Hamamatsu Photonics C10910 Manuale utente

Universal streak camera

C10910

Instruction Manual

Thank you for your purchase.

CAUTION

• Follow the safety precautions in Chapter 1 in order to avoid personal injury

and damage to property when using this system. The manual describes the

correct handling method of the system and provides instructions that should

be followed to avoid accidents. Read this manual carefully before using

this system. After reading this manual, store it in a location where you can

refer to it at any time.

Ver.1.19E

MAY 2018

HAMAMATSU PHOTONICS K.K.

87550301-19

C10910 INSTRUCTION MANUAL Ver.1.19E

1. SAFETY PRECAUTIONS

1-1 SYMBOLS

The symbols shown below are used for this system.

Protective conductor terminal

Alternating current

ON (supply)

OFF (supply)

1-2 CLASSIFICATION OF WARNINGS

We have classified the warnings symbols that appear in this instruction manual and on the

system as follows for your convenience. Make sure that you fully understand them and

follow the instructions they contain.

WARNING

Improper handling of the system without observing

these warnings could lead to serious injury to the user

and even death.

CAUTION

Improper handling of the system without observing

these cautions could lead to personal injury to the user

or damage to property.

Note

This symbol indicates a note to help you get the best performance

from the system. Read the contents of the note carefully to ensure

correct and safe use. Failure to observe one of these notes might

impair the performance of the system.

This symbol indicates a cautionary item that should be followed when

handling the system. Read the contents carefully to ensure correct

and safe use.

This symbol indicates an action that is forbidden. Read and follow the

instructions carefully.

This symbol indicates a compulsory action or instruction. Read and

follow the instructions carefully.

C10910 INSTRUCTION MANUAL Ver.1.19E

WARNING

Power supply

Use the system with the indicated voltage on the rating sticker. Using a

different voltage can damage the system and lead to fire or electric

shock.

Cables

Do not to place heavy objects on cables or bend them excessively. Doing

so can damage the cables and lead to fire or electric shock.

Power supply cord

Use the accessory power supply cord when using this system.

Do not touch the plug with wet hands. Doing so can lead to electric

shock.

Do not attempt to dismantle or modify the system.

Doing so can also lead to damage and even injury, as some internal

components become very hot or high voltage. Do not touch parts that are

not indicated in this manual.

Do not allow foreign objects

such as combustible substances, metal objects or water to get inside the

system. These can damage the system and lead to fire or electric shock.

In the event of an anomaly

such as the image suddenly disappearing or the occurrence of a strange

noise, a strange smell or smoke coming from the system, immediately

turn off the power switch and unplug the power supply cord and contact

Hamamatsu subsidiary or your local distributor. Do not attempt to repair

the system yourself.

Do not remove any covers that are secured to the system.

Internal circuits in this system may have high voltages, so removing the

cover may lead to electrical shock.

C10910 INSTRUCTION MANUAL Ver.1.19E

CAUTION

Power supply cord

When unplugging the power supply cord, do not pull on the cord. Remove the

plug from the outlet to avoid causing electric shock or fire.

If the system is not in use for a long period of time, unplug the power supply

cord from the outlet to avoid damaging the cord and causing electric shock or

fire.

Connecting and disconnecting cables

Always turn off the system before connecting and disconnecting cables.

Shipping precautions

When transporting the system by truck, ship, airplane, etc., wrap it

securely in packaging material or something similar.

Strong impact

Do not subject the system to strong shocks (such as dropping it).

Doing so can damage the system.

To prevent overheating in the system’s interior, do not wrap the

device in cloth or other material.

Make sure a space of at least 10 cm at the front of each

ventilating holes for ventilation.

Disposal

When disposing of the system, take appropriate measures in compliance

with applicable regulations regarding waste disposal and correctly

dispose of it yourself, or entrust disposal to a licensed industrial waste

disposal company.

In any case, be sure to comply with the regulations in

your country, state, region or province to ensure the system is disposed

of legally and correctly.

Operating environment

This system is designed and tested for use in an industrial environment. If

this system is used in residential areas, EMI (electro-magnetic

interference) may occur. This system must not be used in residential

areas.

C10910 INSTRUCTION MANUAL Ver.1.19E

CAUTION

Streak tube

The system has a built-in highly-sensitivity streak tube with a very high

photon detection capability. Because of this, excessive incident light can

damage the streak tube. The streak camera operation should be handled

with extreme care to avoid damage.

Protection function of streak camera

The system is provided with protection functions to safeguard from

excessive incident light. However, these functions are not effective in all

cases, so the user should handle the instrument with care, and not rely on

these protective functions to avoid damage.

ND filter

When performing measurements for the first time, make sure an ND filter

or a similar filter is placed in front of the input optics to reduce the

intensity of light. Start with low intensity light and increase gradually to

avoid damage.

C10910 INSTRUCTION MANUAL Ver.1.19E

2. CHECK THE CONTENTS OF PACKAGE

When opening the package, check that the following items are included before use. If the

contents are incorrect, insufficient, or damaged in any way, contact a Hamamatsu

subsidiary or your local distributor before attempting to operate the system.

C10910-XX Universal streak camera main unit

C10910 Universal streak camera main unit

Power unit

Power cable 2 m

USB cable 4 m

BNC-BNC cable 1.5 m

BNC-BNC cable 4 m

AC code 2 m

Spare fuse(inside of AC inlet) 250 V, T4 A

Scaling file(CD-ROM)

C10910 test report

C10910 instruction manual

Tool for exchanging horizontal plug-in unit (HEX wrench 4

mm)

Spacer ring for output optics

Streak tube(inside of main unit)

M10914-01 Horizontal blanking unit

C10910 INSTRUCTION MANUAL Ver.1.19E

Option

Vertical plug-in unit

M10911-01 Synchroscan unit

SMA-SMA cable 2 m

SMA-BNC converter

SMA-50 Ω termination

SWR cable(LEMO – red and black banana plug)

M10911-02 250 MHz synchroscan unit

SMA-SMA cable 2 m

SMA-BNC converter

SMA-50 Ωtermination

SWR cable(LEMO – red and black banana plug)

M10911-03 Synchroscan unit

SMA-SMA cable 2 m

SMA-BNC converter

SMA-50 Ω termination

SWR cable(LEMO – red and black banana plug)

M10912-01 Fast single sweep unit

BNC-BNC cable 1.5 m

SMA-BNC converter

M10913-01 Slow single sweep unit

BNC-BNC cable 1.5 m

SMA-BNC converter

M10913-11 Slow single sweep unit

BNC-BNC cable 1.5 m

SMA-BNC converter

C10910 INSTRUCTION MANUAL Ver.1.19E

Horizontal plug-in unit

M10914-01 Horizontal blanking unit

M10914-01 Horizontal blanking unit is attached to C10910-XX Universal streak camera

main unit.

M10914-02 Shift blanking unit

BNC-BNC cable 1.5 m

M10915-01 Synchronous blanking unit

M10916-01 Dual time base extender unit

Slit length fine adjustment plate

BNC-BNC cable 1.5 m

M10916-02,-03 High repetition dual time base extender unit

Slit length fine adjustment plate

BNC-BNC cable 1.5 m

SMA power divider

SMA-SMA cable 2 m

* When you purchase plug-in additionally, scaling file is attached without M10914 and

M10915 series.

C10910 INSTRUCTION MANUAL Ver.1.19E

Input optics

A1976-01 input optics for streak camera

A1974 input optics for streak camera

Output optics

A11695-01 50:35 output optics for streak camera

A11695-11 50:35 output optics for streak camera

Mount table

A11771-01 Mount table for ORCA-R2

A11771-03 Mount table for ORCA-Flash4.0

A11771-03 Mount table for ORCA-flash4.0
