1

SRD7502

PCIe 4.0 SRD Series NVMe AIC Drives

Quick Installation Guide

V1.01

2

System Requirements

Windows Compatibility

•Computer with a free PCIe 4.0/3.0 x16 slot

•Windows 10, Windows Server 2016 or later, Microsoft Hyper-V

Linux Compatibility

•Computer with a free PCIe 4.0/3.0 x16 slot

•Linux Kernel v3.10 or later

MacOS Compatibility

•Computer with a free PCIe 4.0/3.0 x16 slot

•macOS 10.13 or later

For information about motherboard compatibility, please visit the link

below:

https://highpoint-tech.com/PDF/Compatibility_List/FnL/SRD/FnL_SRD7502_C

ompatibility_List_v1.01_21_5_8.pdf

3

SRD7502 Kit Content

•Pre-Configured SRD7502 AIC Drive

•Quick Installation Guide

SRD7502 Hardware

Front View

Low-Profile (Half-Height) form factor

Anodized aluminum heatsink

Low-Noise Cooling Fan

PCIe 4.0 x16 Host Interface

4

SRD7502 Hardware Installation

Step 1. Carefully remove the SRD7502 from the box.

Step 2. Power off the motherboard and locate the PCIe slot (x16).

Figure 1 - PCIe x16 slot diagram

Note: Please consult your computer/motherboard manual for more

information about the system’s PCIe configuration.

Step 3. Align the Host Interface of the SRD7502 with the PCIe slot and

gently press it in.

Note: Please make sure the AIC Drive is securely installed before

powering on the system. A loose connection will prevent the AIC

Drive from functioning properly.

5

Resources

We recommend visiting the SRD7502 Product Pages for the latest

documentation. (installation guide, compatibility list, etc.)

Document Downloads:

https://www.highpoint-tech.com/USA_new/SRD7502-Overview.html

If you want to know more about similar products (BRD/SRD/CRD

Series), please visit the HighPoint website at:

https://www.highpoint-tech.com/USA-new/FnL-AIC-Drive.html

FnL Monitor

FnL Monitor is an intuitive, web-based monitoring utility that is

available for all major operating system platforms. FnL Monitor’s

enables customers to check and track the health of their AIC drives in

real time.

For more information, please refer to the links below:

https://www.highpoint-tech.com/USA_new/SRD7502-Overview.html

6

Customer Support

If you encounter any problems while utilizing the SRD7502 AIC Drive,

or have any questions about this or any other HighPoint Technologies,

Inc. product, feel free to contact our Customer Support Department.

Web Support:

https://www.highpoint-tech.com/websupport/main.php

HighPoint Technologies, Inc. websites:

https://www.highpoint-tech.com

© Copyright 2021 HighPoint Technologies, Inc. All rights reserved.
