CCD Color Camera

KP-D20BP-S3

Specifications

Hitachi Kokusai Electric Inc.

Tokyo Japan

DWN

DSGN

CHKD

APPD

・・

Ｆ

8716616

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

1. General

The KP-D20BP-S3 is a single CCD type color camera utilizing digital signal

processing in addition to digital control of the various correction and

adjustment functions to enable high quality images.

The high density CCD comprises 470,000 picture elements PAL and provides

clear pictures even under low illumination, in addition to high sensitivity and

resolution.

Important functions, including auto iris and auto white balance, allow use in

a wide range of CCTV systems for image processing, surveillance and other

applications.

2. Principal features

(1) Very small, light weight,Various functions

44 (W) x 44 (H) x 49 (D) mm , 130g

Y/C output standard equipment

RS-232C standard equipment

(2) High sensitivity and resolution

The high density interline type CCD sensor with on-chip microlenses

enables low-light pickup down to 0.3 lux (F 1.2 lens, AGC maximum) and

horizontal resolution of 470 TV lines.

(3) Digital signal processor (DSP)

Digital processing includes 2 H enhancer and contour correction to deliver

clear pictures and high signal to noise ratio (S/N). Picture control

parameters can also be adjusted with the aid of on-screen menus, thus

enabling optimum adjustments to match the application.

(4) Electronic shutter

The electronic shutter can be set in 10 steps from standard (off setting) 1/50

second to 1/30000 second. Auto electronic shutter (AES) operates to

1/180000 second. Even with a fixed iris lens, the shutter speed responds to

the amount of light to keep the signal output at optimum level.

(5) Backlight compensation

Backlight compensation can operate with either a video signal or control

voltage input type auto-iris lens. The sensing area can also be selected

according to usage conditions.

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

(6) Three white balance modes

Auto-tracking white balance (ATW) functions by detecting white color in the

scene at a color temperature from 2500 to 8000 Kelvin. Auto-white balance

control (AWC) is a preset type function whereby white color in the scene is

detected and white balance is automatically adjusted, then the setting

status is stored. Manual white balance allows adjusting red and blue gain

manually according to requirements.

(7) Text display

Up to 24 alphanumeric characters can be displayed at either the top or

bottom of the screen.

(8) Digital zoom

The screen can be smoothly enlarged up to 4 times.

(9) Picture quality menus

A wide variety of modes and parameters can be selected from menus and

adjusted by using rear panel key buttons.

3. Specifications

(1) Pickup element : Interline transfer type CCD (with on-chip microlenses)

Total pixels :795 (H) ×596 (V)

Effective pixels :752 (H) ×582 (V)

Scanning area :6.47 (H) ×4.83 (V) mm

(equivalent to 1/2-inch pickup tube)

Unit cell size :8.6 (H) ×8.3 (V) μm

(2) Scanning system : 2:1 interlace

Frequency Horizontal : 15.625 kHz

Vertical : 50 Hz

(3) Sync system : Internal

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

(4) Video signal output : Composite video : 1.0 Vp-p/75 Ωunbalanced

Video:0.7Vp-p positive or negative (negative picture)

Sync :0.3 Vp-p negative

Burst : 0.3 Vp-p more than 8 cycles

Subcarrier frequency : 4.433618 MHz±100 Hz

Connector : BNC type

Y/C outputs

Y:1.0Vp-p

Video:0.7Vp-ppositiveornegative(negativepicture)

Sync :0.3 Vp-p negative

C:0.3Vp-p(Burst)

Impedance:75ohmsunbalanced

Connector:Roundmulti-connector,12pin

(5) Remote control : RS-232C

Connector:Roundmulti-connector,4pin/12pin

(6) S/N (luminance signal) : More than 50 dB

(standard gain, enhancer and gamma off)

(7) Resolution : Horizontal :More than 470 TV lines

Vertical :More than 350 TV lines

(8) Scene illumination range : 0.3 to 100,000 lux (F1.2, Auto-iris lens)

(9) Minimum illumination : 0.3 lux (F1.2, 3200 K, AGC 31dB.)

(10)Signal processing : Digital processing (input: 10 bits)

(11) AGC : On/off selectable

Max.gainatonsettingselectable:6,12,21and31dB

(factorysettingis21dB)

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

(12) Electronic shutter speed : Selectable in 10 steps

: OFF(1/50), 1/120, 1/250, 1/500, 1/1000, 1/2000,

1/4000, 1/10000,1/20000,1/30000 second,

andAuto

(13) Backlight compensation : On/off switchable

Sensingareas: selectablefrom9areas

(14) Auto-iris lens outputs : Video signal input type lens

(a) Luminance signal : 1.0 Vp-p/high impedance

Power supply : 12 VDC 60 mA

(b) Iris control voltage input (galvanometer) type lens

Coupling coil impedance

Damper : 1150 Ω±10 %

Drive : 190 Ω±10 %

(15) White balance Selectable auto-tracking (ATW), preset (AWC),

manual (MANUAL) ( R/B gain adjustment )

(16) Text display : One line of up to 24 alphanumeric characters

Selectable display position

(17) Digital zoom : Up to 4×, selectable enlarge position

Resolution loss with magnification (approx. 50 % at

2×zoom)

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

(18) Picture adjust menus : Modes and settings can be selected and adjusted

fromon-screenmenus

(1) Text display On/off, text edit, display position

(2) Backlight compensation Selectable on/off

(3) Level detect area Selectable

(4) Video level Adjustable

(5) AGC Selectable on/off, max. gain

(6) Shutter speed Selectable

(7) White balance Selectable mode

(8) Digital zoom Adjustable Wide(standard) to Tele(max.4×)

(9) Gamma correction Selectable on/off

(10)Chromalevel Adjustable

(11) Black level Adjustable

(12)Enhancer Adjustable

(13) Video signal polarity Selectable negative/positive

(19) Lens mount : C/CS mount (C mount adaptor option)

(20) Powersupply :12VDC ±10%

(21) Ambient temperature :-10 to +50 ℃, 30 to 80 % RH

(22) Storage ambient : -20 to +60 ℃, 20 to 90 % RH

(23) Vibration endurance :Less than 29.42 m/s2, 10 to 55 Hz

30minuteseachonXYZaxes

(Donotsubjecttostrongvibrationforlongperiodsoftime.)

(24) Power consumption : Approx. 220mA

(25) External dimensions :44 (W)×44 (H)×49(D) mm

(Notincludinglensandprotrusions)

(26) Mass : Approx. 130g

(27) Supplied equipment : Camera

Operatinginstructions

(28) Optional accessories : Lens (See operating instructions)

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

AC adaptor (AP-130)

DCinputplug(R03-P3F)

Lens plug (E4-191J-100)

Tripodadaptor(TA-D20AB)

Cmountadaptor(LA-D20AB)

RemoteY/Cplug(HR10A-10P-12S(01))

(29) YC Output / Remote control Pin and signal assignments

Pin Signal

1 GND

2 +12V

3 GND(Y)

4 Y output

5 GND(TX)

6 TX output

7 RX input

8 GND(C)

9 C output

10 GND

11 +12V

12 GND(RX)

Tokyo Japan

DWN

DSGN

CHKD

APPD

・・

Ｆ

8716616

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

Notice:

These specifications are subject to change without prior notice due to product

improvement.

Confirm the most recent specifications at time of order.

Hitachi Kokusai Electric certifies this product complies with the standard

warranty conditions of Hitachi Kokusai Electric , and that quality control is

implemented to theextent required to comply with these conditions.

Warranty and service:

(1) The guarantee period is one year after the data purchase. However,

the defects due to erroneous use or intentional act are excluded.

(2) As the defect after expiration of the guarantee period, where product repair

is possible, repair will be performed at charge.

(3) The present Warranty pertains only to the camera unit. Secondary

malfunctions attributable to camera failure as well as expenses

incurred by disassembly and reassembly of the related system, are beyond

the scope of this Warranty.

(4) Compensation for loss of business, loss or damage to software, database and

other contingent losses are beyond the scope of this Warranty.

(5) Hitachi Kokusai Electric Inc. is not liable for the losses caused when the

equipment is used in a system, use for business trades, production process,

medical fields, crime prevention applications, etc.

(6) The parts used in the equipment have their respective lives. The lives of

such parts will be shortened under the environments of high

temperature or high humidity.

When the stable operation is required for a long time, It is recommended to

perform periodical maintenance and inspection every year or every two

years.

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

・・

Tokyo Japan

DWN

DSGN

CHKD

APPD

Ａ

Ｂ

Ｃ

Ｄ

Ｅ

Ｆ

8716616

DATE CORRECTION AND REASONS BY CHKD APPD
