HH Electronics TENSOR-MINI Manuale utente

USER MANUAL


Page 1

CONTENTS
TENSOR-MINI OVERVIEW................................................................................................................................. 2
FEATURES ......................................................................................................................................................2
CONTROLS......................................................................................................................................................... 3
CHANNEL 1 & 2............................................................................................................................................. 3
LINE OUT & CHANNEL 3..............................................................................................................................4
BLUETOOTH AND USB CONTROLS .......................................................................................................... 5
MAINS INLET .................................................................................................................................................5
SETUP .................................................................................................................................................................. 6
MULTI-POSITION ..........................................................................................................................................6
BLUETOOTH CONNECTIVITY.....................................................................................................................6
USB PLAYBACK .............................................................................................................................................8
EQ SETTINGS.................................................................................................................................................9
BATTERY LEVEL............................................................................................................................................. 9
SPECIFICATIONS .............................................................................................................................................10
DIMENSIONS (in mm).................................................................................................................................11
SAFETY AND WARNINGS...............................................................................................................................12




Page 2

TENSOR-MINI OVERVIEW

The ultra portable Tensor-MINI is an easy to carry, lightweight, high power PA loudspeaker with built

in Li-Ion Battery. The versatile preamp includes a 3 channel mixer, DSP and reverb effects along with a

Bluetooth/USB media player. Bluetooth also supports stereo linking of two units. The multi-angle

cabinet can be used on the ground, as a monitor or on a pole stand and the user controlled EQ

adjustment ensures you can always get optimal sound quality. The Tensor-MINI is ideal for

Performers/Vocalists/Parties and more.

FEATURES

•Ultra compact, lightweight design

•6.5” Co-Axial full range driver

•High power amplifier

•3 channel Mic/Line/Instrument mixer with reverb

•Bass/Treble control

•Internal Li-Ion battery powered

•Media player with Bluetooth audio streaming and stereo linking

•USB media player capabilities

Page 3

CONTROLS

CHANNELS 1 & 2

1. XLR/6.3mm COMBI SOCKETS

Channel 1 and 2 inputs take either XLR or 6.3mm jack. Can connect balanced or unbalanced signals.

2. TONE PRESET SWITCH

Select between Mic, Instrument or Line mode for the channel.

3. REVERB LEVEL

Set the reverb level for the respective channel (available on 1 and 2), current level will show on the

LCD below. Push this to instead edit the bass/treble levels for the channel, again visible on the LCD.

4. VOLUME LEVEL AND SIGNAL INDICATOR

Volume level controls the preamp gain for that channel. Set to minimum when first setting up and

increase gradually to a suitable volume.

Signal indicator LED shows green when a signal is present on the channel and red when the signal is

clipping. Occasional red flashes are ok but avoid constant illumination of the red light. Turn the

volume down on your device or the MINI if so.

Page 4

LINE OUT & CHANNEL 3

5. LINE LEVEL OUT

6.3mm line level output to link to other devices. This will be the same mix of all 3 channels that plays

out of the speaker but at a line level. Also the output for this is post EQ so the bass, treble and reverb

settings will be applied.

6. AUX INPUT

3.5mm stereo aux socket. A line level input for audio use.

7. VOLUME LEVEL AND SIGNAL INDICATOR

Control the volume for the aux input as well as the USB and Bluetooth inputs.

Signal indicator LED shows green when a signal is present on the channel and red when the signal is

clipping. Occasional red flashes are ok but avoid constant illumination of the red light. Turn the

volume down on your input device or the Tensor-MINI if so.

Page 5

BLUETOOTH AND USB CONTROLS

8. USB SOCKET

Connect your mobile phone or USB flash drive here to use USB channel of the Tensor-MINI.

9. PLAYBACK CONTROLS

Used to control the playback for USB and Bluetooth audio, cycle through USB folders, set the mode

for channel 3 and enter EQ adjustment. For more info see USB Playback (Page 7).

10. LCD

Display screen for outlining Bluetooth and USB playback as well as indicating EQ settings.

MAINS INLET

11. POWER SWITCH

Turns the system on and off. It is good practice to keep the master

volume at minimum when switching on and off.

12. C7 IEC MAINS SOCKET

C7 type IEC input to connect with the provided mains lead. Accepts

universal voltage 100-240V~.

Page 6

SETUP

MULTI-POSITION

Depending on your use case, the Tensor-MINI can be used in various positions:

BLUETOOTH CONNECTIVITY

To connect a device, such as a mobile phone, press the MODE button so

that the letters “bt” show on the LCD display, alongside a flashing

Bluetooth symbol on the bottom left. The MINI is now looking for a device

to pair to.

On your device’s Bluetooth settings, find the device named “TENSOR-

MINI” and connect to it. Upon pairing, the Bluetooth logo will stop flashing

to signal a connection.

Songs can be paused/resumed with the play/pause button and

skipped/backtracked using the forward/backward buttons.

To unpair from a Bluetooth connected device, simply hold down the Play/Pause button for approx. 1-

2 seconds. Will only work whilst in Bluetooth mode.

Page 7

To connect two Tensor-MINIs via TWS, have both speakers on Bluetooth mode and hold the shuffle

button on one for 3 seconds to enter pairing mode. The screen will show “bt –n”.

Hold down the same button on the other unit to activate TWS on it. Both Tensor-MINIs will pair

together and their screens will show “bt-L”and “bt-R”to indicate the left and right channels.

When they’re linked, you can pair your mobile device as usual.

Page 8

USB PLAYBACK

A USB flash drive can be plugged into the USB socket on the back of the

MINI to play audio from. The USB can contain multiple folders of music that

can be played individually or shuffled together.

Use the “MODE” button to cycle between the Bluetooth input and the USB

input for channel 3. If nothing is plugged into the USB socket, or if the

device is not compatible, “NO” will appear on the LCD.

With usable USB plugged in, the word USB will show as well as the runtime

of the current audio track.

Whilst in USB mode, cycle through the tracks in the current folder using the

forward/backward buttons on the right. Pause or resume the current track with the play/pause button.

By holding the play button for 1-2 seconds, it is also possible to navigate through the USB folders via

the forward/backward buttons.

The shuffle button will cycle through different playback modes, with the currently selected mode

displayed on the LCD when pressed. “ALL” will play through all tracks available. “ONE” plays the

current track then stops. “RAND” is a random shuffle of the available tracks.

Page 9

EQ SETTINGS

All 3 channels can have their own bass, treble and reverb settings

modified through the controls on the Tensor-MINI.

For channels 1 and 2, push in the reverb knob to modify the EQ for the

respective channel. For channel 3, hold the “MODE” button for 1-2

seconds until the “H” (high frequency level) shows on the LCD. The current

set level shows on the right hand side and can go from -10 to +10. A

minus sign appears to the right of the “H” to indicate a negative value.

Use the reverb knob or the rewind/skip buttons to increase or decrease

the value.

Press the reverb knob (CH1/2) or ”MODE” (CH3) button again to change

the bass/low frequency level, again ranging from -10 to +10.

Press the reverb knob again (CH1/2 only) to modify the reverb –“RE” level

of the channel. This ranges from 0 to +16.

BATTERY LEVEL

The battery level and charging status are both indicated by the LED found on the top of the Tensor-

MINI. Be sure to keep an eye on this display whilst in use, especially if the power cable is not

connected.
