save all work and exit all applications prior to the installation of this software.
2.1.1 Windows users
1. Click Start.
2. Select Control Panel.
3. Select Add or Remove Programs.
4. Scroll to the MP-Dock application.
5. Click Remove. There is no need to restart the computer.
2.1.2 Mac OS X users
1. Select Go in the Finder menu bar.
2. Select Applications.
3. Scroll to the MP DataLink folder.
4. Drag the folder to the trash.
2.2 Windows installation
Note: Install the MP DataLink software before the MP-Dock is connected to the computer.
Make sure to uninstall any previous versions of the software before the installation
is performed (see section 2.1).
Note: Installation and use of MP DataLink requires user acceptance of the End User License
Agreement (EULA).
2.2.1 Install the executable and support files
1. Place the MP DataLink software CD into the CD drive or download the MP
DataLink application from www.hach.com.
2. If Auto install does not start, go to Start, My Computer, MP DataLink.
3. Double-click the MP DataLink icon under Devices with Removable Storage.
MP DataLink installation
8
4. Click NEXT in the MP DataLink Setup Wizard Welcome window to begin the
software installation.
5. Read the End User License Agreement (EULA). If the terms are acceptable,
check the “I accept the terms in the License Agreement” box and click NEXT.
MP DataLink installation
9
6. Click NEXT to accept the file location for the install. (Browse to choose an
alternative location.)
7. Click INSTALL in the Ready to Install window. A Status bar indicates the
installation progress.
MP DataLink installation
10
8. Click FINISH in the Completing Setup Wizard window.
2.2.2 USB serial converter installation
Note: If the Found New Hardware Wizard does not appear, omit this section and go to Section
3 Enable data transfer on page 25.
1. Insert the USB connection cable into any USB port on the computer.
2. The Found New Hardware Wizard prompts the user to search for drivers.
Check the box to search for drivers.
