i.C³® User Guide
For Helmer i.Series®Incubators
360406/A
Countertop
PC100-Pro, PC900-Pro,
PC1200-Pro
Document History
Revision Date CO Supersession Revision Description
A 27 JUN 2019 14808 n/a Initial release.
* Date submitted or change order review. Actual release date may vary.
Document Updates
The document is furnished for information use only, is subject to change without notice and should not be construed as a commitment
by Helmer Scientic. Helmer Scientic assumes no responsibility or liability for any errors or inaccuracies that may appear in the
informational content contained in this material. For the purpose of clarity, Helmer Scientic considers only the most recent revision of
this document to be valid.
Support Information
Operation and Service Manuals provide additional product information. Product manuals are available at www.helmerinc.com.
Notices and Disclaimers
The i.C³® User Guide provides information about use of the i.C³. Refer to the product operation or service manual for general
information. Refer to the product service manual for additional information about the equipment on which the i.C³ is installed.
Condential / Proprietary Notices
Use of any portion(s) of this document to copy, translate, disassemble or decompile, or create or attempt to create by reverse
engineering or otherwise, the information from Helmer Scientic products is expressly prohibited.
Copyright and Trademark
Copyright © 2019 Helmer, Inc. Helmer®, i.Series®, and i.C³®, are registered trademarks of Helmer, Inc. in the United States ofAmerica.
Helmer, Inc., doing business as (DBA) Helmer Scientic and Helmer.
Disclaimer
This manual is intended as a guide to provide the operator with necessary instructions on the proper use and maintenance of certain
Helmer Scientic products.
Any failure to follow the instructions as described could result in impaired product function, injury to the operator or others, or void
applicable product warranties. Helmer Scientic accepts no responsibility for liability resulting from improper use or maintenance of its
products.
The screenshots and component images appearing in this guide are provided for illustrative purposes only, and may vary slightly from
the actual software screens and/or product components.
Helmer Scientic
14400 Bergen Boulevard
Noblesville, IN 46060 USA
www.helmerinc.com Part No. 360406/ Rev A
Contents
1 Overview ...........................................................................................4
Features............................................................................................4
Using the Touchscreen.................................................................................5
Care of the i.C3Screen.................................................................................5
2 Initial Setup.........................................................................................6
Language Conguration................................................................................6
Settings Conguration .................................................................................6
3 Home Screen Basics .................................................................................7
Home Screen Layout ..................................................................................7
Home Screen Icons and Indicators .......................................................................7
4 i.C3Applications (APPS) ..............................................................................8
Using i.C3 Applications .................................................................................8
5 Temperature Alarm Test.............................................................................. 10
6 Min/Max Temperature Monitoring ...................................................................... 11
7 Temperature Graph .................................................................................12
Event Data .........................................................................................13
Viewable with the 1-Day Time Span......................................................................13
8 AgiTrak (if installed)..................................................................................15
Agitator Status ......................................................................................16
Agitator Count Log ...................................................................................17
Agitator Diagnostics ..................................................................................17
9 Information Logs ...................................................................................18
Event Log..........................................................................................18
Event Log Detail Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Access Control Log (if installed).........................................................................20
10 Data Transfer ......................................................................................22
CSV Download......................................................................................22
Downloading Temperature Graphs and Alarm Event Data to PDF ..............................................24
Uploading Firmware Updates...........................................................................25
11 Customizing the i.C3Screen ..........................................................................27
Brightness Settings ..................................................................................27
Home Page Screensaver ..............................................................................27
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
ii
12 i.C3 Settings .......................................................................................28
Password Protection of the i.C3Settings Screen ............................................................28
Temperature Setpoint .................................................................................29
Alarm Settings ......................................................................................29
Users and Passwords ................................................................................30
Sound Settings......................................................................................31
Display Settings .....................................................................................32
Device Status.......................................................................................33
Sensor Calibration ...................................................................................34
Date/Time..........................................................................................34
Auxiliary Systems....................................................................................35
Restore Factory Settings ..............................................................................35
System Functions....................................................................................36
13 Access Control (if installed) ...........................................................................37
Access Control Setup.................................................................................37
Access Control Screen................................................................................38
Access Control as the Home Screen .....................................................................39
14 Icon Transfer.......................................................................................40
Appendix A - Icon Reference Guide........................................................................41
Common Buttons ....................................................................................41
Application Icons ....................................................................................42
Appendix B - i.C3 Reference Guide ........................................................................43
General Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Alarm Settings ......................................................................................45
Event Log Codes ....................................................................................46
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
iii
1 Overview
Cautions
• To avoid injury, before using the i.C3 User Information Center, read all instructions in the associated product
operation manual.
• To avoid damage to the i.C3 unit, read all instructions provided in this user guide.
Features
The i.C3® consists of an intuitive user interface and icon-driven touchscreen. The touchscreen is contained within the
instrument bezel, as are additional features.
Touchscreen
The interface to the i.C3system.
USB Port
Connect a ash memory device to download temperature data or upload rmware.
Ethernet/RJ45 Connection (Not shown)
Allows the system to provide and receive data or commands to and from external devices.
Audio Speaker
Provides an audible signal when alarm conditions are met. Also provides audible signal when screen icons and
buttons are touched.
Touchscreen
Audio Speaker
(boom of bezel)
USB Port
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
4
Using the Touchscreen
The touchscreen and touch techniques make the i.C3easy to use. Icons, status indicators, and navigation buttons let
the user see and respond to i.C3system conditions and events.
Note
Anything that touches the screen is understood as a command. Do not let anything touch the screen unintentionally.
Touch Techniques
Touch-select Touch once to select an item.
Touch-drag To move an item, touch-hold to select the item and drag it to a new location. Use a deliberate
touch-drag motion (without lifting)
Touch-scroll To scroll, slide nger slowly across the screen (horizontal or vertical). Stop before lifting. For
more control while scrolling, keep your nger in contact with the screen.
Icons, Indicators, and Buttons
For a complete list of all icons and indicators, see the Icon Reference Guide at the end of this user guide.
Application icons serve as navigation buttons to the associated application screen.
Status indicators alert the user to a change of status.
Navigation buttons return the display the previous screen or the Home screen.
Care of the i.C3Screen
CAUTION
The iC3screen uses a sensitive touch technology.
• To avoid damage to the touchscreen, do not apply pressure on the front of the display bezel or around the
screen borders.
• To preserve optimal touch sensitivity, keep the screen clean of foreign objects. Avoid excessive dust accumulation
on the screen.
• Do not expose the i.C3 screen to liquids or a harsh environment that contains excessive dust, heat or humidity.
• Clean the i.C3screen with a clean, dry cotton cloth.
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
5
2 Initial Setup
Language Conguration
The Language screen is displayed when the i.C3 is powered on. Use the Language screen to select the i.C3 display
language.
Choose language
1. Touch the Language button. The language drop-down list is displayed.
2. Scroll to touch the language to be displayed. The selected language is displayed in the Language button.
3. Touch to conrm language selection, or to cancel.
4. Touch the Home icon to continue to the Home screen.
Note
English is the default language. Available languages may vary from those shown above.
Settings Conguration
Basic conguration parameters have been set for the i.C3 at the factory. If factory default settings need to be adjusted,
refer to i.C3Settings.
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
6
3 Home Screen Basics
Note
To temporarily silence active alarms, touch the Mute icon in the top right corner of the screen.
Home Screen Layout
The i.C3 Home screen is comprised of three information areas:
Information header - The dark blue horizontal band across the top of the Home screen. This header is displayed on all i.C3
screens. From left to right it includes: the Event Log icon, Screen ID, Unit ID, Date/Time, Battery indicator, and Mute icon.
Display zone - The middle band of the screen which includes information indicators and messages. From left to right, they
are: Status display; Alarm Conditions indicator and Alarm Conditions message; Primary Monitor Probe display; Min/Max
Temperature Display (if enabled).
Notes
• Primary Monitor Probe refers to the monitoring probe located on the right side of the chamber.
• Min/Max temperature display shows the highest and lowest Primary Monitor probe temperature occurrence within a
given period of time.
Application icons - Icons located at the bottom of the screen which include ve factory-preset application icons. From left to
right they are: i.C3 Applications (APPS), Settings, Temperature Graph, Automatic Alarm Test, and AgiTrak. These icons can
be changed or rearranged through the Icon Transfer feature. For more information refer to Icon Transfer.
Notes
• After two minutes of no interaction, the Temperature Graph screensaver is displayed (if enabled).
• Additional applications are available on the i.C3 APPS screen.
Home Screen Icons and Indicators
Touch the Event Log icon to
navigate to the Event Log screen. Touch the Reset icon to reset the
Min/Max display. Time since last
reset will be displayed.
Look for the New Event indicator
(red asterisk).
Touch the Mute icon to temporarily
silence alarm sound.
Screen ID
Unit ID
Event Log Icon-Indicator
Display Zone
i.C³ Applicaons
Primary Monitor Probe
Informaon Header
Alarm Condion Indicator
Alarm Condion Message
Min/Max Temperature Display
Min/Max Reset
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
7
4 i.C3Applications (APPS)
All i.C3 Applications can be reached from the i.C3 APPS screen.
Notes
• i.C3 Applications screen icons are interchangeable with those found on the Home screen.
• Primary Monitor probe reading and alarm conditions are displayed on the left side of the screen.
Using i.C3Applications
To navigate to an application screen, touch the associated application icon.
Contact Information
View product support information including the rmware revision numbers.
i.C3 Settings
All i.C3 system settings are congured and other preferences selected from the i.C3Settings screen.
Note
The i.C3 Settings screen is password protected, unless password protection is turned O (from the i.C3 Settings screen).
If accessing the i.C3 for the rst time, use the factory-originated password (1234).
Brightness Settings
Adjust monitor screen brightness.
Icon Transfer
Reposition application icons on the Home and Applications screens.
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
8
Information Logs
Access all available data log applications.
Temperature Graph
View current and historical probe temperature data and alarm events.
CSV Downloads
Download information log(s).
PDF Downloads
Download historical information as a PDF.
Uploads
Upload rmware updates.
Alarm Test
Initiate automatic alarm tests for the high and low temperature alarms.
AgiTrak
Control agitator speed and view current agitator status.
Access Control (if installed)
Display keypad for incubator access.
Helmer Scientic i.C3 User Guide for i.Series Incubators
360406/A
9
Altri manuali per i.C3
3
Indice
Manuali Apparecchiature di registrazione popolari di altre marche
Strymon
Strymon NIGHTSKY Manuale utente
Mitsubishi Electric
Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuale utente
Tews Technologies
Tews Technologies TPMC465 Manuale utente
Honeywell
Honeywell Excel 50 Manuale utente
SeaLevel
SeaLevel COMM+8.LPCI Manuale utente
Arturia
Arturia AUDIOFUSE STUDIO Manuale utente
