DETAILED

INSTRUCTIONS

FOR USE OF THE

ELECTRIC OVEN

IE MT

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Hisense HBF22ILPP o

cerca il tuo prodotto tra le migliori offerte di Forni

We thank you for your

trust and the purchase of our

appliance.

This detailed instruction manual is

supplied to make the use of this

product easier. The instructions

should allow you to learn about your

new appliance as quickly as possible.

Make sure you have received an

undamaged appliance. If you do find

transport damage, please contact the

seller from which you purchased the

appliance, or the regional warehouse

from which it was supplied. The

telephone number can be found on

the invoice or on the delivery note.

Instructions for installation and

connection are supplied on a

separate sheet.

Important information

Tip, note

CONTENTS

784868

MAINTENANCE

& CLEANING

TROUBLE-

SHOOTING

4 IMPORTANT SAFETY INSTRUCTIONS

6 Before connecting the appliance:

7 THE ELECTRIC OVEN

11 Technical specifications

12 Control unit (depending on the model)

14 BEFORE USING THE APPLIANCE FOR THE FIRST TIME

15 STEPS OF THE COOKING PROCESS (1–6)

15 Step 1: SWITCHING ON AND SETTINGS

16 Step 2: CHOOSING THE COOKING SYSTEM

18 Step 3: CHOOSING THE SETTINGS

21 Step 4: SELECTING ADDITIONAL FUNCTIONS/EXTRAS

23 Step 5: STARTING THE COOKING PROCESS

23 Step 6: SWITCHING OFF THE OVEN

24 DESCRIPTIONS OF SYSTEMS (COOKING MODES) AND COOKING

TABLES

40 MAINTENANCE & CLEANING

41 Conventional oven cleaning

42 Using the steam clean function to clean the oven

43 Removing and cleaning wire and telescopic extendable guides

44 Installing the catalytic inserts

45 Cleaning the oven cavity ceiling

46 Removing and inserting the oven door (depending on the model)

49 Removing and inserting the oven door glass pane

50 Replacing the bulb

51 TROUBLESHOOTING TABLE

52 DISPOSAL

INTRODUCTION

PREPARING THE

APPLIANCE FOR

THE FIRST USE

COOKING STEPS

784868

IMPORTANT SAFETY

INSTRUCTIONS

CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM

FOR FUTURE REFERENCE.

This appliance may only be used by children aged 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

supervision or instructions are provided to them concerning

use of the appliance in a safe way and if they understand

the hazards involved. Do not let the children play with the

appliance. Cleaning and user maintenance shall not be made

by children without supervision.

WARNING: The appliance and its accessible parts become hot

during use. Care should be taken to avoid touching heating

elements. Children less than 8 years of age shall be kept away

unless continuously supervised.

WARNING: Accessible parts may become hot during use.

Young children should be kept away.

During use the appliance becomes hot. Care should be

taken to avoid touching heating elements inside the oven.

Only use the temperature probe recommended for use in

this oven.

WARNING: Ensure that the appliance is switched off before

replacing the lamp to avoid the possibility of electric shock.

784868

Do not use harsh abrasive cleaners or sharp metal scrapers

to clean the oven door glass/ the glass of hinged lids of the

hob (as appropriate), since they can scratch the surface,

which may result in shattering of the glass.

Do not use steam cleaners or high pressure cleaners to

clean the appliance as this may result in an electric shock.

Means for disconnection must be incorporated in the fixed

wiring in accordance with the wiring rules.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons

in order to avoid a hazard (only for appliances supplied with

connection cord).

The appliance must not be installed behind a decorative

door in order to avoid overheating.

784868

The appliance is intended for household

use. Do not use it for any other purpose,

such as room heating, drying of pets or

other animals, paper, fabrics, herbs etc. As

this may lead to injury or fire hazard.

The appliance may only be connected to

the power mains by an authorised service

technician or expert. Tampering with

the appliance or non-professional repair

thereof may result in risk of severe injury or

damage to the product.

If the power cords of other appliances

located near this appliance are caught

in the oven door, they may be damaged,

which may in turn result in a short circuit.

Therefore, keep the power cords of other

appliances at a safe distance.

Do not line the oven walls with aluminium

foil and do not place baking trays or other

cookware on the oven bottom. Aluminium

foil would prevent air circulation in the

oven, hinder the cooking process, and ruin

the enamel coating.

Oven door become very hot during

operation. A third glass is installed for extra

protection, reducing the temperature of the

outside surface (only with some models).

Oven door hinges may be damaged when

under excessive load. Do not place heavy

pans on open oven door and do not lean

against open oven door when cleaning the

oven cavity. Never stand on the open oven

door and do not let children to sit on it.

Appliance operation is safe with and

without tray guides.

Make sure the vents are never covered or

obstructed in any other way.

BEFORE CONNECTING THE APPLIANCE:

Carefully read the instructions for use before connecting

theappliance. Repair or any warranty claim resulting from

incorrect connection or use of the appliance shall not be covered

by the warranty.

THE ELECTRIC OVEN

(DESCRIPTION OF THE OVEN AND EQUIPMENT – DEPENDING ON

THE MODEL)

Control unit

Oven door

Oven handle

Guides

- Cooking levels

Safe open Sensor

784868

The figure represents one of the built-in appliance models. Since the appliances for which

these instructions were drawn up may have different equipment, some functions or

equipment may be described in the manual that may not be present in your appliances.

PUSH-PULL KNOB

Slightly push the knob until it pops out; then, rotate it.

After each use, rotate the knob back to the "off" position and push it back in. The

push-pull knob can only be pushed back when the switch is in the "off" position.

WIRE GUIDES

The wire guides allow preparation of the food on four levels (please note that the levels/

guides are counted from the bottom up).

Guides 3 and 4 are intended for grilling.

TELESCOPIC PULL-OUT GUIDES

Telescopic pull-out guides may be fitted for the 2nd, 3rd, and 4th level.

Pull-out guides can be partly or fully extendable.

SAFE OPEN SENSOR

The sensor deactivates oven heating and the fan when the oven door is opened during the

cooking process. When the door is closed, the sensor turns the heaters back on.

COOLING FAN

The appliance is fitted with a cooling fan that cools the housing and the appliance control

panel.

EXTENDED OPERATION OF THE COOLING FAN

After the oven is switched off, the cooling fan continues to operate for a short while in

order to cool the oven.

784868

OVEN EQUIPMENT AND ACCESSORIES (depending on the model)

GLASS BAKING DISH is used for cooking

with all oven systems. It can also be used as

a serving tray.

The GRID is used for grilling or as support

for a pan, baking tray or baking dish with

the food.

There is a safety latch on the grid.

Therefore, lift the grid slightly at the front

when pulling it out from the oven.

784868

The SHALLOW BAKING SHEET is used for

baking pastry and cakes.

The DEEP BAKING TRAY is used for roasting

meat and baking moist pastry. It can also be

used as a drip tray.

Never place the deep baking tray in the

first guide during the cooking process, except

when grilling food or using the roasting spit

and you are only using the deep tray as a drip

tray.

As baking accessories heat up, their

form may change. This does not affect

their functionality and their original form

will be restored when they cool down.

The grid or the tray should always be

inserted into the groove between the two

wire profiles.

With telescopic extendable guides, first pull

out the guides of one level and place the

grid or the baking tray onto them. Then,

push them in with your hand as far as they

will go.

Close the oven door when the

telescopic guides are retracted all the way

into the oven.

784868

The appliance and some of the accessible parts tend to heat up

during cooking. Use oven mitts.

CATALYTIC INSERTS prevent the spraying

fat from accumulating on the sides of the

oven cavity.

1 WHAT IS CATALYSIS?

Catalytic cleaning is a chemical process

in which catalysts completely break

down the grease particles during food

preparation. In case of normal use, the

service life of the catalytic inserts is equal

to the service life of the appliance. If the

inserts are worn out sooner, replacements

are available at service centres.

2 HOW TO CLEAN THE CATALYTIC

INSERTS?

Catalytic inserts are cleaned automatically

at temperatures of 85 °C or higher. In

case of minor stains, they can be easily

removed and cleaned with water and

a soft cloth. Do not use aggressive

cleaners and do not wash the inserts in

the dishwasher. Streaks on the catalytic

inserts do not affect their effectiveness.
