HIK VISION DS-2CD2042WD-I Manuale utente

User Manual

Code: DS-2CD2042WD-I(4mm)

IP CAMERA DS-2CD2042WD-I(4mm) - 4.0 Mpx Hikvision

DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl

POL; 60-713 Poznań; Graniczna 10

e-mail: [email protected]; tel: +(48) 61 864 69 60

2021-11-10 DS-2CD2042WD-I(4mm) 1/6

Warning!

Please read the user manual included in this work as it contains important information related with safety of installation and use of

the device.

Only persons who read the user manual may use the device.

The user manual must be kept because it may be required in the future. The device is to be used exclusively for purposes specified

in this user manual.

The device must be unpacked prior to starting-up. After removing the packaging make sure the device is in working order.

If the product has defects, it should not be used until it is repaired.

The product is intended for use at home and commercial use and may not be used for other than intended use.

The manufacturer is not liable for damages resulting from not adhering to the rules contained in the user manual, therefore, we

recommend to follow the aforementioned safety rules for operation and maintenance of the device. In this way you will ensure

yourself safety and avoid causing damage to the device.

The manufacturer and the supplier are not liable for losses or damages arising out of the product, including financial or intangible

losses, loss of profits, income, data, pleasure from use of the product or other products related with it - indirect, incidental or

consequential loss or damage. The above provisions apply whether the loss or damage concerns:

1. Deterioration of quality or the lack of operation of the products or products related with it due to damage as well as the lack of

access to the product when it is undergoing repair, which results in stoppage the loss of user's time or a break in business activity;

2. Improper results of operation of the product or products related with it;

3. It applies to losses and damages according to any legal category, including negligence and other losses, termination of a

contract, expressed or implied guarantee and strict liability (even if the manufacturer or the supplier was notified about the

possibility of occurrence of such damages).

Safety measures:

Particular attention at designing was directed to quality standards of the device where ensuring safety of operation is the most

important factor.

The device must be secured against contact with caustic, staining and viscous fluids.

The device was designed in such a way that it restarts operation when power supply is restored after a break.

Attention! We recommend using protections to further protect the device from possible overvoltages in installations.

Surge protectors are effective protection against accidental pass to the device voltages higher than the rated. Damages

caused by pass the voltages higher than specified in manual, are not under warranty.

Turn off the device before transporting it.

Prior to connecting the device to a power source check whether the supplied voltage is consistent with rated voltage specified in

the user manual.

Proper product disposal:

A marking of a crossed out waste bin indicates that the product may not be disposed together with other household waste in the

entire EU. To avoid possible damage to the natural environment of health due to uncontrolled waste disposal, therefore, it should be

handed over for recycling, propagating in this way sustainable use of natural resources.

To return a worn-out product, use a collection and disposal system of this type of equipment or contact a seller from whom it was

purchased. He will then be recycled in an environmentally-friendly way.

User Manual

Code: DS-2CD2042WD-I(4mm)

IP CAMERA DS-2CD2042WD-I(4mm) - 4.0 Mpx Hikvision

DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl

POL; 60-713 Poznań; Graniczna 10

e-mail: [email protected]; tel: +(48) 61 864 69 60

2021-11-10 DS-2CD2042WD-I(4mm) 2/6

IP camera with efficient H.264 image compression algorithm for

clear and smooth video streaming at maximal resolution of 4

MPx.

PoE powering possibility, compatible with the 802.3af standard

makes the device more universal and easier to install.

Standard: TCP/IP

Sensor: 1/3 " Progressive Scan CMOS

Scanning system: Progressive

Matrix size: 4.1 Mpx

Resolution:

2688 x 1520 - 4.0 Mpx ,

2304 x 1296 - 3.0 Mpx ,

1920 x 1080 - 1080p

1280 x 720 - 720p

Lens: 4 mm

View angle: • 82 ° (manufacturer data)

• 80 ° (our tests result)

Compression: H.264+ / H.264 / MJPEG

S/N ratio: > 50 dB (AGC off)

Range of IR illumination: 30 m

Alarm inputs / outputs:

Audio:

Memory card slot:

Bitrate: 32 ... 16384 kbps - H.264

Main stream frame rate: 20 fps @ 4.0 Mpx

25 fps @ 1080p

Network interface: 10/100 Base-T (RJ-45)

User Manual

Code: DS-2CD2042WD-I(4mm)

IP CAMERA DS-2CD2042WD-I(4mm) - 4.0 Mpx Hikvision

DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl

POL; 60-713 Poznań; Graniczna 10

e-mail: [email protected]; tel: +(48) 61 864 69 60

2021-11-10 DS-2CD2042WD-I(4mm) 3/6

Network protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,

UPnP, SMTP, SNMP, IGMP, IEEE 802.1x, UDP, PPPoE, QoS, IPv6

WEB Server: Built-in, NVR compliance

Max. number of on-line users: 6

ONVIF: 2.6

Mobile phones support:

Port no.: 8000 or access by a cloud (P2P)

• Android: Free application iVMS-4500 or Hik-Connect

• iOS (iPhone): Free application iVMS-4500 or Hik-Connect

Default admin user / password: admin / -

Default IP address: 192.168.1.64

Web browser access ports: 80

PC client access ports: Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application

Mobile client access ports: 8000

Port ONVIF: 80

RTSP URL:

• Main stream

rtsp://192.168.1.64:554/Streaming/Channels/101/ - RTSP - without authorization

rtsp://user:[email protected]:554/Streaming/Channels/101/ - with

authorization

• Sub stream

rtsp://192.168.1.64:554/Streaming/Channels/102/ - RTSP - without authorization

rtsp://user:[email protected]:554/Streaming/Channels/102/ - with

authorization

RS-485 interface:

Main features:

• 3D-DNR - Digital Noise Reduction

• WDR - 120 dB - Wide Dynamic Range

• BLC - Back Light Compensation

• RESET button

• Possibility to change the resolution, quality and bit rate

• Intelligent Image Analysis : Motion Detection, intrusion, crossing the line (tripwire)

• ROI - improve the quality of selected parts of image

• Configurable Privacy Zones

• Mirror - Mirror image

Power supply: • PoE (802.3af),

• 12 V DC / 410 mA

Power consumption: ≤ 5.0 W

Housing: Compact, Aluminum

"Index of Protection": IP67

Color: White

Operation temp: -30 °C ... 60 °C

Supported languages:

English, Bulgarian, Chinese, Croatian, Czech, Danish, Estonian, Finnish, French,

Greek, Spanish, Dutch, Japanese, Korean, Lithuanian, Latvian, German, Norwegian,

Polish, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish,

Hungarian, Vietnamese, Italian

Weight: 0.38 kg

Dimensions: 155 x 70 x 70 mm

User Manual

Code: DS-2CD2042WD-I(4mm)

IP CAMERA DS-2CD2042WD-I(4mm) - 4.0 Mpx Hikvision

DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl

POL; 60-713 Poznań; Graniczna 10

e-mail: [email protected]; tel: +(48) 61 864 69 60

2021-11-10 DS-2CD2042WD-I(4mm) 4/6

Manufacturer / Brand: Hikvision

SAP Code: 300710224

Guarantee: 3 years

Side view:

User Manual

Code: DS-2CD2042WD-I(4mm)

IP CAMERA DS-2CD2042WD-I(4mm) - 4.0 Mpx Hikvision

DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl

POL; 60-713 Poznań; Graniczna 10

e-mail: [email protected]; tel: +(48) 61 864 69 60

2021-11-10 DS-2CD2042WD-I(4mm) 5/6

RESET button:

Camera mounting side view:

User Manual

Code: DS-2CD2042WD-I(4mm)

IP CAMERA DS-2CD2042WD-I(4mm) - 4.0 Mpx Hikvision

DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl

POL; 60-713 Poznań; Graniczna 10

e-mail: [email protected]; tel: +(48) 61 864 69 60

2021-11-10 DS-2CD2042WD-I(4mm) 6/6

In the kit:
