Hasselblad XPan 4/45 Manuale utente

LENSES

www.hasselblad.com

1/2

Document ID: 3024015/0610

CLOSE FOCUS RANGE DATA:

Minimum distance object to ﬁlm 0.70 m

Corresponding distance object to front lens 0.62 m

Maximum image scale 1: 13

Corresponding area of coverage 31 x 84 cm

Corresponding exposure reduction 0.2 f-stop

XPan

HASSELBLAD 4/45

100

0 10 20 30

Image height (mm)

f/4

MTF (%)

100

0 10 20 30

Image height (mm)

f/8

MTF (%)

MTF

Modulation Transfer as a func-

tion of image height at inﬁnite

focus setting.

Sagittal slit orientation drawn

with continuous line and tan-

gential with dashed. White

light. Spatial frequencies 10,

20 and 40 lp/mm

ENTRANCE PUPIL POSITION

56 mm in front of the ﬁlm plane.

(at inﬁnite focus setting):

The entrance pupil position is the correct position of the

axis of rotation when making a panorama image by com-

bining individual images of a scene.

To convert meters into feet, multiply by 3.281. To convert meters into inches, multiply by 39.37

LENSES

www.hasselblad.com

2/2

Document ID: 3024015/0610

Depth-of-ﬁeld in meters

f/4 f/8 f/16 f/22

∞ 15 - ∞ 8 - ∞ 4 - ∞ 3 - ∞

10 m 6 - 30 4 - ∞ 3 - ∞ 2.3 - ∞

5 m 3.8 - 7.5 3 - 14 2.2 - ∞ 1.9 - ∞

3 m 2.5 - 3.7 2.2 - 4.8 1.7 - 12 1.5 - ∞

2 m 1.8 - 2.25 1.6 - 2.6 1.4 - 4 1.2 - 6

1.5 m 1.38 - 1.65 1.3 - 1.8 1.1 - 2.3 1 - 3

1.2 m 1.13 - 1.29 1.05 - 1.4 0.95 - 1.65 0.9 - 1.9

1 m 0.95 - 1.06 0.91 - 1.12 0.83 - 1.30 0.8 - 1.4

0.8 m 0.77 - 0.835 0.74 - 0.87 0.69 - 0.95 0.65 - 1.05

0.7 m 0.678 - 0.725 0.66 - 0.75 0.62 - 0.8 0.59 - 0.85

XPan

HASSELBLAD 4/45

DEPTH-OF-FIELD DATA

Given distances are calculated for a blur circle diameter of 33 microns and do not include the effect of lens aberra-

tions.
