USER'S MANUAL
15"17"20"LCD TV
Please read this manual carefully before
using your television and keep this manual
In a good place for future reference.
M O D E L :
L15S V 6-A 0, L17LV 6-A 1,L 20AV 6-A 0
L 17L6A -G 1,L 2 0L6A ,L 1 5 G 1 -A 0 ,
L17G 1-A 0,L 20G 1-A 0,L 15D2-A 0,
L17D 2-A 0
Front Panel Controls
Control Panel Function
1. MENU Press to select the main menu
2. VOL (V-/VOL-) V olume down / Left orientation to adjust the item in the OSD
VOL (V+/VOL+) Volume up / Right orientation to adjust the item/Press to
enter the submenu.
3. PR (P-/CH-) TV channel down / to select the item in the menu
PR (P+/CH+) TV channel up / to select the item in the menu
4.TV/AV Select the input signals: SCART/PC-RGB/A V/S-VIDEO/TV
5. Power supply switch
6. Power indicator
Illuminates red in standby mode, illuminates green when the display is
turned on
7.Remote Sensor Receiving remote control sends the infrared remote
signal.
12
6
7
4351243
122
33
5
66
7
7
44
MENU PR VOL TV/AV
6
75
TV/AV MENU VOL- VOL+ CH- CH+ POWER
41235
6767
TV/AV MENU VOL- VOL+ CH- CH+ POWER
41235
G1 series D2 series
Note: These buttons are on the top of the sets on these two series.
V0.1
0090508051A
