H&S 6118 Manuale utente

Revision#01

6118 Starting Ser. #510001

6120 Starting Ser. #511001

6122 Starting Ser. #512008

Manufactured By

H&S MANUFACTURING CO.,INC.

P.O. BOX 768 (715) 387-3414 FAX (715) 384-5463

MARSHFIELD, WISCONSIN 54449

HSMFG0115 Part #60553

WARNING

READ AND UNDERSTAND THIS MANUAL

BEFORE OPERATING THIS EQUIPMENT.

UNSAFE OPERATION OR MAINTENANCE OF

THIS EQUIPMENT CAN RESULT IN SERIOUS

INJURY OR DEATH.

6118/6120/6122

OPERATOR’S MANUAL

FLEX-FRAME

RAKE

CONTENTS

Warranty & Warranty Registration Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

Manufacturers Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Dealer Pre-Delivery Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Dealer Delivery Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Safety Information - Be Alert Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Safety Information - Explanation of Safety Signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Safety Information - Warning - Owner Must Read and Understand . . . . . . . . . . . . . . . . . . . . . .10

Cap Screw Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Set-up & Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Preparing for Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Operation & Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-16

Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Lubrication Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-19

Decal Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20-25

Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Service Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27-28

-3-

(Remove Dealers File Copy At Perforation)

DEALER PRE-DELIVERYCHECK LIST

AFTER COMPLETION, DEALER SHOULD REMOVEAND RETAIN FOR RECORDS

After the rake has been completely set-up, check to be certain it is in correct operating order before

delivering to the customer. The following is a list of points to inspect. Check off each item as you

have made the proper adjustments and found the item operating satisfactorily.

Rake was not damaged in shipment. Check for dents and loose or missing parts.

Report damage immediately to H&S Manufacturing Co., Inc.

Rake has been correctly assembled according to instructions in this manual. Wheel

nuts and all other fasteners are tightly secured.

All bolts and fasteners are tight.

All grease fittings have been lubricated. See Lubrication Chapter of this manual for

details.

Hoses and fittings are properly attached and there are no visible leaks.

All mechanisms are operating trouble free.

Rake wheels touch ground in unison when lowered into position. (Rake setting level)

Wheels are properly mounted.

Tires are inflated to correct pressure.

Decals are in place and legible.

ModelNumber

Serial Number

Dealer’s Name

Inspection Date

Signature of Pre-Delivery Inspector

IntentionallyLeftBlank

-4-

DEALER DELIVERYCHECK LIST

AFTER COMPLETION, DEALER SHOULD REMOVEAND RETAIN FOR RECORDS

Thischecklistthat follows is an important reminderofvaluableinformation that should be passed

on to the customer at the time this Rake is delivered.

Check off each item as you explain it to the customer.

This delivery check list, when properly filled out and signed assures the customer that the

Pre-delivery service was satisfactorily performed.

Explain to the customer that the pre-delivery inspection was made.

Explain to the customer all the safety precautions they must exercise when operating

this unit.

Explain raking and windrow width adjustments.

Explaintocustomer that regular lubrication is requiredforproperoperation and long life of

machine.

Show customer the lubrication section of Owner’s Manual.

Give the customer Owner’s Manual and make sure they read and understand all operating

and service instructions.

Have the customer sign a completed “Warranty Registration”, and mail it.

Date Delivered

Dealer’s Name

Signature of Original Buyer

Note: Warranty is not valid until warranty card is completed and returned to H&S Mfg. Co., Inc.

-5-

(Remove Dealers File Copy At Perforation)

IntentionallyLeftBlank

-6-

-7-

SAFETYINFORMATION

ALERT! YOURSAFETY

ISINVOLVED.

THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY

IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE

BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN

PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR

DAMAGE.

H&S MANUFACTURING CO., INC.

RECOGNIZE SAFETY INFORMATION

This is the safety-alert symbol. When you see this symbol

on your machine or in this manual, be alert to the potential

for personal injury.

Follow recommended precautions and safe operating

practices.

UNDERSTAND SIGNAL WORDS

Asignalword; DANGER, WARNING,orCAUTION-is used

with the safety-alert symbol. DANGER identifies the most

serious hazards.

Safety signs with signal word DANGER or WARNING are

typically near specific hazards.

General precautions are listed on CAUTION safety signs.

FOLLOW SAFETY INSTRUCTIONS

Carefully read all safety messages in this manual, and all safety signs on your machine. Follow all

recommended precautions and safe operating procedures.

Keep signs in good condition. Immediately replace any missing or damaged signs.

-8-

SAFETYINFORMATION

OBSERVE MAXIMUM TRANSPORT SPEED

The maximum transport speed for this implement is 32 km/h (20 m.p.h.).

Some tractors are capable of operating at speeds that exceed the maximum

transport speed of this implement. Regardless of the maximum speed capability

of the tractor being used to tow this implement, do not exceed the implement’s

maximum transport speed.

Exceeding the implements maximum transport speed can result in:

* Loss of control of the tractor/implement combination

* Reduced or no ability to stop during braking

* Implement tire failure

* Damage to the implement structure or its components

Use additional caution and reduce speed when towing under adverse surface

conditions, when turning, and when on inclines.

Do not attempt transport if the fully loaded implement weighs more than 1.5 times

the weight of the tractor.
