Harmopool Duo Manuale utente
Harmo Pool Duo water treatment system
ZWMX0113-P and ZBSX0114-P
Table of content
Introduction...........................................................................................................................................3
Characteristics.......................................................................................................................................3
Specifications.........................................................................................................................................4
Installation.............................................................................................................................................4
Installation items...............................................................................................................................4
Installation of water treatment plate...............................................................................................5
Setting parameters............................................................................................................................9
Winter ready....................................................................................................................................12
Spring startup..................................................................................................................................13
Maintenance and inspection...............................................................................................................13
Maintenance.....................................................................................................................................13
Warnings..........................................................................................................................................14
Introduction
This manual contains all of the necessary information for installation, debugging and
maintenance. Read the manual thoroughly before opening or using the unit.
The manufacturer of this product will not be responsible for damage or damage caused by the
product as a result of improper installation or maintenance. It is essential that the instructions
of this manual are always followed. Qualified personnel must install the product.
Only a qualified installer, center, person or authorized dealer can repair this product
Maintenance and operation should be performed according to the recommended time
and frequency as specified in the manual
Use only original standard parts. Failure to do so will void your warranty
Characteristics
Durable: The materials used are chlorine, acid (sulfuric acid) and base-resistant. This
can cause prolonged exposure to swimming pool water (even with salt for salt
electrolysis)
The dosing devices are not suitable for use with hydrochloric acid (HCl)
Simple operation: The system is user-friendly to operate: Turn it on and adjust desired
pH (acid) or redox value (chlorine)
Low cost: The operational cost is very low, because the pool water will never turn green
when used correctly
Specifications
ZWWX0113‐P/ZWWX0114‐P
PH CONTROL ZWMX2155 Peristaltic pomp
CHLORINE CONTROL BSV salt electrolysis
ZBSX0003 = ZWMX0113-P
ZBSX0004 = ZWMX0114-P
POOL CONNECTION 50mm rubber
FLOW SWITCH
SAFETY
Optional
DIMENSION PLATE 100 x 50 cm
DISPLAY CARD Harmo pool ref ZWMX7010
RELAY CHART Harmo pool ref ZWMX7011
Installation
Installation items
The company provides the plate with water treatment devices without a plug for the metering
devices. It is electrically connected to the salt electrolysis device.
Attention!
The electrical installation must be that:
o The acid pumps cannot work if the filter pump does not work
Adding the chemicals to the swimming pool must be done downstream of the
swimming pool accessories such as heating, UV lamp, filter etc.
It is recommended to install the water treatment unit in bypass configuration
Install the water treatment unit on a solid basis
Always keep the product upright. If the product is tilted or placed on its side, then the
electrodes cannot measure correctly
The product must be installed indoors. If you want to do this outside you should
contact your supplier
The dosing devices must not be used with hydrochloric acid (HCl). Sulphuric acid 15
or 30% must be used.
The device's electronics (metering devices) must be installed indoors. Make sure - in
case of leak - the water cannot over install to walk
Make sure the acid container are placed OUTSIDE or in a well-ventilated area
Calibrate the pH and Rx electrodes for initial use, and then "regularly". We
recommend 2 calibrations per year, and extra calibrations if in doubt of water quality /
machine operation.
We recommend to verify the water quality using a independent technique once a
month.
The peristaltic tube inside the acid dosing system must be replaced on a yearly basis.
The acid container has to be placed lower than the peristaltic pump.
The acid injection nozzle need to be detartrated regularly, minimum on yearly basis.
Installation of water treatment plate
1. Place the water treatment system to fixed wall
2. Insert pH and chlorine electrodes into the electrode holders. Fix the nut with a pliers or
tighten the cap. If you do not do this, there is a chance that a leak will occur which is
not guaranteed
3. Connect water inlet and outlet so the water first passes through the redox and pH
measuring electrode and then along the salt electrolysis.
Preferred installation in bypass configuration:
4. Make the electrical connections in such a way that:
The salt electrolysis and acid pump cannot work if the filter pump is not working
The salt electrolysis and acid pumps can be switched off when the filter pump
operates
5. Start the filter pump
6. Verify that the installation does not leak
7. Stop the filter pump and remove the electrodes from the container and calibrate pH and
redox electrodes
Attention!
a) If you do not have a bypass configuration, close the holes of the electrode holders with
a rubber stopper (Product Code: ZFPX4640) that prevents the water from spraying the
probe during the calibration
b) The electrodes calibration procedure may take several minutes. To ensure accurate
reading, it is important to follow the steps below
c) Make sure that the calibration fluids used in the calibration process always match the
indicated values and the fluids are not contaminated
8. Calibration electrodes
In a few short steps, you have calibrated the electrodes within the shortest time:
1) Dip the measuring heads into the pH (pH7) and Redox calibration fluids
(465-468 mV) and give them 5 minutes the time to equilibrate before continuing the
calibration process
2) Press pH and Redox for 10 seconds: (A) buttons (upper and lower buttons) separately
in to 2 red led; (B) light up
3) After about 2 minutes the lights turn on and you can read the values of the screen. If
the calibration is correct, the values are as follows:
a. pH 7.0 + - 0.1
b. Redox 468 + -10mV
If the values are not within the range as described above, you can press pH and
Redox buttons again to repeat the calibration process.
If the calibration fails, the LED (B) remains flicker, and the electrode must be
changed.
If you do not have a bypass configuration, you can insert two rubber caps
ZFPX4640 into the electrode holders to avoid water coming out of the electrode
holders during the calibration
Setting parameters
A number of parameters must be set. If you press the middle button, you will see the following
screen:
Press the middle button again. The "Language" setting has now been checked
1. Language
If you press the middle button, you can choose from multiple languages. Now Dutch is selected,
so press it again to set the language Dutch. To choose another language, press the middle button
again. Then navigate through the top or bottom buttons to the languages French, Castellano,
Italian, English or German. You confirm your language selection by pressing the middle button.
2. Method of dosing (salt electrolysis, proportional or continuous)
Press the second button from the top. The "dosage" setting has now been checked. Press the
center button to activate this setting. Press the lower button until the dosing method "salt
electrolysis" is selected.
Explanation of the salt electrolysis dosing :
The device will measure the pH and Redox for 30 seconds. This measurement is stored
in memory
During 2 minutes, the following happens:
o If the PH value is much higher than the setpoint (target), the metering pump
always rotates
o If the PH value comes closer to the setpoint value, the metering pump goes on
and off. The closer PH value you get to the set point value, the less the pump is
running
o The salt electrolysis device will allow salt electrolysis to function for 2 minutes,
if the Redox is lower than the setpoint. After two minutes, salt electrolysis and
pH dosage will stop, and pH and Redox will be measured again. This circle
repeats continuously
3. PH + or PH-
Press the lower button. The setting "PH + or PH-" is now checked. Press the center button to
activate this setting. If the character appears, press the middle button again. Now you have the
supply of PH-settled.
PH- must be adjusted when using liquid chlorine. Liquid chlorine already contains PH + which
is always added as a stabilizer.
PH- must be set using salt electrolysis. In the production of chlorine by the salt electrolysis
device, PH + (NaOH) is formed as by-product.
It is not possible to use PH + and PH- at the same time : one of both needs to be selected.
