Health o meter® Professional

Digital Scale Wireless USB Station

User Instructions

P/N UMWIFIUSB Rev20141231

Thank you for your purchase of this Health o meter®Professional product. Please read this manual

carefully, and keep it for easy reference or training.

TABLE OF CONTENTS

3 Wireless Configuration - WAP/WPA2 17Caution and Warning

Windows Requirements 3 Administrator Configuration 18

4 Wireless Network Communication 19Service

Package Contents 5 Maintenance 20

Connecting to a Health o meter®

Professional Scale 21PC Requirements

6 Disconnecting from a Health o meter®

Professional Scale 22Product Overview

7 Firmware Upgrade 23Hardware Installation

Software Installation 10 Troubleshooting 25

Configuration - Control Center 11 Factory Defaults 26

Configuration - Web Page 12 Limited Warranty 31

Federal Communication (FCC)

Statement 32General Settings

Wireless Configuration - WEP 15 CE Statement 33

For User Instructions updates and revisions please go to:

http://www.homscales.com

CAUTION AND WARNING

To prevent installation and performance issues to your PC, please follow these instructions

carefully.

To prevent unsuccessful installation, exercise caution when installing Health o

Meter®Professional Scales Allscripts Connectivity App.

For accurate data collection, confirm and upload the data according to the procedure

described in this manual.

If the Interface software becomes damaged or corrupted, do not operate the application.

Reinstall the Interface software per installation guide instructions.

Windows Requirements

This installation is exclusively compatible with Windows®XP, Vista, and 7.

In addition, the installation also requires Windows Installer 3.1 or higher. Most versions of

Windows have this installed already. If it's not listed as an optional update in Windows Updates;

Installation also requires the .NET 4.0 Client Profile to be installed on your PC. If this is not

already installed, this is available as an option through Windows Update.

You can download these software tools from:

http://www.microsoft.com/downloads/en/details.aspx?FamilyID=5A58B56F-60B6-4412-95B9-

54D056D6F9F4

*Windows is a registered trademark of Microsoft Corporation.

SERVICE

Customer Service Information

For further information or telephone support, please contact Customer Service at:

Telephone: 1 (800) 815-6615

Email: [email protected]

Package Contents

o1 x Wireless 4-Port USB Station

o1 x Installation Manual

o1 x Installation CD

o1 x Warranty / Registration Card

o1 x Power Adapter

o1 x USB Cable

o1 x Ethernet Cable

PC Requirements

oCPU of 1.7GHz and above

oMinimum 512MB RAM

oWindows XP/Vista/7

oAvailable wireless router in home/office network

Product Overview

1. USB connected LED

2. USB port located on the front

3. On/Off Switch

4. Power adapter connector

5. Reset button

6. Network port

7. USB ports located on the back

8. Antenna

Figure 1

NOTE: Before you connect your Health o meter®Professional scale to the Wireless USB

Station, please refer to the user manual and install the driver on your computer first.

Hardware Installation - Step 1

1. Connect your Health o meter®Professional scale USB port to any one of the USB ports on the

Wireless USB Station. Place the Wireless USB Station on a shelf or table near the scale.

Figure 2

Hardware Installation - Step 2

2. Connect the Wireless USB Station to the router, switch or office Ethernet network with the

included Ethernet cable.

Figure 3

Hardware Installation - Step 3

3. Connect the power adapter to the Wireless USB Station and turn it on using the On/Off

switch. The USB connected LED will turn on indicating that unit is correctly connected to

the network. Turn on your Health o meter®Professional scale.

Figure 4

Software Installation

Please insert the installation CD into your Windows based PC. The CD should auto play and

bring up the software installer.

If you have disabled the auto-play function, please browse the CD and run the set-up program

manually.

Follow the instructions of the wizard to complete the installation process. Once the installation is

complete, click "Finish" to launch the application.

Figure 5
