Smart-Mini

Water Purification System

Operation and Service Manual

Version:1501

Notice

If it is the first time for you to use our product, please carefully read this operating and

maintenance manual which will give you a lot of help. We take responsibility for regular

maintenance and repair work instead of consequences caused by improper operation.

The content of the publication is subject to change and/or updating without notice. The

content of this manual is only for reference use. The manufactory and the distributors shall

not be responsible for losses caused by incorrect description or misuse of this manual. The

graphics contained in the manual are as general representative which may have some errors

compared to entity. But the description is definitely match the function.

In accordance with copyright law, the company holds and retains the exclusive right to

all the works. Without written consent provided by company, any other organization or

individual has no right to any form of manual changes.

Preface

Thank you for using Smart-Mini water purification system designed and manufactured

by Shanghai Canrex Analytic Instrument Co, Ltd.

If you have any good suggestion, Please contact us, we will improve our products and

after sale service continuously.

Global Exclusive Agent: Healforce development (hongkong) Co. ltd. Tel: (00852）28987303

China Exclusive Agent: Nison Instrument (Shanghai) Co. ltd. Tel: (8621)62728646

Manufacture: Shanghai Canrex Analytic Instrument Co. ltd. Tel: (8621)50911997

ISO 9001:2008 Certificate

Contents

Chapter 1 General.....................................................................................................................1

1.1 Confirm the ordering products.......................................................................................1

1.2 Safety information......................................................................................................... 1

1.3 System operating environment...................................................................................... 1

1.4 warnings signal.............................................................................................................. 2

Chapter 2 System Introduction............................................................................................... 3

2.1 System principle.............................................................................................................3

2.2 Technical features.......................................................................................................... 3

2.3 Specifications for the system......................................................................................... 4

2.4 Diagram of the Smart-Mini system................................................................................5

Chapter 3 Instructions before installation..............................................................................7

3.1 check before installation................................................................................................ 7

3.2 Option spare parts.......................................................................................................... 7

3.2.1 Systematic data recording package CR-SP840....................................................7

3.2.2 Enhanced pretreatment cartridge CR-SP102....................................................... 7

Chapter 4 Installation...............................................................................................................9

4.1 Pipeline connections...................................................................................................... 9

4 .2 Signal cable connection.............................................................................................. 10

4.3 Pretreatment installation.............................................................................................. 10

4.3.1 open the side door of the main unit....................................................................10

4.3.2 The position of the main components................................................................ 10

4.3.3 Installation of pretreatment cartridge.................................................................11

4.3.4 Installation of ultra-purification cartridge (CR-SP302M)................................. 12

4.3.5 Installation of ultra-purification cartridge(CR-SP303M).................................. 12

Chapter 5 Parameter setting and operation......................................................................... 14

5.1 Control panel area........................................................................................................ 14

5.2 LCD display area......................................................................................................... 14

5.3 symbols and graphics for LCD display........................................................................14

5.4 Function Keypad..........................................................................................................15

5.5 Operation......................................................................................................................15

5.6 Parameters setting........................................................................................................ 17

5.6.1 Alarm Settings....................................................................................................18

5.6.2 Calendar setting................................................................................................. 21

5.6.3 Volume of taking product water setting............................................................. 22

5.6.4 Dispensing flow setting......................................................................................22

5.6.5 Ultra-pure water quality setting......................................................................... 23

5.6.6 Unit selection..................................................................................................... 23

Chapter 6 Maintenance.......................................................................................................... 25

6.1 Routine maintenance....................................................................................................25

6.2 Periodic maintenance................................................................................................... 25

6.3 Maintenance works and service works........................................................................ 26

6.3.1 Into the maintenance settings.............................................................................26

6.3.2 Pre-treatment replacement................................................................................. 28

6.3.3 RO membrane replacement................................................................................29

6.3.5 UV lamp replacement........................................................................................ 33

6.3.6 Micro-filter replacement.................................................................................... 34

6.3.7How to re-installation when the cartridges are not installed in the right place...36

6.4 System status check..................................................................................................... 36

6.5 Data record of system.................................................................................................. 37

6.7 Restore factory settings................................................................................................39

Chapter 7 Troubleshooting.....................................................................................................40

7.1 No display.................................................................................................................... 40

7.2 Making RO water is too low........................................................................................40

7.3 The pure water conductivity is too high....................................................................41

7.4 Ultra-pure water resistivity is too low......................................................................... 41

7.5 The flow rate of ultra-pure water is too low................................................................ 41

Chapter 8 Order information................................................................................................ 42

8.1 Consumable..................................................................................................................42

8.2 Option parts..................................................................................................................42

Chapter 9 Appendix................................................................................................................43

Appendix 1 Fuse replacement............................................................................................43

Appendix 2 pressure limiter installation............................................................................ 44

Appendix 3 inlet valve unit installation............................................................................. 45

Appendix 4 Leakage protection sensor installation........................................................ 46

Appendix 5 Components connection to main-board......................................................... 47

Chapter 1 General

1.1 Confirm the ordering products

The manual is written for Smart-Mini series water purification system

The content of the manual can lead users to installation, operation and maintenance of

the Smart-Mini series water purification system

We strongly recommend our users to read and understand the content of the manual

before installation, operation and maintenance

You can easily find the model of the system in the nameplate at the back of the system.

Please contact Shanghai Canrex Analytic Instrument Co., Ltd if you find out any

incorrect description in this manual.

1.2 Safety information

You must use the safety norms according to this manual before using the Smart-Mini

system, especially water and power supply. It is necessary to refer to this manual when you

install or operate the Smart-Mini system. Unqualified using environment will endanger the

normal operation, or even damage the whole system.

The installation, commissioning and maintenance of the equipment can only be

completed by Heal Force or its authorized agents. Heal Force did not responsible for duties

and responsibilities if the equipment is disassembled by unauthorized dealer or service

personnel.

1.3 System operating environment

Indoor sue

Avoid direct sunlight

Between 0-2000 meters altitude

Ambient temperature: 4-45℃

Operating Voltage: AC 220V 50 Hz OR 110V 60Hz

Inlet pressure: 0.1-0.4MPA.

The fluctuation range of the main power supply can be 10% of the normal voltage.

Transient over-voltage power supply is grade 2.

There is an drains around the equipment(1 meters)

Adequate indoor ventilation

Mounting surface must be fixed, level, and not burning

Avoid direct sunlight

No heat source next to the equipment.

Be away from strong magnetic field.

1.4 warnings signal

Note alert you to pertinent facts and conditions, please

read this operation and service manual carefully before

you operate the main system

Caution: Caution alert you to the possibility of damage to

the equipment, and water in pipe may spill out when the

cartridge is installed OR replaced.

Danger: Danger alert to a possibility of personal injury.

Power supply must be firmly grounded

Chapter 2 System Introduction

2.1 System principle

Smart-Mini Series is an advanced essential laboratory equipment, widely used in trace

analysis, diagnostics, toxicology, precision optics laboratories, as well as in hospital, research

institute and other water quality monitor department. The device adopted advanced modular

design, CPU auto-control technology, highly integrated water treatment equipment. It is the

new generation of intelligent water purification system with intellectual property.

The feed water of Smart-Mini system is ordinary tap water. The feed water is passing

through the multi-channel process of pretreatment cartridge, reverse osmosis cartridge,

purification cartridge, Ultra-purification cartridge ,UV sterilizer, Micro-filter cartridge. The

quality of ultrapure water can reach the resistivity of 18 MΩ.cm, and eliminating bacteria.

2.2 Technical features

Product line is abundant, as many as a hundred variety, to meet individual needs.

Disposable integrated cartridge simplifies operation. It takes less time to replace any

component

Modular design concept, including pretreatment cartridge, reverse osmosis,

purification cartridge Self-diagnostic microprocessor control system monitors major

parameters and alarm to ensuring the main system at optimize operation status.

Advanced CPU self-controlled technology can determine the configuration. The

system will shutdown automatically when the feed water is shortage and auto flush when the

main system re-stared. Double channel design for pure water and ultrapure water.

Special UV sterilizer control technology make the UV light work only when

ultrapure water is produced, thus can extend life time of UV lamp.

Interactive LCD display affords user optimum convenience, with indication on

conductivity, resistivity, temperature, operate mode, volume dispense products water.

3-channel resistivity sensors, equipped with temperature compensation function,

comprehensively monitor system operation and water quality variation.

Two hours standby mode with various types of loop disinfection. Using hydrogen

peroxide as disinfectant to protect operator and filtration cartridge, and guarantee the quality

of ultrapure water.

Leakage protection unit(optional). The main unit cut off the inlet water and send an

alarm signal if water leakage occurs.

A special connection process is applied for the Smart-Mini system, eliminating the

risk of RO membranes seepage when the main unit is in standby mode.

Volume dispense function (0.1-25L adjustable) or water producing amount according

to your needs

PIN-coded access to software set points prevent unauthorized changes to operation or

system settings.

RS232 port allows for data collection and permanent record of water quality and

system parameters--essential for compliance with good laboratory practice guidelines.

With remote monitor software (option),you can remote the water system on the

computer.

2.3 Specifications for the system

Smart-Mini

Feed water

requirement

Conductivity μS/cm@25℃

＜400

Pressure MPa

0.1～0.4

Temperature ℃

5～40

Pure water

Specification

Ion rejection rate %@25℃

≥95

Bacteria remove %

＞99

Products resistivity MΩ.cm

＞18

Make rate* L/H@25℃

25-30

Dispensing rate L/H

25-30

TOC** ppb

1-10

Particles***（0.22μm） /ml

Bacteria*** cfu/ml

Power Consumption W

Weight kg

Main System

Dime. W*D*H

525*314*571

Note:

* The making rate will be changed with temperature variation. （3% per 1℃）

** The feed water TOC is less than 1000ppb.

*** with 0.22um final filter cartridge

2.4 Diagram of the Smart-Mini system

Smart-Mini

Indice

Altri manuali Heal Force Sistema di filtraggio dell'acqua

Heal Force

Heal Force Smart-NE Series Manuale operativo

Manuali Sistema di filtraggio dell'acqua popolari di altre marche

Wisy

Wisy LineAir 100 Manuale utente

Schaffner

Schaffner Ecosine FN3446 Series Manuale operativo

Pentair

Pentair FLECK 4600 SXT Guida utente

H2O International

H2O International H20-500 Manuale utente

Renkforce

Renkforce 2306241 Manuale utente

Neo-Pure

Neo-Pure TL3-A502 Manuale utente

FLTR

FLTR OBF Manuale utente

STA-RITE

STA-RITE VERTICAL GRID DE FILTERS S7D75 Manuale utente

Applied Membranes

Applied Membranes W-G844EM Manuale utente

BEGA

BEGA 116 Manuale utente

WATA

WATA Standard Manuale utente

Price

Price FFU series Manuale

Gaggenau

Gaggenau BRITA INTENZA 467873 Manuale utente

Brita

Brita SAFF-100 Manuale utente

HEISSNER

HEISSNER FPU24000-00 Manuale utente

BGS technic

BGS technic 1518 Manuale utente

Reverse Osmosis

Reverse Osmosis RF Series Manuale utente

ubbink

ubbink Filtramax Series Manuale utente
