Hitachi Cable WIRELESSIP 5000 Manuale utente

- 1 -

Product certified to meet technical standards

Thank you for purchasing the WirelessIP 5000.

● Please carefully read and understand this

"User's Manual" before using the product.

● After reading this manual, please keep it

close at hand for use any time you need it.

WirelessIP 5000

User's Manual

TD61-2893

- 2 -

Introduction

Thank you for your purchase of this product.

This user's manual contains items that you should follow in order to prevent any harm to yourself and others, or damage to

equipment, and to enable you to use this product safely. An explanation of the markings and symbols used in this manual is

provided below. Please understand these symbols before reading the rest of this document.

Please always observe for the sake of safety.

zEverycarehasbeentakenin the writingofthismanual,but if youfindanypoints of concern withthismanual,please notify

us through one of our contact points.

zPlease understand that this company can not assume any responsibility for any damage or other pure economic loss

resulting from lost communications opportunitiesdue to a breakdown of this product, its incorrect operation, power failure

or other external factors.

zAfter sales service

We request that you write down in a memo or otherwise store any information that you yourself have registered in this

product.

This company has no obligation concerning changes to, or loss of, any information and bears no responsibility for this

whatsoever.

During repairs for a breakdown, data created by the customer or loaded in from outside may change or be lost.

This company takes no responsibility for this.

This symbol indicates cautions concerning the handling of this

product.

This symbol indicates details that if ignored, and the product

is handled incorrectly, can result in failure of this product to

perform to its full capacity or in loss of function.

This symbol indicates details that if ignored, and the product

is handled incorrectly, can result in injury or damage to

equipment.

This symbol indicates details that if ignored, and the product

is handled incorrectly, can result in death or severe injury.

Warning

Caution

- 3 -

Introduction

■Registered trademarks/copyrights

zWindows is a registered trademark of the Microsoft Corporation in the United States and other countries.

zWindows XP is an abbreviation for the Microsoft Windows XP Home Edition operating system and the Microsoft Windows

XP Professional operating system.

zWindows 2000 is an abbreviation for the Microsoft Windows 2000 Professional operating system.

zThe Japanese-language converter software "Mini-Wnn" is a registered trademark of Omron Software, Ltd.

zOther company names and product names are trademarks or registered trademarks of their respective companies.

Any reproduction or copying of its content without prior permission is strictly forbidden.

The contents of this manual may be revised at any time without prior notice. For support information about added functions,

changes, etc., we recommend that you periodically visit the home page below for updated information.

Our company's home page http://www.wirelessip5000.com/

■Voluntary Control Council for Interference by Information Technology Equipment (VCCI) standards

This device is a Class B Information Technology Device as defined by the Voluntary Control Council for Interference by

InformationTechnology Equipment(VCCI).Thisproduct isintendedfor useinhomeenvironments, butifitis usednearradio or

TV receivers, it may cause interference with reception. Please use this product correctly as explained in this user's manual.

■Caution concerning the Radio Law and wireless LAN

Thewireless device usedin thisproduct hasreceived specialwireless devicecertification asa low-powerdata communications

system wireless device based on the Radio Law. Therefore, use of this product does not require any wireless station permit.

zUse of this product is restricted to within Japan. This product was designed and manufactured for use within Japan.

Therefore,usingthisproductoutsideofJapanmaybreakthisproductandotherequipment.Suchusagemayalsotouchon

the laws of that nation, so this product may not be used outside of Japan.

zDonot usethis product near persons using pacemakers. This product may cause life-threatening electromagnetic interference

witha cardiacpacemaker.

zDonotusethisproductnearmedicalequipment.Thisproductmaycauselife-threateningelectromagneticinterferencewith

medical equipment.

zDo not use this product near a microwave oven that is in use. A microwave oven can cause electromagnetic interference

with the wireless communications of this product.

zThe wireless device in this product has been certified under the Radio Law, so do not disassemble or alter this product.

- 4 -

Introduction

■Caution concerning interference with 2.4Ghz wireless LAN

When communicating with a 2.4GHz LAN, be careful about the following.

Microwave ovens and other industrial, scientific, and medical equipment, as well as indoor wireless stations (wireless stations

requiring permits) and special low-power wireless stations (wireless stations not requiring permits) used for identifying mobile

units used in plant manufacturing line etc., as well as amateur wireless stations (wireless stations requiring permits) operate in

the frequency band used by this product.

zBeforeusing thisproduct, double check that no indoor wireless stations, special low-power wireless stations for mobile unit

identification,or amateur wireless stations are in operation in the vicinity.

zIfthis product should cause harmful electromagnetic interference in an indoor wireless station for identifyinga mobileunit,

quickly change the frequency used or stop emitting the electromagnetic signal, then notify the store of purchase and

consult with them about measures for avoiding interference (for example, installing a partition wall).

zBesidesthat,ifthisproductshouldcauseharmfulelectromagneticinterferenceinaspeciallow-powerwirelessstationused

for identifying a mobile unit, or in an amateur wireless station, or some other problem occurs, please inquire at the store

from which you made your purchase.

■Built-in 2.4GHz band (IEEE801.11b) wireless LAN functions

Usage frequency band : Wireless equipment using the 2.4GHz band

Transmission method : DSSS

Modulation : DQPSK DBPSK CCK

Assumed interference distance : 40 m max.

Frequency modulation advantages : The entire bandwidth can be used to avoid the frequency bands of indoor wireless

stations and special low-power wireless stations used for identifying mobile units, as well

as amateur wireless stations.

Because the 2.4GHz band frequency used in this product overlaps with medical equipment, microwave ovens and other

industrial and scientific equipment, as well as indoor wireless stations and special low-power wireless stations for identifying

mobile units used in plant manufacturing line etc., electromagnetic interference is possible. Before starting to use this product,

double check that no indoorwireless stations or special low-power wireless stations are operating within the interference range

of this product.

- 5 -

Safety precautions

Besuretoread thissectionfor thesake of safeusage. Please observethese precautions inorder to usethis product safelyand

prevent injury to the user and others and to prevent damage to equipment.

Please understand these "warnings" and "cautions" before reading the rest of this manual.

Store it safely near at hand for future reference after reading it.

The phone

zDo not use any AC adaptor other than the one came with this product.

Doing so can result in fire, electrical shock, and malfunction.

zDo not use any accessory or separately-sold item other than those specified for this product.

Doing so can result in fire, electrical shock, and malfunction.

zNever swing or throw this product by the end of a hand-strap (off-the-shelf product).

You could strike and hurt someone or damage this product.

zThis device should not, under any circumstances, be used inside an airplane or aviation facilities, a high-speed

train (bullet train) or a hospital.

Electromagnetic interference could cause electronic equipment to malfunction and result in an accident.

zDo not use this product with wet hands.

This can result in electrical shock.

zNever use this product in any location where it can be easily wet by water or other liquid (such as near a sink or

hot tub).

zNever disassemble or alter this product. Do not repair this product yourself

Doing so can result in fire, electrical shock, and malfunction.

zUse this product somewhere out of the reach of infants and small children.

An infant or small child playing with this product could receive an electrical shock and injury.

zPlease discontinue use if any unusual conditions should occur, such as the device emitting smoke, an unusual

smell, a strange noise, or water getting into this product.

Continued use the device inthis condition can resultin the outbreak offire, electric shock, or malfunction. Immediately cut

off the power and remove the battery pack. Make sure that the smoke stops, then contact the store of purchase.

Warning

- 6 -

Safety precautions

zDo not install the device on shaky, inclined, or otherwise unstable surfaces.

The product might fall and cause a fire, injury, or breakdown.

zDo not sit on this product, place a heavy object on it, or pinch it between objects.

Doing so may break this product

zDo not use this product where dew condensation may occur.

When moving this product suddenly between environments at drastically different temperatures, there is a danger of dew

condensation, so take care. This can cause deformation, discoloration, fire, and breakdown. If dew condensation forms in

this product, either dry it or leave it for a long while in the current environment before using it.

zDo not leave this productanywhere subject to drastic environmental changes, such as locations subject to direct

sunlight or near a heater or air conditioner.

This can cause deformation, discoloration, fire, and breakdown.

zDo not drop the product or subject it to strong shocks.

Doing so may cause injury or breakdown.

zDo not use or leave this product in any location subject to high humidity or dust.

Doing so may break this product

zDo not use this product near a radio or television.

It may cause or be subject to electromagnetic interference.

zDo not use this product in strong magnetic fields or where static electricity occurs or where the temperature or

humidity exceeds the usage environment given in the user's manual.

Doing so may break this product

zNever use paint thinner or benzine to clean this product.

This cancause deteriorationof thecase or paint peeling.Normally, wipe this productwith a soft cloth.If it isquite dirty, dip

the cloth in a little diluted neutral detergent.

Caution

- 7 -

Safety precautions

Battery pack (accessories)

zFailure to follow the items below can cause rupture, fire, heat, battery fluid leakage, electrical shock, and burns.

・ Do not charge the battery pack with any method other than that specified.

・ Do not use this battery pack in any device other than this product.

・ Do not put this product into fire or heat it.

・ Do not solder this product.

・ Do not carry or leave this product with a necklace or other metal.

・ Do not short the terminals of the battery pack.

・ Do not use, charge, orleave near an open fire, near a stove, subject to direct sunlight, or anywhere else that reaches

high temperatures.

・ If any fluid that has leaked from the battery gets in your eyes, do not rub them. There is a danger of blindness, so

immediately wash out your eyes with plenty of clean water and seek immediate medical attention.

・ Use only the battery pack specifically manufactured for the Hitachi Cable WirelessIP 5000. Using a product not

designedfortheWirelessIP5000wouldcausedangerandwouldmakeitimpossibletowarrantythecorrectoperations

of this product and your communications.

zFailure to follow the items below can cause rupture, heat, and battery fluid leakage.

・ Do not wrap this battery pack with tape or otherwise process it. This battery pack may emit gas.

・ Do not attempt to disassemble or alter the battery pack.

・ Do not place any tool or other metal or electrically conductive item on the battery pack or let such item fall onto the

battery pack.

・ Keep water and seawater off and out of the battery pack.

zFailure to follow the items below can cause rupture, heat, battery fluid leakage, rust, and impaired performance

and reduced service life.

・ Do not charge the battery pack longer than the specified time.

・ Only charge the battery pack within the ranges of 0-40°C and 10-90% humidity.

・ Do not use or store in any location that can reach high temperature.

・ Do not charge outdoors in the cold or use while cold.

・ Do not throw this battery pack or subject it to strong mechanical shock.

・ Always switch the power switch Off when the product is not in use.

・ When this product will beleft unused for aprolonged period, remove thebattery pack and store it in a dry location at a

temperature between 0 and 25°C.

zNever use paint thinner or benzine to clean this product.

This cancause deteriorationof thecase or paint peeling.Normally, wipe this productwith a soft cloth.If it isquite dirty, dip

the cloth in a little diluted neutral detergent.

Warning

Caution

- 8 -

Safety precautions

AC adaptor (accessory)

zFailure to follow the items below can cause rupture, fire, heat, battery fluid leakage, electrical shock, burns, and

breakdown.

・ This device should not be used at a voltage other than 100 VAC.

・ Do not charge the battery pack with any method other than that specified.

・ Do not use this battery pack in any device other than this product.

・ Do not use any AC adaptor other than the one came with this product.

・ Do not use this AC adaptor to charge anything other than the battery pack that came with this product.

・ Do not attempt to disassemble or alter the battery pack. Do not repair this product yourself

・ UseonlyanACadaptorspecificallymanufacturedfortheHitachiCableWirelessIP5000.Usingaproductnotdesigned

for the WirelessIP 5000 would cause danger and would make it impossible to warranty the correct operations of this

product and your communications.

zFailure to follow the items below can cause fire, heat, electrical shock, injury, and breakdown.

・ Do not let water get into or onto the AC adaptor. Do not use the AC adaptor with wet hands.

・ Do not under any circumstances touch the AC adaptor with wet hands during charging.

・ Do not place any heavy object on the power cord or pinch it between objects.

・ Use this product somewhere out of the reach of infants and small children.

・ Plug the AC adaptor all the way into the electrical socket.

・ Plug the AC adaptor into its own socket, not into a multi-socket tap or extension cord.

・ Check that the power plug (or AC adaptor) is free from dust before plugging into the electrical socket. Once every six

months to one year, unplug the power plug (or AC adaptor) from the socket and inspect and clean it. Dust build up

could cause fire and electrical shock.

・ When plugging or unplugging the AC adaptor, always hold the adaptor itself, not the cord.

・ When unplugging or plugging in the power cord, hold it by the plug. Never pull the cord itself.

・ Do not process the power supply cord, bend or twist it with excessive force, yank it, or heat it.

・ If the power supply cord is damaged or the plug is loose in the socket, do not use the AC adaptor.

・ If there is lightning in the vicinity, for safety sake, unplug from the socket.

・ Please discontinue use if anyunusual conditions should occur,such as the deviceemitting smoke, an unusual smell,

orastrangenoise.Ifsuchaconditionshouldoccur,immediatelydisconnecttheACadaptorfromtheelectricalsocket,

make sure that the smoke stops, then contact the store of purchase.

Warning

- 9 -

Safety precautions

zFailure to follow the items below can cause fire, battery fluid leaks, heat, electrical shock, and injury.

・ After charging is complete and when not charging, unplug the AC adaptor from the electrical socket.

・ Only charge the battery pack within the ranges of 0-40˚C and 10-90% humidity.

・ Do not use or leave this product in any location subject to high humidity or dust or poor ventilation.

・ When plugging or unplugging the AC adaptor, do not pull on the power cord.

•Never use paint thinner or benzine to clean this product.

This cancause deteriorationof thecase or paint peeling.Normally, wipe this productwith a soft cloth.If it isquite dirty, dip

the cloth in a little diluted neutral detergent.

Caution

- 10 -

CONTENTS

Introduction...............................................................................................................................................................................2

Safety precautions....................................................................................................................................................................5

CONTENTS............................................................................................................................................................................10

Chapter 1 Overview.................................................................................................................................1-1

Features of the WirelessIP....................................................................................................................................................1-2

Names & Functions of Device Parts......................................................................................................................................1-4

Using accessories.................................................................................................................................................................1-7

Accessories.......................................................................................................................................................................1-7

Battery pack installation method.......................................................................................................................................1-7

Using accessories.................................................................................................................................................................1-8

Battery pack removal........................................................................................................................................................1-8

AC power supply adaptor..................................................................................................................................................1-8

Charging method...............................................................................................................................................................1-9

Chapter 2 Placing and Receiving Telephone Calls...............................................................................2-1

Switching the Power On/Off..................................................................................................................................................2-2

Power ON..........................................................................................................................................................................2-2

Power OFF........................................................................................................................................................................2-2

Calling method.......................................................................................................................................................................2-3

Receiving calls.......................................................................................................................................................................2-4

Call log...................................................................................................................................................................................2-5

Details...............................................................................................................................................................................2-6

Deleting one item from the call log....................................................................................................................................2-7

Deleting the entire call log.................................................................................................................................................2-8

Various operation methods....................................................................................................................................................2-9

Redial................................................................................................................................................................................2-9

Calling from the call log.....................................................................................................................................................2-9

Call from phone book......................................................................................................................................................2-10

Caller ID..........................................................................................................................................................................2-12

Speed Dialing..................................................................................................................................................................2-13

Hold function...................................................................................................................................................................2-14

Call waiting......................................................................................................................................................................2-15

Hold transfer....................................................................................................................................................................2-16

Chapter 3 Phone book............................................................................................................................. 3-1

Phone book menu.................................................................................................................................................................3-2

Phone book registration........................................................................................................................................................3-3

Registration from phone book menu.................................................................................................................................3-3

Registration from a telephone number..............................................................................................................................3-5

Registration from a call log................................................................................................................................................3-7

Phone book editing................................................................................................................................................................3-9

Phone book editing..............................................................................................................................................................3-10

Group management.............................................................................................................................................................3-11

Deleting one item from phone book.....................................................................................................................................3-13

Deleting entire phone book..................................................................................................................................................3-15

Chapter 4 Messaging...............................................................................................................................4-1

Message menu......................................................................................................................................................................4-2

Inbox......................................................................................................................................................................................4-3

New Message........................................................................................................................................................................4-7

Drafts.....................................................................................................................................................................................4-8

Outbox.................................................................................................................................................................................4-11

Setup...................................................................................................................................................................................4-14

Chapter 5 Presence................................................................................................................................. 5-1
