Heinner HVC-V1200BL Manuale utente

VACUUM CLEANER

Model: HVC-V1200BL

www.heinner.ro

•Vacuum cleaner

•Power: 1200W

•Suction power: 240W

www.heinner.com 1200W, 50Hz, 220-240V

Before using the appliance, please read carefully this instruction manual and keep it for future

reference.

This instruction manual is designed to provide you with all required instructions related to the

installation, use and maintenance of the appliance.

In order to operate the unit correctly and safety, please read this instruction manual carefully

before installation and usage.

I. INTRODUCTION

II. PACKAGE CONTENT

➢Vacuum cleaner

➢Floor brush

➢Nozzle

➢User manual

➢Warranty card

Va multumim pentru alegerea acestui produs!

www.heinner.com 1200W, 50Hz, 220-240V

III. DESCRIPTION OF THE APPLIANCE

1. Modern and elegant design

2. Multiple air-filter system guarantees a hygienic cleaning

3. Drivers accessories: floor brush, nozzle etc

4. User-friendly wire rewinder pedal

IV. KNOW YOUR VACUUM CLEANER

www.heinner.com 1200W, 50Hz, 220-240V

V. IMPORTANT SAFETY INSTRUCTIONS

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

If the supply cord is damaged, it must be replaced by the manufacture or its service

agent or a similarly qualified person in order to avoid a hazard. For household use

only.

Do not use for absorbing detergent, kerosene, glass, needle, cigarette ash, water,

match etc.

The appliance should not be exposed to heat

Unplug the appliance from the mains supply. Socket after use and before every

cleaning pull the mains cable, in order to disconnect the appliance from the mains.

www.heinner.com 1200W, 50Hz, 220-240V

Do not put any object into openings. Do not use with any opening blocked. Keep the

appliance free of dust, lint, hair etc.

Do not use the vacuum cleaner without dust container or dust filter in place.

Do not vacuum any flour, cement etc, in order to avoid the overloads.

The appliance should only be cleaned with a dry or damp cloth ,it should never

immersed in water. Do not use any solvents for cleaning.

www.heinner.com 1200W, 50Hz, 220-240V

VI. ASSEMBLY VACUUM CLEANER

Connect the hose with vacuum cleaner

Insert flexible hose into the air-intake: Press the knob until it clicks into the position

Remove the flexible hose: Unplug the appliance and press the knob at the end of

the hose. Remove it from the air-intake opening.

Fit the telescopic to the angled pipe.

Fit the floor brush to the telescopic tube.

www.heinner.com 1200W, 50Hz, 220-240V

VII. OPERATION

A yellow mark on power cord shows the ideal cable length. Do not expend the cable

beyond the red mark. To rewind the power cord, press the rewinder pedal with one

hand and guide the cord with the other hand.

Press the power switch to switch the appliance on. Use the electronic speed adjusting

to control the suction power of the cleaner.

The suction power can be adjusted with the sliding control on the angled pipe too.

Put the telescopic tube into the fixing hook of the appliance when you have a break.

Caution: Do not transfer the appliance when the fixing hook is used.

www.heinner.com 1200W, 50Hz, 220-240V

VIII. CLEANING TOOLS

Crevice tool:

For cleaning corner edge and draws etc:

Where is difficult to reach, such as gaps and the keyboard, bookshelf and windows.

Sofa brush: For cleaning bed, sofa, couch etc.

Use of the selector on floor brush: Bristles extended for carpets. Bristles retracted for

hard floors.

If the angled pipe has blockage. Insert it into the air-intake and switch the appliance

on.

www.heinner.com 1200W, 50Hz, 220-240V

IX. CLEANING AND MAINTENANCE

Empty the dust container

1. After removing the flexible hose ,press the cover lock button and open the

dust container.

2. Remove the dust filter from the container.

3. Replace the dust filter in the container.

4. Close the dust container until it is locked in the position.

Change filter

Replace the motor filter: Open the dust container and remove the motor filter. Fix

the new filter in the position.

Replace the outlet filter: Detach the grille by pulling firmly away from the appliance,

remove the outlet filter and replace the new filter. Fix the grille again.

Clean the filter: Clean the filter in water and allow them to dry completely before

replace them.

www.heinner.com 1200W, 50Hz, 220-240V

X. ERROR DETECTION

Before you contact our services center, please check the following points:

Problem

Possible reason

Active

Motor does not start

-Power card not firmly

plugged into outlet

-Outlet damaged

-Cleaner not switch on

-Plug unit firmly

-Check the outlet

-Switch on the

appliance.

Suction power is weaker

-unit clogged

-Dust filter needs

cleaning

-Dust container not in

position

-Filter blocked

-Remove the

blockage

-Clean the dust

filter

-Close the dust

container

-Clean the filter

The wire can not be winded

completely .

The wire may diverge the wire

wheel.

Draw the wire a

little then rewind.

The wire can not be draw out.

The wire may wind disorder

Press the rewinder

button and try

again.

Speed adjust does not work

Appliance is defective

Repair the

appliance

(only specialist)

Power card winds unwanted

back

Rewind mechanisms is

defective

Repair the

appliance

(only specialist)

The dust container can not be

closed

Dust filter is not in the

position

Fix the dust filter

and try again
