Hercules AIR+ Manuale utente

GETTING STARTED WITH DJCONTROL AIR+ AND DJUCED™ 40°

1/10 2/10

1 -

CONNECTING HEADPHONES,

A MICROPHONE

AND SPEAKERS

When connecting headphones, make sure that the volume level is suitable

for listening with headphones: start playing a music track before putting

on the headphones, and turn down the volume if it seems that the sound

coming from the headphones is too loud.

Microphone: you can only connect a balanced microphone, such as a dynamic

balanced microphone.

FRONT PANEL: HEADPHONES AND MICROPHONE

REAR PANEL: SPEAKERS

INSTAllATION

• Run the installer program.

• Follow the instructions.

• Insert the CD-ROM.

The DJControl AIR+ drivers and control panel software are installed on your system,

along with the DJUCED™ 40° software.

The DJControl AIR+ control panel:

1- Main tab

2- Output balance (left/

right) for channels

3- Volume on channels

1-2 and 3-4

4- Unlock/lock right and left

channel volume

5- Mute on/o

6- Adjust talkover

attenuation level

7- Disable/enable proximity

sensor

8- Set jog wheels (disable/

enable and set sensitivity)

9- Select MIDI resolution

More information (forum, tutorials, videos...) available at

www.HERCUlESDJMIXROOM.com

Please note that the DJControl AIR+ control panel may dier slightly on Mac.

3/10 4/10

3 -

MONITORING A TRACK

Monitoring lets you prepare the next

track to be played (following the track

that you are currently playing for your

audience). You will use monitoring to

beatmatch the next track to be played,

or pause the track at a precise spot so

that playback will start from this exact

position. Or you can place a HotCue

point, which will let you start playback

of the track from that point (please also

see section 6 – WORKING WITH HOTCUE

POINTS).

3.1 You are playing a track on deck A, and

want to monitor the next track on deck B.

3.2 Press the Cue button before you start

playing the track to be monitored.

3.3 Press the Headphones button on deck

B (the deck on which the track that you

want to monitor is loaded).

3.4 Adjust the volume on your headphones

using the headphones volume knob.

3.5 Start playing the track to be monitored

on deck B. Prepare the track (beatmatch

the track, place a HotCue point...).

2 - lOADING YOUR MUSIC

IN DJUCED™ 40°

Use the Files / Folders rotary browser knob to browse through

les and folders.

Browse through the list of

folders or through les:

Press the browser knob to

toggle between folders/les:

Press the Load A or Load B buttons to enter/exit

the selected folder, or load the selected le on the

corresponding deck:

2.1 Browse to the location where your music les are stored on your computer.

2.2 After highlighting a track, press Load A to load the track on deck A, or press Load B

to load the track on deck B. DJUCED™ 40° automatically analyzes the BPM (number of

beats per minute) of the track you have loaded.

DJUCED™ 40° lets you play the most popular audio le formats (mp3, wav, wma, aif...)

if the codec is installed on your computer. If a le format is not properly recognized

in iTunes, Windows Media Player... update your version of the software in question.

LOAD A LOAD B

5/10 6/10

5 -

SCRATCHING

ON A TRACK

5.1 Make sure that the Vinyl button is lit up,

so that you are in Scratch mode.

5.2 Start playing a track loaded on deck A,

for example.

5.5 ... and gently turn the jog wheel to the

right and to the left, in succession.

5.3 Place your hand on the jog wheel on

deck A, as shown in the illustration.

5.4 Press down slightly on the jog wheel...

4 -

MIXING TRACKS

Mixing tracks means to link up songs,

one after another, without any gaps or

silences between them.

4.1 You have loaded a track onto each deck

(A and B). Position the volume faders as

shown below.

4.2 You start o by playing the track on

deck A.

4.3

Set the crossfader to the side of the deck

on which the track is playing (here, to the left).

4.4 Press the Mix button on the front

panel. The sound that will be played for

your audience on the speakers will be the

same as the sound being played on your

headphones.

Adjust the volume on your headphones

using the headphones volume knob.

4.7 To make the transition, progressively

move the crossfader toward the deck on

which the new track is being played (here,

to the right).

When there are 30 seconds remaining

until the end of the track, an alert is

displayed to let you know that it's time

to get ready to play the next track.

4.5

Before the end of the track being played,

start playing the track loaded on deck B.

4.6

To ensure a transition at the same tempo,

synchronize the BPM (number of beats per

minute) of the track that you are getting

ready to play. Here, press the Sync button on

deck B (1), so that the BPM value of this track

will match the BPM of the track that is about

to nish (on deck A). Or set the same BPM as

on Deck A using the pitch fader (2).

A B

1 2

7/10 8/10

8 -

WORKING WITH EFFECTS

8.1 Applying an eect on a track that has been loaded and is being played:

Make sure that the Bank1button is on. Press button(s) 1, 2and/or3 to toggle the corresponding

eect(s) on or o. Press button 4 to toggle MacroFx (a combination of eects) on or o.

The Mapping tab in the SETTINGS panel of the DJUCED™ 40° software lets you choose

from among the dierent mapping congurations available for eects and loops.

The corresponding eect is displayed in DJUCED™ 40°, and is applied to the track being played.

7 -

WORKING WITH SAMPlES

Playing a sample on a track that has

been loaded and is being played:

7.1 Make sure that the HotCue/Sample

button is on (this is Sample mode).

7.2 Tap on one or more pads to trigger

the samples (a short snippet of music or

sound). The more pressure you apply on

the pad, the louder the volume of the

sample played will be; however, you can

disable this velocity-dependent aspect

in the control panel, if you prefer. When

a sample is triggered on a pad, the pad

stays lit up the same amount of time as the

sample length: perhaps one second, for a

short sound like a drum hit; a few seconds,

for a sample of music (for example).

6 -

WORKING WITH HOTCUE POINTS

A HotCue point is a marker that you can place in a music track. It lets you start

playback of the track from that point.

6.1 Make sure that the HotCue/Sample

button is o (this is HotCue mode, the

default mode).

6.2 You can place up to 4 markers, known as HotCue points: press pad 1 to place HotCue 1,

pad 2 to place HotCue 2, etc. Once this is done, when you are in HotCue mode simply press

one of pads 1 to 4 to access the corresponding marker in the track.

When you press the Cue button, playback starts from the last HotCue point you have

placed in the track.

6.3 To delete a HotCue point: when in HotCue mode, press the Shift button and press

the pad associated with the HotCue point that you want to delete. Or you can click on the

Minus sign button (in the DJUCED™ 40° software) to delete the corresponding HotCue

point.

9/10 10/10

10 - USING THE AIR CONTROl

11 - CREATING A PlAYlIST

10.1 In the DJControl AIR+ control panel, make sure that the proximity sensor (air

control) is enabled.

A playlist is a set of tracks that you choose to group together – as part of a specic

genre (electro, rock...) or theme (favorites, party, birthday, 80s...).

10.2 Make sure that the Bank 1 button is on. Press and

hold button 1, 2, 3 or 4and move your hand above

the proximity sensor at the same time to modulate the

amount of the eect applied.

11.2 Click the button to create a playlist.

Enter a name for the playlist, then click OK.

11.1 Highlight one of the tracks

that you want to add to the

playlist, using the Files / Folders

rotary browser knob:

The new playlist appears in the Playlists folder.

11.3 Return to the folder containing your

music, using these controls:

11.4 In DJUCED™ 40°, select one or more

tracks using your mouse.

By holding down the SHIFT key on your

computer's keyboard, you can select

several consecutive les.

Drag and drop the selected les into the

play list you have created (here, “My Playlist”).

The button appears on the left.

9 -

WORKING WITH lOOPS

9.1 Looping in or out

Make sure that the Bank 2 button is on.

Then press button 1 to set the loop’s start point, and button 2 to set the loop’s end point.

Use the vertical lines in DJUCED™ 40° (1 line = 1 beat), as well as the music being played, to

help you determine the best place for the end of the loop.

9.2 Increasing or decreasing the length of the loop

Make sure that the Bank 2 button is on. Then press button 3 to divide the length of the

current loop in half, or button 4 to double the length of the loop.

Press the MAGIC button to instantly split the current loop into 4 parts, and

assign the parts of the loop to the 4 pads. If you press the MAGIC button without

having a current loop, nothing will happen and a message will be displayed at the

bottom of the DJUCED™ 40° window, instructing you to rst create a loop before

you can generate samples.

DJUCED™ 40° plays a part of the track as a loop.

2X2
