NOTICE

AXE100 CX

Instruction Manual

The instruction manual, warranties and other associated documentation are subject

to change without notice. Hobbico assumes no responsibility for inadvertent errors

in this manual.

Heli-Max products are to be used by ages 14 and over.

HMXE0818 Axe 100

HMXE0828 Axe 100

CX RTF

CX Tx-R

INTRODUCTION

Thank you for purchasing the Heli-Max AXE 100 CX Helicopter. We are certain

you will get many hours of enjoyment out of this model. If you should have any

questions or concerns please feel free to contact us at: helihotline@hobbico.com.

For the latest technical updates or manual corrections visit the Heli-Max web site

at www.helimax-rc.com. If there is any new technical information, changes or

important updates to this model a “tech notice” box will appear on the 100 CX

product page. Click the “tech notice” box to learn more about this important update.

All controls and responses from the AXE 100 CX are described with the tail pointing

directly toward you. This is the best way to ﬂy in the beginning since it keeps the

control inputs oriented in the same direction as the model will respond.

When you see this symbol, please pay special attention and

heed all warnings regarding the information within.

TECHNICAL SUPPORT

●Please note that we cannot provide any information on the pricing that you

will ﬁnd in your local retailer’s store for any products.

●If you need technical support or have any question, you can reach us by one

of the following means. When contacting us, please include the name of the

product you are referring to, its stock number and as much information about

your question or issue as possible.

●For support outside the U.S. or Canada, please contact the distributor in your

country. If unable to contact the appropriate distributor, please contact us.

However, we are unable to respond to emails in languages other than English.

EMAIL: helihotline@hobbico.com. Please be sure to list your full email

address (ex: [email protected]) as well as at least one other means of

daytime contact in your email.

TELEPHONE: 1-217-398-8970, Select option 5. Available Monday-Friday,

8am-5pm U.S. Central Time.

FAX: 1-217-398-7721. Please be sure to include a daytime telephone

number or return fax number so that we can contact you.

REGULAR MAIL: If you prefer, we can always respond with a regular

mailed letter. Simply write to us, including a brief explanation of your

problem or question along with the product name.

WARRANTY

Heli-Max guarantees this kit to be free from defects in both material and

workmanship at the date of purchase. This warranty does not cover any component

parts damaged by use or modification. In no case shall Heli-Max’s liability

exceed the original cost of the purchased kit. Further, Heli-Max reserves

the right to change or modify this warranty without notice. In that Heli-Max has

no control over the final assembly or material used for final assembly, no liability

shall be assumed nor accepted for any damage resulting from the use by the

user of the final user-assembled product. By the act of using the user assembled

product, the user accepts all resulting liability. If the buyer is not prepared to

accept the liability associated with the use of this product, the buyer is

advised to return this kit immediately in new and unused condition to the

place of purchase.

To make a warranty claim, Hobby Services 217-398-0007

send the defective part or 3002 N. Apollo Dr., Suite 1

item to Hobby Services Champaign, IL 61822

at this address. USA

Include a letter stating your name, return shipping address, as much contact

information as possible (daytime telephone number, fax number, e-mail address),

a detailed description of the problem and a photocopy of the purchase receipt.

Upon receipt of the package the problem will be evaluated as quickly as possible.

CONTENTS

AXE 100 CX Helicopter

TX 410 4-Channel SLT Transmitter

Heli-Max 150mAh LiPo Battery pack (1)

USB Charger

Small Phillips screwdriver

AA Batteries (4, not included in the Tx-R version.)

SPECIFICATIONS

Rotor Diameter: 190mm (7.48")

Empty Weight: 28.2g (.995 oz)

Weight RTF: 31.9g (1.25 oz)

Fuselage Length: 220mm (8.66")

Height: 126mm (4.96")

Width: 45mm (1.8")

AXE100 CX RTF

OPERATIONAL WARNINGS

●Failure to follow these safety precautions may result in injury to yourself

and others.

●Your AXE 100 CX should not be considered a toy. It should be treated as a

working model that functions much like a full-size helicopter. Keep your face

and body as well as all spectators away from the rotating blades whenever

the battery is connected. Keep loose clothing, shirt sleeves, ties, scarfs, long

hair or loose objects such as pencils or screwdrivers that may fall out of shirt

or jacket pockets away from the rotors. The spinning blades of a model of

this type can cause injury.

●When choosing a ﬂying site stay clear of buildings, trees and power lines.

AVOID ﬂying in or near crowded areas.

●DO NOT ﬂy close to people or pets. Maintain a safe distance from the helicopter.

●Do not alter or modify the model. Doing so may result in an unsafe or unﬂyable

model.

●When repairs are necessary you should correctly install all components so

that the model operates properly on the ground and in the air. Please check

the operation of the model before every ﬂight to insure that all equipment is

operating and that the model has remained structurally sound.

●Please allow a 10 minute cool down period after each ﬂight so the motor

controller and motors can cool down. Failure to do so may cause loss of

control due to the controller overheating and shutting down.

●Inspect the rotor blades before each ﬂight for nicks. If the blades have been

damaged, replace them before ﬂying the model again. Be sure to check

linkages or other connectors often and replace them if they show any signs

of wear or fatigue.

●After a crash you should inspect all plastic parts on the helicopter for damage

before attempting to ﬂy the model again.

BATTERY CHARGING

●Please read and understand the following regarding the usage of LiPo

batteries.

●Through the use of the included LiPo battery you have assumed all risk and

responsibility regarding a LiPo battery and its use.

●ALWAYS unplug your battery from the helicopter after use.

●ALWAYS recharge the batteries before storage to prevent the voltage from

dropping below the 3.0 volts.

●It’s best to store your batteries charged and at room temperature.

●Never disassemble, puncture or modify the battery pack in anyway.

●Never allow the battery temperature to exceed 150° F [65° C].

●If your battery begins to swell or becomes damaged in any way, stop using

it. Contact Hobby Services at 217-398-0007 to learn the proper way to dispose

of your battery.

●Only use the included charger with the included LiPo battery. Do not attempt

to use the provided charger with NiCd, NiMH or batteries with other chemistries.

●Do not leave the charger unattended while in use and always charge your

battery in a ﬁre-resistant location.

●Disconnect the battery and remove input power from the charger immediately

if either becomes hot!

●Do not allow water or other foreign objects to enter the charger. Keep the

charger away from moisture and do not submerge in water.

●Please keep all electronic components out of the reach of children!

Plug charger into a USB port. A steady red light will glow letting you know the

battery is charging. The light will flash slowly when the charge is complete.

Remove the battery from the charger. Under normal operating conditions, the

battery may take up to 60 minutes to recharge. Never leave the battery attached

to the charger after charging is complete.

NOTE: A fast flash indicates a charge error. This is usually an indication that

your battery is defective and should be replaced.

WARNING!! The charger supplied with the Heli-Max AXE 100 CX

helicopter contains protective circuitry. If you experience any

difﬁculties while charging the battery, please disconnect the battery

from the charger and unplug the charger from the power source.

Allow the battery and charger to rest for two hours as this will allow the charge

protection circuit to reset. If this issue re-occurs during normal use, please

contact our Technical Support Department for assistance.

TRANSMITTER (RTF Model)

Please fully read the transmitter manual included with

your helicopter to learn more about how to use and

adjust your TX410.

TRANSMITTER SETUP AND CONTROLS

Remove the battery cover from

the back of the transmitter and

install the four “AA” batteries.

Double-check the polarity of each

battery before replacing the

battery cover.

Turn the transmitter on and make

sure that there is a blue light

behind the Heli-Max panel at the

top of the transmitter. The LCD

screen should be on with a throttle

position indicator and other

information.

The transmitter can now be turned

off until the model is ready for

flight.

DUAL RATES

The transmitter has a dual rate

function. This feature toggles

between a flight mode that reduces

the model’s range of motion to make

the AXE 100 CX easer to fly and one

that allows the full range of motion

so the AXE 100 CX can fly in a more

aggressive manner. To toggle

between these two flight modes,

press down on the right control stick

and release it. When the transmitter

is in low rates, the ellipse in the lower

center of the LCD screen will show a half ellipse and emit a single low pitch

single beep. For high rates, the ellipse will be complete and the transmitter

will emit a single high pitch beep.

SERVO REVERSING

This transmitter uses the Tactic SLT protocol and can be used with other

SLT receivers. In those applications, it may be necessary to reverse the

servo travel direction as follows:

With the transmitter OFF, push and “hold”

the rudder trim button to the right and

the throttle trim button down. Then turn

ON the transmitter.

Let go of the trim buttons and you will

see 1-1 or 1-0 displayed. The first Digit

is the channel number. To change the

channel you want to reverse, push down

on the right stick. To reverse the travel

direction, push the elevator trim button

up or down so the second number

changes. The V-Cam travel direction

settings should be “1” for all channels.

To confirm the change and exit to normal

operation, push down on the left stick.

The changes will not be saved if the

power is turned off before the left stick

assembly is pushed down.

TRANSMITTER (Tx-R Model)

Your AXE 100 CX uses the Tactic protocol. With the

simple addition of the Tactic Anylink™to your favorite

transmitter, be it Futaba

, JR

, Spectrum

or other

compatible system, you can fly your Heli-Max AXE 100

CX with a familiar transmitter. Any other SLT compatible aircraft transmitters

like the Tactic TTX402/TTX403 can also be used with the 100 CX.

The following setup guides for Futaba, Spektrum, and Tactic systems should

work for most transmitters that are currently available. You may find that you

need to set the servo travel for the throttle channel to maximum so the ESC on

the AXE 100 CX will arm.

AXE 100 CX Futaba

Type

Swash

Reverse (REVR)

Dual Rates (D/R)

Exponential (EXPO)

Timer (TIMR)

AILE

ELEV THRO RUDD

234

HELI

7 Min

NNNN

140/100 140/100 140/100

–10 –10 –10

H-1

AXE 100 CX Spektrum

Type

Swashplate Type

Reverse

Dual Rates (D/R)

Exponential (EXPO)

Timer

THRO

AILE ELEV RUDD

234

HELI

7 Min

RRRR

100/80 100/80 100/80

+10 +10 +10

90 degree

AXE 100 CX Tactic TTX 650

Type

Swash

Reverse (REVR)

Dual Rates (D/R)

Exponential (EXPO)

Timer (TIMR)

AILE

ELEV THRO RUDD

234

HELI

7 Min

NNNN

100/80 100/80 100/80

–10 –10 –10

1 Servo

Please verify that the servos respond to the controls as described in the next

section of the manual.You may need to reverse one or more channels to make

the servos respond correctly.

™

Indice

Altri manuali Heli-Max Giocattolo

Heli-Max

Heli-Max EC145 Manuale utente

Heli-Max

Heli-Max MD530 2.4GHz RTF/Tx-R Manuale utente

Heli-Max

Heli-Max Axe 100 FP 2.4GHz RTF Manuale utente

Heli-Max

Heli-Max Novus AH-1J SeaCobra Manuale utente

Heli-Max

Heli-Max RotoFly Manuale utente

Heli-Max

Heli-Max Comanche CX Manuale utente

Heli-Max

Heli-Max AXE 400 3D Rx-R Manuale utente

Heli-Max

Heli-Max MX400 PRO Manuale utente

Heli-Max

Heli-Max Novus 125 CP Manuale utente

Heli-Max

Heli-Max AXE100CP Manuale utente

Heli-Max

Heli-Max Axe CX Micro Manuale utente

Heli-Max

Heli-Max 2000FP V-Cam Manuale utente

Heli-Max

Heli-Max Novus UH-1D HUEY Manuale utente

Heli-Max

Heli-Max AXE Mini EP RTF Manuale utente

Heli-Max

Heli-Max Kinetic 50 Manuale utente

Heli-Max

Heli-Max 1SQ V-cam Manuale utente

Heli-Max

Heli-Max Novus FP Manuale utente

Heli-Max

Heli-Max MX400 PRO Manuale utente

Heli-Max

Heli-Max AXE100 SS Manuale utente

Heli-Max

Heli-Max Novus CP Manuale utente

Heli-Max

Heli-Max BLACK HAWK Manuale utente

Heli-Max

Heli-Max AXE CX Nano Manuale utente

Heli-Max

Heli-Max AXE CPv3 Manuale utente

Heli-Max

Heli-Max AXE CP-L Manuale utente

Manuali Giocattolo popolari di altre marche

marklin

marklin 37321 Manuale utente

Canon

Canon PAPER CRAFT Manuale utente

GREAT PLANES

GREAT PLANES Pitts M-12S Manuale utente

NOCH

NOCH 14261 Manuale utente

Hausler

Hausler 450 SE V2 Manuale utente

Dynaflite

Dynaflite Daydream Manuale utente

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuale

Kenner

Kenner Batman 63651 Manuale utente

LEGO

LEGO 8527 Manuale utente

iKarus

iKarus ECO 8 Manuale utente

Multiplex

Multiplex EasyStar II Manuale di istruzioni

Walkera

Walkera 38 Manuale di istruzioni

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuale utente

MD MXION SWD Manuale utente

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuale utente

marklin

marklin 39671 Manuale utente

Meccano

Meccano 15103 Manuale utente

LEGO

LEGO TECHNIC 8735 Manuale utente
