Hiboy DK1 Manuale utente

Electric Dirt Bike

DK1

USER MANUAL

The manufacturer reserves the right to make changesto the product，

and update this manual at any time.

www.hiboy.com

Contents 1. Package Contents

Carefully check package contents, if anything is missing or

damaged, please contact Hiboy customer service for support:

[email protected]

Charger x 1pcs

M6 hexagon

wrench x 1pcs

User manual x 1pcs

10. Limited Warranty Statement

9.Specifications

8.Daily Care and Maintenance

7.Dangerous Actions (No attempting!)

6.Riding Notice

5.Riding Basics

4.Charging

3.Assembly

2.Product Overview

1.Package Contents

Screw x 4pcs

open-end

wrench x 1pcs

We suggest that the products was assemblied by an adult. Tips: Please charge for 12 hours for first time using.

Aluminum assemblyx 2 pcs

Electric Dirt Bike

DK1

USER MANUAL

2. Product Overview 3. Assembly

Handle

Handlebar

Cushion

Rear

wheel Pedal

Kickstand Front

wheel

Front

fork

Acceleration

Brake lever

Rear fork mount

Rear shock absorber

Aligne hole of the rear shock absorber and

hole of the rear fork.

Put on M8*40mm

cylindrical head screws with socket head

cap, then covered with M8 nylon lock nut

at the other end.

Tighten the screws and

nuts by a 6mm Allen key and 13mm open-end

wrench.

Charging

port Gear

Back

fork

Motor

pack

Battery

LED display

On/Off

4. Charging

Open the rubber plug Insert the charging plug in Fill and fix the rubber plug

after the charging

Note:

• Hiboy electric dirt bike will be fully charged when the LED light on the charger changes from red （charging）to green.

When the battery is fully charged, please STOP CHARGING and unplug the unit.

• Do not charge when there is excessive odour/ heat, leakage or physical damage.

• Do not connect the charger if the charging port is wet. Keep your charging environment clean and dry at all times.

• If the charging port is damp or has any liquid on it, do not charge your E-Bike.

• In order for the battery to operate at maximum efficiency, avoid charging your E-Bike in extremely hot or extremely cold

environments.

• Use only the battery and charging cable provided to you by HIBOY. If a replacement is needed, please contact HIBOY directly.

• Use caution when charging. Charger should be operated by an adult.

• Always disconnect from the charger prior.

Up aluminum assembly

Put the handlebar assembly on the up

aluminum assembly, move it symmetrically

and adjust it to the right angle for your

riding.

Put on the up aluminum assembly, then put

on 4pcs M8*20mm cylindrical head socket

head cap screws.

Tighten the screws with a 6mm socket

head wrench.

Down aluminum assembly

Handlebar assembly

M8*L20mm screws with

hexagon socket head cap

5. Riding Basics

Always wear a helmet and safety gear so to avoid falling and injury

during the driving learning, as shown in the figure.

1. Hold both handles. 2.Activate the power button and observe the

charge on the right handlebar.

Following these techniques and tips can ensure you have a safe, fun riding experience on the DK1 electric dirt bike. Check

to make sure your brakes are fully intact, pedals are securely installed, and handlebars are locked in place.

• The recommended minimum rider age is 3. Do not exceed the weight limiteof140 lbs(64 kg) .

• Always wear an approved helmet and protective gear to avoid possible injury.

• Ensure your tires are intact with no punctures.

• Ensure the vehicle speed is safe to yourself and others, and be ready to stop at any time.

• When riding with friends, keep a safe distance between your devices to prevent collisions.

• Be aware of your surroundings at all times to ensure a safe ride. Your eyes are your best tools for safely avoiding obstacles

and slippery surfaces.

• Stay in open spaces and flat areas, avoid steeps slopes or high traffic areas.

• Only ride the kids E-bike where permitted, you must comply with local laws and give way to pedestrians.

3. Twist the throttle to accelerate and put your

foot on the pedal.

4 . To slow down/stop, first, the right hand

let go of the accelerator，then the left hand

gradually squeeze the brake to slow down/stop.

6. Riding Notice

Do not keep your hands away from

handlebar.

Do not try riding up or down stairs, and

jumping over obstacles.

7. Dangerous Actions (No attempting!)

Do not turn the handlebar violently during

high-speed riding

8. Daily Care and Maintenance

Cleaning and storage

Battery maintenance

If you see stains on the kid's E-bike's body, wipe them off with a damp cloth. If the stains won't scrub off, put on some

toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth.

Notes: do not clean the kid's E-bike with alcohol, gasoline, kerosene or other corrosive and volatile chemical solvents to

prevent dire damage. Do not wash the board with a high-pressure water spray. During cleaning, make sure that the kids

E-bike turned off, the charging cable is unplugged, and the rubber flap is closed as water leakage may result in electric shock

or other major problems. When the kid's E-bike is not in use, keep it indoors where it is dry and cool. Do not put it outdoors for a

long time. Excessive sunlight, overheating and overcooling accelerate the battery pack's lifespan．．

1. Use original battery packs, use of other models or brands may bring about safety issues;

2. Do not touch the contacts. Do not dismantle or puncture the casing. Keep the contacts away from metal objects to prevent short

circuits which may result in battery damage or even injuries and deaths;

3. Use original power adapter to avoid potential damage or fire;

4. Mishandling of used batteries may do tremendous harm to the environment. To protect the natural environment, please follow local

regulations to properly dispose of used batteries.

5. After every use, fully charge the battery to prolong its lifespan.

Storage and Disposal

1. Please try to store the kids E-bike in a cool and dry place between 14 in extremely humid environments the interior

and 104

of the scooter may suffer condensation or even water accumulation, which may damage the battery rapidly. Devices are not intended

for use at elevations greater than 2000m above sea level prolonged exposure to UV rays, rain and the elements may damage

the enclosure materials, store indoors when not in use.

2. In daily use, try to avoid recharging the scooter after completely exhausting the battery. If the battery is low, charge it as soon as

possible.

3. Please charge the kid's E-bike every other month to preserve the battery.

1110

9. Specifications

30 DAY SATISFACTION GUARANTEED RETURN POLICY

If you are unsatisfied with your purchase, Hiboy’s return policy allows you to return the product purchased on the Authorization channel within 30 days counting from the date

of receipt of shipment, and request a refund from the Authorization channel for any reason. Note: Express shipping cost is non-refundable.

For the return request, Hiboy is not responsible for lost packages due to the carrier, or products received that cannot be verified. Received products that have damage determined

to have been caused by the end-user may be subject to denial of the return request.

Hiboy warrants the original purchaser that your Hiboy product shall be free from defects in materials and workmanship under normal use for the period aforementioned.

Hiboy does not warrant the operation of the product will be uninterrupted or error-free.

Hiboy is not responsible for damage arising from failure to follow instructions relating to the product's usage.

1. A Return Merchandise Authorization (RMA) must be requested from Hiboy within 30 days from the date of receipt of shipment. To request an RMA, contact Hiboy Service Team

at [email protected].

2. The cost of return shipping will be borne by the customer.

3. For warranty service, please keep your receipt and/or invoice to validate proof of purchase.

4. Returned product must be in good physical condition (not physically broken or damaged).

5. All accessories originally included with your purchase must be included with your return.

6. If you return a product to Hiboy, (a) without an RMA from Hiboy(b) without all parts included in the original package, Hiboy retains the right to refuse delivery of such return.

10. Limited Warranty Statement

Max.Usage time 90 Minute

10%

[1] Item height: from the ground to the top of the dirt bike;

[2] Max. Range: measured when it is no wind and at 77°F, the dirt bike's fully charged to ride at a even speed of

9.3 mph (15km/h) on a flat surface with a load of 88.2 pounds(40kg).

The real battery life vary with different factors of the load, humidity, wind speed and operation habits...etc.

1312

REMEDIES

If a hardware defect is found and a valid claim is received by Hiboy within the Warranty Period, Hiboy will, at its option and to the extent permitted by law, either (1) repair the

product at no charge, using new or refurbished replacement parts or, (2) replace the product with a new or refurbished product. In the event of a defect, to the extent permitted

by law, these are your sole and exclusive remedies. Shipping and handling charges may apply except where prohibited by applicable law. This Limited Warranty is valid only in

the jurisdictions where the products are sold by www.hiboy.com and are valid to the extent permitted by the applicable laws of such jurisdictions. Any replacement hardware

product will be warranted for the remainder of the original warranty period or thirty (30) days, whichever is longer, or for any additional period of time that may be applicable in

your jurisdiction.

HOW TO OBTAIN WARRANTY SERVICE

A Warranty Service Order must be requested from Hiboy within Warranty Period from the date of receipt of shipment. To request a Warranty Service Order, contact Hiboy Service Team

[email protected].

To obtain warranty service, you must deliver the product, in either its original packaging or packaging providing an equal degr ee of protection, to the address specified by

Hiboy. In accordance with applicable law, Hiboy may require the customer to furnish proof of purchase details and/or comply with registration requirements before receiving

warranty service. period or thirty (30) days, whichever is longer, or for any additional period of time that may be applicable in your jurisdiction.

Except to the extent prohibited by applicable law, Hiboy shall not be liable for any incidental, indirect, special, or consequential damages, including but not limited to loss of

profits, revenue or data, resulting from any breach of express or implied warranty or condition, or under any other legal theory, even when Hiboy has been advised of the

possibility of such damages. Some jurisdictions do not allow the exclusion or limitation of special, indirect, incidental or consequential damages, so the above limitation or

exclusion may not apply to you.
