HIK VISION AX Series Manuale utente

Title:

DS-PWA32 How to Configure Wireless Keypad to

Control Panel

Version:

v1.0

Date:

06/24/2019

Product:

AX Series Wireless Security Control Panel

Page:

1 of 7

No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788

E-Mail: support@hikvision.com •www.hikvision.com

Preparation

1. AX Series Wireless Security Control Panel,V1.0.4 or above

2. Wireless Keypad: DS-PKA-WLM

DS-PWA32 How to Configure Wireless Keypad to Control Panel

1. Add Keypad to Control Panel

1) Add by Hik-connect APP

You should add peripheral to the control panel before performing other operations such as arming or

disarming.

Before You Start, Make sure the control panel is disarmed.

Some control panel models do not support add detectors or wireless devices remotely. You should

add them to the control panel directly. For details, see the user manual of the wireless device.

1) Tap to enter the Scan QR Code page.

2) Scan the peripheral's QR code to add the peripheral.

3) Select a peripheral type, and create a name for the peripheral.

The added peripheral will be listed in the Zone tab or the Wireless Device tab.

Note

Title:

DS-PWA32 How to Configure Wireless Keypad to

Control Panel

Version:

v1.0

Date:

06/24/2019

Product:

AX Series Wireless Security Control Panel

Page:

2 of 7

No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788

E-Mail: support@hikvision.com •www.hikvision.com

2) Add by Panel Function button

1) Click the Learn button of Panel, enter Adding Detector Mode .

2) Open the keypad Back plate, Trigger the Keypad Tamper.

3) Finish Adding. (Default link to Partition 1 )

3) Add by Website

1) Login the website.

2) Select Device Management---Keypad---setting.

3) Select the linked Partition No and add the Serial No.

4) Click the OK.

Learn button /

Signal strength activation

Title:

DS-PWA32 How to Configure Wireless Keypad to

Control Panel

Version:

v1.0

Date:

06/24/2019

Product:

AX Series Wireless Security Control Panel

Page:

3 of 7

No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788

E-Mail: support@hikvision.com •www.hikvision.com

Title:

DS-PWA32 How to Configure Wireless Keypad to

Control Panel

Version:

v1.0

Date:

06/24/2019

Product:

AX Series Wireless Security Control Panel

Page:

4 of 7

No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788

E-Mail: support@hikvision.com •www.hikvision.com

2. Configure Keypad password

1) Login the website.

2) Select User Management---User.

3) Click Add, create a new Operator (Including Name, password, keypad password, User

Permission).

4) Click the OK.

Title:

DS-PWA32 How to Configure Wireless Keypad to

Control Panel

Version:

v1.0

Date:

06/24/2019

Product:

AX Series Wireless Security Control Panel

Page:

5 of 7

No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788

E-Mail: support@hikvision.com •www.hikvision.com

3. Keypad Operation

Press and hold any key for 2s to wake up the wireless keypad.

When you see battery light on, then you can operate.

Stay arm

Away arm

Disarm

Fire Alarm

Title:

DS-PWA32 How to Configure Wireless Keypad to

Control Panel

Version:

v1.0

Date:

06/24/2019

Product:

AX Series Wireless Security Control Panel

Page:

6 of 7

No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788

E-Mail: support@hikvision.com •www.hikvision.com

Title:

DS-PWA32 How to Configure Wireless Keypad to

Control Panel

Version:

v1.0

Date:

06/24/2019

Product:

AX Series Wireless Security Control Panel

Page:

7 of 7

No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788

E-Mail: support@hikvision.com •www.hikvision.com

First Choice for Security Professionals

HIKVISION Technical Support
