3
Set the “PART COUNTER” for the quantity of parts desired on the top
row. The bottom row of numbers counts the quantity of parts cut of the
desired quantity. To reset the upper row to change the part quantity for
another job, press the small buttons above each number to set each
column to zero by pressing the button until the readout reaches zero or to
the desired quantity. Clear the parts cut row (lower row of numbers) by
pressing the larger button on the bottom. For more information on using
the Parts Counter refer to the “PARTS COUNTER” section of this
manual.
The “AUTO” switch has three positions; “AUTO” at the top,
“NEUTRAL” in the center, and “FEED” on the bottom. Before
changing the part length, move the “AUTO” switch down to the
“FEED” position. This will move the Bar-Feed forward. Put the
“AUTO” switch in “NEUTRAL” to energize the control. When
preparing to run the machine in an automatic cutting sequence
place the switch in the “AUTO” position.
The “OUT-OF-STOCK” switch will be triggered if the bar
clamp (feed vise) closes without material. When this occurs
the saw motor shuts off, the arm will retract and the indicator
light will illuminate. To clear the light and resume saw
operators press the spring-loaded “POWER” switch to the
“START” position.
Broken Blade Indicator
The Broken Blade light illuminates when the blade breaks or
the blade tension is reduced when changing blades. To reset
the Broken Blade function and clear the indicator light,
replace or tension the blade as required then move the spring-
loaded “POWER” switch to the “START” position.
