HAMPTON BAY H15 Manuale utente

cast iron

replaces

Almost 30 years ago, I founded this com-

pany with a mission to produce the nest

replace products available anywhere.

The Hampton line is the result of millions

of dollars in product development, years

of research and listening to what consum-

ers are looking for in a replace: timeless

styling, exceptional quality and a way to

cut home heating costs.

Hampton Quality

The rich, porcelain, enamel nish of each

Hampton cast iron product is a work of

art. Select the tasteful glass grill, one of

four fashionable colors, side shelves, dou-

ble screen doors and create your own

Hampton.

Exceptional Fire

Without question, the Hampton re is

the best in the industry. Gas res feature

dancing ames and glowing embers,

wood res reveal the age old joy of the

snap of wood as it catches re and the

curl of yellow ames from glowing em-

bers.

Cut Fuel Bills in Half

Turn your furnace down and enjoy

comforting Hampton heat in the living

areas you spend time in. Have peace of

mind, even during power outages. All

Hampton products continue to operate

without electricity.

One Hampton = One Tree

At Hampton Fireplaces, we are commit-

ted to protecting our environment. For

every Hampton sold, we will plant a tree.

Working with American Forests, the trees

planted across North America will o-

set carbon emissions and take one more

step to restore nature's balance.

Lifetime Warranty

I am so condent in the quality work-

manship, the nest materials and durable

heavy-duty construction investedineach

and every product, that I oer a Limited

Lifetime Warranty. I know that you will

be as proud of your Hampton as I am – I

guarantee it.

Robert Little

Founder & CEO

why choose Hampton?

index

Hampton Wood Inserts 4

HI300 & HI200

Hampton Wood Stoves 6

H300 & H200

Hampton Gas Stoves 8

H35, H25, H15

Hampton Gas Fireplaces 10

P36, P36D

Hampton Gas Inserts 11

U31,U32

Technicalspecs 12

Hampton HI300 Wood Insert in enamel timberline brown finish.

Hampton® HI200 & HI300

Wood Inserts

High Efficiency Heat

The Hampton cast wood inserts install easily into your existing re-

place adding the timeless beauty of cast iron while eliminating drafts

from an open replace. These replace inserts can deliver up to

75,000 BTU of high eciency heat, circulating comforting warmth to

the living areas you spend time in. Decrease your heating bills and in-

crease the value of your home with one of two inserts sized to t your

replace and your lifestyle.

Specifications HI300 HI200

Medium Small

Maximum BTU 75,000 55,000

Optimum efficiency 77% 73.8%

Emissions (grams/h) 3.8 3.0

Firebox size 2.3 cu. ft. 1.4 cu. ft

Maximum log size 18" 16"

Min. Fireplace Opening HI300 HI200

Width (front) 25" 23"

Height 21-1/2" 19"

Depth 17-1/2" 13-3/4"

Depth (with offset flue) -- 16-1/2"

Hampton HI200 Wood Insert in metallic black finish.

HI200 in enamel timberline brown finish.HI300 in metallic black finish.HI300 shown with oversize faceplate, in metallic black finish.

Standard Features Optional Features

EPA Certied•

Non-catalytic technology•

Single rod draft control•

Airwash system•

Brick-lined rebox•

Ceramic safety glass•

Burn time: up to 8 hrs.•

6" ue•

Metallic black or timberline brown nish•

2-speed blower•

Surrounds in two sizes (HI300)•

Standard or 4-1/2”oset ue adaptor•

(HI200)

Stainless steel liner kit•

Comfort and Convenience

Convenient and ecient, these wood stoves will keep your home

comfortable all year – even during power outages. Add a two speed

blower to circulate even more heat to every part of your room. All

Hampton wood products are certied by the Environmental

Protection Agency (EPA) and meet strict clean air standards. Available

in two sizes including a hearth mount version, Hampton wood stoves

work hard and look great!

Hampton® H200 & H300

Wood Stoves

Hampton H300 large wood stove shown with optional side shelves in a enamel timberline brown finish.

Hampton H200 medium wood stove in charcoal gray finish.

Specifications H300 H200

Medium Small

Maximum BTU 45,500 38,800

Optimum efficiency 74% 74%

Emissions (grams/h) 4.1 3.9

Firebox size 1.71 cu. ft. 1.34 cu. ft

Maximum log size 18" 16"

Burn time (typical) up to 8 hrs. up to 6 hrs.

* Length of burn time and BTU range depend on type of wood, climate conditions

and installation.

H300 shown in enamel slate blue finish. H300 shown in enamel ivory finish. H200 shown with short cast legs, timberline brown finish.

Standard Features Optional Features

EPA Certied•

Non-catalytic technology•

Airwash system•

Single rod draft control•

Front and side door loading (H300)•

Cast iron cooktop surface (H300)•

Brick-lined rebox•

Ceramic safety glass•

Top or rear vent•

6" ue•

Metallic black, enamel timberline brown,•

enamel ivory (H300), enamel slate blue

(H300) nish

Matching side shelves•

Short cast legs•

Two speed blower•

Outside air adaptor•

Ash drawer (use with standard legs only)•

Outstanding Fire

Hampton’s beautiful styling is matched by its unsurpassed re and

log package. Convenient gas ames have been carefully engineered

to twist and icker in yellows and reds around the most realistic logs

available anywhere today. In addition – this re is designed to deliv-

er controllable high eciency heat with the added option of a wall

thermostat or FireGenie Remote Control. Available in 3 sizes, these

gas stoves will heat anywhere while saving money on your heating

bill.

Hampton H35 large gas stove in enamel slate blue finish.

Hampton® H15, H25, H35

Gas Stoves

Hampton H25 medium gas stove in enamel timberline brown finish with decorative glass grill.

H15 in enamel slate blue finishH25 in charcoal gray finish with decorative glass grillH35 in enamel ivory finish with decorative glass grill

Specifications H35 H25 H15

Natural Gas Large Medium Small

Maximum BTU 36,000 25,000 18,000

Turn down to (BTU) 18,000 12,500 10,500

EnerGuide rating (Canada only) 68.34% 61.15% 62.31%

Efficiency 83% 83% 80%

Propane

Maximum BTU 34,000 23,000 18,000

Turn down to (BTU) 17,500 11,500 10,600

EnerGuide rating (Canada only) 69.72% 61.63% 62.31%

Efficiency 85% 85% 82%

Standard Features Optional Features

Flame height adjustment with up to 50%•

turndown

Heavy-duty ceramic safety glass•

Top mounted easy access controls•

Reversible ue for top or rear venting•

Charcoal gray, enamel slate blue, ivory or•

timberline brown nish

Decorative glass grill (included with H15)•

Double screen doors (H35 only)•

Standard brick panels (H35 only)•

Variable speed blower•

FireGenie® remote control•

Wall thermostat•

AstroCap™ vent system•

Color match vent paint•

LP conversion kit•

BTU reduction kit (H35 only)•

Hampton P36 gas fireplace in enamel timberline brown finish.

Hampton® P36 & P36D

Medium Gas Fireplaces

A Direct Vent Fireplace … anywhere.

Direct vent technology allows you to install your unique Hampton

replace almost anywhere in your home without a costly chimney

system. The replace simply vents directly to the outside of your

home, either through a wall or up through your roof.

Standard Features Optional Features

Flame height adjustment with up to 50%•

turndown

Heavy-duty ceramic safety glass•

Easy access faceplate mounted controls•

Grills and surrounds in metallic black or•

enamel timberline brown

Enamel door frame (timberline brown)•

Double screen doors (metallic black only)•

Brick panels in standard or herringbone•

design

FireGenie® remote control•

Wall thermostat•

AstroCap™ vent system•

LP conversion kit•

Specifications P36 P36 Deep

NG LP NG LP

Maximum BTU 30,000 30,000 30,000 30,000

Turn down to (BTU) 15,500 15,500 15,500 15,500

EnerGuide rating (Canada only) 62.7% 62.7% 64.62% 64.62%

Efficiency 82% 82% 82% 82%
