Haier WQP4-2000N Manuale utente

WQP4-2000N

Haier Household Electric Dishwasher

CONTENTS

Features ------------------------------------------------------------------------

Parts and Functions-----------------------------------------------------------

Safety---------------------------------------------------------------------------

Before operation---------------------------------------------------------------

Operation instructions--------------------------------------------------------

Maintenance--------------------------------------------------------------------

Troubleshooting and Maintenance Service--------------------------------

Technical specifications & Illustration of dishes arrangement ---------

Back

cover

Electric principle diagram----------------------------------------------------

USER’S MANUAL

CODE:0120500989A

Two sprayers of dimensional spray

KNK

FEATURES

The appliance is equipped with two sprayers, enabling dimensional

spray and super cleanliness.

Intelligently programmed with 4 washing programs

available for selection, which are intensive wash,normal

wash, light wash and rinse.

Heated wash

Sliding nylon rack

Specially designed for easy access of dishes.

Automatic fault alarm

Equipped with automatic fault detection system, the buzzer triggers

and the pilot light twinkles when fault occurs or the door is not

properly closed.

Open-door protection

In case that the door is opened during operation, the machine stops

and will not restart until the door is closed again.

Easy operation and convenient use

All mentioned above are advanced

features of the appliance.

This unit is a tableware-cleaning dishwasher. It sprays hot water with detergent

on the tableware, then flushes with clean water.

Door

KOK

PARTS AND FUNCTIONS

Handle

Switch

First push, on; Second push, off.

Used when opening or closing the

door. Be careful not let the door open

accidentally.

Upper sprayer

Washing while Rotating.

Lower sprayer

Door seal

Filter

Separates water with

residues.

Operation board

Power cable

Water inlet

Washing box

Exhaust outlet

Draining hose

Water comes out from

here after washing.

Inlet hose

Connected with a tap.

Hot air comes out from

here in operation.

SELECT START / PAUSE

ON OFF

KPK

PARTS AND FUNCTIONS

ON/OFF switch VFD display Program select button

The lamp lights when the washing

process is selected. The lamp

twinkles when the appliance is under

washing prosess.

Intensive wash Normal wash Light wash Rinse wash

Wash process

display

Remained time

display Spray process

display Drying process

display

WQP4-2000N

*Please read "safety" carefully before operation, so as to use the unit correctly.

KQK

SAFETY

*All of the items in this chapter concern safety.

*Please observe them strictly.

special power socket

Use the special power socket

Caution If the power cable connected at the middle way, or a

prolonged cable or a socket with several spigots is used, the

cable may turn hot or catch fire.

When abnormal phenomenon appears, turn the power

switch to"off", take off the power plug, or cut off the

main power supply and get in touch with haier After-

sales Service Center at once.

Take off

the plug Continually operation at abnormal state may cause electric

shock or fire.

Do not use the unit as flush dishwasher.

It is difficult to eliminate heat, it may cause electric shock or

wet the around appliance.

Nobody is allowed to disassemble or repair it except

special service men.

Abnormal actions may lead to injury, electric shock

or fire.

Power cable must not be damaged

If the supply cord is damaged,it must be replaced by the

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

Never touch the power plug, electric parts, nor operate

the power switch with wet hands.

It is easy to cause electric shock.

Forbidden

Never approach the hot water coming out of the

draining hose, nor the hot steam coming out of the

exhaust outlet.

Touch is

forbidden

Forbidden

Do not open the door while it is in operation.

When the unit stops, do not open the door until the

buzzer rings. Otherwise, hot water may spray

everywhere and hurt you.

Dissembling

is forbidden

Forbidden

KRK

SAFETY

Do not touch detergent with hands when you use it.

Avoid it enter your eyes.

Warning Otherwise, it may lead to rough skin. If it enters your eyes, it

may effect your eyesight. Prevent children from approaching

it.

SPECIAL DETERGENT

Forbidden

After 10cm

The draining hose should be as lateral as possible.

Do not let the end or the middle part of the draining hose

protrude 10cm high. It is an indirect draining type. Draining

water can not go up. If protrusion is higher than 10cm, water

can not be drained out completely. If the draining hose is

shrunken or bent, it may affect water draining. If water can

not be drained out smoothly, the machine will stop operation.

Caution

Easy to be

scaled

Never wash articles except dishes, food containers.

Non-heat-resistant food containers, such as lacquer-coated

containers, aluminum or silver food containers, shall not be

washed. Other-wise, they may be deformed, faded or dama-

ged..

When putting the shelf in or closing the door, make

sure that no food containers touch the body of the

machine. Take care not let the dishes or cups prevent

the sprayer from turning.

Be careful with the dishes after washing.

Forbidden

Do not put heavy objects or water containers on the

top of the dishwasher.

The carpet must not obstruct the opening.

Warning:

Dishwasher Detergents are strongly Alkaline.They can be extremely dangerous, if swallowed .Avoid contact

with skin and eyes and keep children away from the dishwasher when the door is open.

Check that the detergent receptacle is empty after completion of the wash cycle.

-The carpet must not obstract the openings when installing the appliance on the ground with carpet.

-The appliance is not intended for use by young children or infirm persons without supervision.

-Young children should be supervised to ensure that they do not play with the appliance.

-If the supply cord is damaged ,it must be replaced by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

KSK

BEFORE OPERATION

Warning

Intallation should be done by experts.

Water valve

Tighting nut

When connecting it to a lateral type valve

The environment temperature for operation is 5-40°C.

Water quality

Water pressure

Power supply

Maintenance inside the washing box.

The unit has been cleaned before leaving the factory. But it is better to clean it and check each

part for correct position before operation.

Water pressure should be within 0.03~0.6MPa (0.3-6kgf/cm2).Too high water pressure may lead

to water leakage. The surrounding appliances may be got wet.

Environment temperature

Tightly screw the tighting nut on the inlet pipe inti

the water valve.

KTK

Wash Rinse1 Rinse2 Drying

67Min

52Min

OPERATION INSTRUCTIONS

Program selection

1.There are 4 types of washing program available for selection, which are normal wash, intensive

wash, light wash and rinse wash.

2.Press the ON/OFF switch and then indicators for drying and normal wash illuminate.

3.Check the conditions of the dishes and make sure whether a drying process is necessary or not

before selecting the washing program.Press the select button and a beep can be heard, indicating

a program with drying process is selected. The rated duration is shown in table1.When press the

button twice,two beeps can be heard, indicating a program without drying process is selected.

The rated duration is shown in table 2.

4.The program can't be reset when the appliance is in operation. To reset the program, shut off the

power supply and repeat the program selection.

About 26Min

Table 1

Intensive

wash Dirty

Cleanliness

Normal

wash

Rinse

wash

Pilot lamp Washing time

About 10 Min About 20 Min 6 Min

About 25 Min About 5 Min About 20 Min About 6 Min

62Min

About 15 Min About 5 Min About 20 Min About 6 Min

About 17 Min

The indicator for intensive

wash blinks.

The indicator for normal

wash blinks.

The indicator for rinse

wash blinks.

The indicator for light

wash blinks.

Light

wash

About 15 Min

Duration

KUK

1.Open the door and put the shelf in

1)Set the lock on"open"position, draw the

handle forward to open the backdoor.

A.Shelf(The container which

dishes are put in is called shelf).

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Move the lock gently

2)Draw the shelf out of the dishwasher

shelf

2.Dish treatment before washing

1)Wash off residues, such as fish bone,

vegetables,chopsticks,toothpicks,straws,

fat, resin,etc.

2)Dishes adhered with roast food, steam-

ed food, rice should be put into hot water

first. Clean them when they become soft.

3.Put dishes, etc. on the shelf

- Do not let dishes squeezed out of the shelf. If

so,they are easy to damage.

-Correct arrangement

4.Put the shelf into the washing box.

B.Put in detergent

1)The detergent container is set on the inside

door.

Do not let detergent cover the food containers.

Otherwise, detergent may remain on dishes. It

will reduce washing ability.

2)The amount of detergent to put in is about 15g.

1.Special detergent

When the enclosed special detergent is finished,

please buy it in the after-sales service centers

or maintenance depart-ments in each area. For

the contact method, see Warranty.

Dirty spots of rice and eggs, as well as tea spots

can be cleaned by the action of the decomposing

enzyme.

Notice:

None-special detergent is forbidden to use.

Foam may occur if kitchen detergent is used. It

may cause fault to the machine.

2.Close the door

After the door is closed, set the lock to "shut off"

position.

Move the lock gently

OPERATION INSTRUCTIONS

SELECT START / PAUSE

ON OFF

KVK

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

C.Dish washing

1.Switch on the appliance.

Press the ON/OFF switch and the indicators

for drying and normal wash illuminate.

Select proper program (see page 7). The

program indicator lights in 5 seconds and

the wash process starts.

2.Program selection

3.Food containers drying

1)After washing is finished and the power switch

is switched off, open the door. Food containers

will be dry in several minutes.

4.End of wash.

Poorer cleanness

1.Do not let food containers lapped.

If too many food containers are put in it, the

lapped parts can not be washed. If it is

necessary to lap the containers, make sure that

water can spray direct to the inside of the

containers.

2.Yellow or balck spots on food containers

When yellow or black spots are seen on food

cantainers, it means that more iron or tea

elements are in the containers.

3.Check the following items:

1)Chopsticks and forks that protrude out too long

will prevent the spray from turning. If so, please

rearrange them.

2)When the filter or the sprayer is blocked, clean

them, please.

3)Please use special detergent.

4)Do not cover the washing container with food

containers.

5)Remove hard matters adhering to the food

containers.

OPERATION INSTRUCTIONS

Altri manuali per WQP4-2000N

Indice

Altri manuali Haier Lavastoviglie

Haier

Haier DW9-TFE1 Series Manuale utente

Haier

Haier DW9-AFE ME Manuale utente

Haier

Haier HDW9SST Manuale utente

Haier

Haier HDW6WH Manuale utente

Haier

Haier DW-8888-24 Manuale utente

Haier

Haier HDW12-TFE3SS Manuale utente

Haier

Haier DW12-PFE1 ME Manuale utente

Haier

Haier DW15-PFE2ME Manuale utente

Haier

Haier DW12-TFE3 series Manuale utente

Haier

Haier DWL 2825 D00 Manuale utente

Haier

Haier DW12-PFE2-U Manuale utente

Haier

Haier DW9-CBE7 Manuale utente

Haier

Haier DW9-TFE3-F Manuale utente

Haier

Haier DW12-BFES Manuale utente

Haier

Haier DW12-AFE4T Manuale utente

Haier

Haier DW9-AFM ME Manuale utente

Haier

Haier DW12-AFM4 Manuale utente

Haier

Haier ESD100 Manuale utente

Haier

Haier ESD301 - Dishwasher 5 Cycles Manuale utente

Haier

Haier DW15-PFE S Manuale utente

Haier

Haier HDW13G1 Manuale utente

Haier

Haier DW12-CBE7 Manuale utente

Haier

Haier WQP12-AFM2 Manuale utente

Haier

Haier DW12TFE4SS HA AA Manuale utente

Manuali Lavastoviglie popolari di altre marche

Electrolux

Electrolux ESI5211LOX Manuale utente

KitchenAid

KitchenAid KUDB230B Manuale utente

Brandt

Brandt BDJ424DB Manuale utente

Asko

Asko DSD767UXXL.AU Manuale utente

Beko

Beko DFN26210W Manuale utente

NEFF

NEFF S153ITX00E Scheda tecnica

Midea

Midea SV 4.45 wi Manuale utente

LG LDF7932 Manuale utente

Gorenje

Gorenje GV63214 Manuale utente

Hotpoint

Hotpoint HDA1100ZWH Manuale di servizio

Blomberg

Blomberg LDFN2240W Manuale utente

AEG

AEG FFB83836PM Manuale utente

Cylinda

Cylinda DM3220RFD Manuale utente

Atag

Atag DW8214MB Manuale utente

GE GLD8000 Series Manuale utente

Siemens

Siemens SN23HI02KE Scheda tecnica

Omega

Omega ODW717X Manuale utente

BORETTI

BORETTI BVW-683 Manuale utente
