INSTRUCTION MANUAL
FOR
MODEL L-2100 PUMP
Copyright Hitachi High-Technologies Corporation 2002. All rights reserved. Printed in Japan. Part No. 890-9101
-1-
PREFACE
Thank you very much for purchasing Hitachi Model L-2100/2130
pump, which has been specifically designed for automatic
analysis in a liquid chromatograph system.
The Model L-2100/2130 pump is intended for use by persons
having a basic knowledge of chemical analysis.
Remember that improper use of analytical instruments,
chemicals or samples would result not only in wrong analytical
data but also in consequences adverse to safety.
Carefully read this instruction manual before attempting
operation. For proper use of the pump, please acquaint yourself
with it.
ABOUT THIS MANUAL
The operating procedures and maintenance/checkup instructions
for the L-2100/2130 pump are described in this manual.
First of all, read "IMPORTANT" and "SAFETY SUMMARY" at the
beginning of this manual for ensuring safety in operation of the
pump.
If installation of the pump is not yet completed, refer to Section 2.
Before attempting operation, read through Sections 3 and 4 to
become acquainted with the structure of the instrument and its
basic operations.
-2-
-3-
IMPORTANT
Precautions on Electromagnetic Wave Interference
1. Possible Electromagnetic Wave Interference Caused by This Instrument
Where this instrument is used in a residential area or an
adjacent area thereto, it may cause interference to radio and
television reception.
To prevent this, use the specified system connection cables in
strict accordance with the instruction manual. The instrument is
designed to minimize possible electromagnetic wave
interference caused by it if the specified cables are connected
properly.
However, there is no guarantee that electromagnetic wave
interference will not be caused by the instrument.
If the instrument does cause interference to radio or television
reception, which can be determined by turning the instrument off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•Reorient the antenna of the radio/television receiver.
•Increase separation between the instrument and the radio/TV
receiver.
•Connect the instrument to an outlet on a circuit different from
that to which the radio/TV receiver is connected.
2. Possible Electromagnetic Wave Interference Affecting This Instrument
Where this instrument is used near an intense electromagnetic
source, interference noise may be given to the instrument to
incur an adverse effect on its performance or functionality.
To present this, use the specified system connection cables in
strict accordance with the instruction manual. The instrument is
designed to minimize possible electromagnetic wave
interference affecting it if the specified cables are connected
properly.
However, there is no guarantee that electromagnetic wave
interference will not occur in the instrument. If the instrument
does incur electromagnetic wave interference, which can be
determined by turning on and off possible sources of
electromagnetic interference nearby, the user is encouraged to
try to correct the interference by one or more of the following
measures:
-4-
•Reorient the instrument.
•Increase separation between the instrument and possible
sources of electromagnetic interference.
•Connect the instrument to an outlet on a circuit different from
that to which possible sources of electromagnetic interference
are connected.
•Check that any other device connected with the instrument is
not affected by electromagnetic interference.
Warranty on Product
The Model L-2100 pump is warranted to be free from defects in
material or workmanship under normal use within the product
specifications indicated in this manual and under conditions
given below. This warranty is void if the instrument is not used
according to the instruction manual.
(1) Scope of Warranty
Any parts which prove to be defective in design or
workmanship during the warranty period will be repaired,
adjusted or replaced without charge. A substitute part may
be used for repair, or replacement with an equivalent
product may be made instead of repair. Such system
components as a personal computer and printer to be
updated frequently for improvement may not be available in
original versions at the time of replacement. Note that this
warranty does not apply to the instrument if modified by the
user or resold without permission from the manufacturer,
consumable parts, and any failure of lifetime-expired parts.
(2) Warranty Period
One year from the date of initial installation
(3) Availability of Technical Support Service
Technical support service for this instrument is available
within regular working hours on workdays specified by
Hitachi High-Technologies Corporation.
-5-
(4) Limitations and Exclusions on Warranty
Note that the following cases are excluded from the scope
of this warranty.
(a) Failure due to operation at a place not meeting the
installation requirements specified by Hitachi High-
Technologies Corporation.
(b) Failure due to power supply voltage/frequency other
than specified by Hitachi High-Technologies
Corporation or due to abnormality in power supply.
(c) Corrosion or deterioration of the tubing due to
impurities contained in reagent, gas, air or cooling
water supplied by the user.
(d) Corrosion of the electric circuits or deterioration of the
optical elements due to highly corrosive atmospheric
gas.
(e) Failure due to use of hardware, software or spare parts
other than specified by Hitachi High-Technologies
Corporation.
(f) Failure due to improper handling or maintenance by
the user.
(g) Failure due to maintenance or repair by a service
agent not approved or authorized by Hitachi High-
Technologies Corporation.
(h) After disposal of this instrument, or after its resale
without Hitachi High-Technologies Corporation
approval.
(i) Failure due to relocation or transport after initial
installation.
(j) Failure due to disassembly, modification or relocation
not approved by Hitachi High-Technologies
Corporation.
(k) Consumables, and failure of parts that have reached
the end of specified useful life.
(l) Failure of parts excluded from the warranty in the
instruction manual or other documents.
(m) Failure due to acts of God, including fire, earthquake,
storm, flood, lightning, social disturbance, riot, crime,
insurrection, war (declared or undeclared), radioactive
pollution, contamination with harmful substance, etc.
(n) Failure of the hardware, or damage to the system
software, application software, data or hard disk due to
computer virus infection.
-6-
(o) Failure of the personal computer connected with the
instrument, or damage to the system software,
application software, data or hard disk due to power
interruption or momentary power voltage drop caused
by lightning.
(p) Failure of the personal computer connected with the
instrument, or damage to the system software,
application software, data or hard disk due to
disconnection of main power to the personal computer
without taking the specified normal shutdown
procedure.
(5) Disclaimer of Warranty
THE MANUFACTURER MAKES NO WARRANTIES,
EITHER EXPRESS OR IMPLIED, EXCEPT AS PROVIDED
HEREIN, INCLUDING WITHOUT LIMITATION THEREOF,
WARRANTIES AS TO MARKETABILITY,
MERCHANTABILITY, FOR A PARTICULAR PURPOSE
OR USE, OR AGAINST INFRINGEMENT OF ANY
PATENT. IN NO EVENT SHALL THE MANUFACTURER
BE LIABLE FOR ANY DIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE, OR
LOSSES OR EXPENSES RESULTING FROM ANY
DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
NO ORAL OR WRITTEN INFORMATION OR ADVICE
GIVEN BY THE MANUFACTURER, ITS DEALERS,
DISTRIBUTORS, AGENTS OR EMPLOYEES SHALL
CREATE A WARRANTY OR IN ANY WAY INCREASE
THE SCOPE OF THIS WARRANTY.
(6) Warranty Card
The warranty card will not be reissued. Keep it in a safe
place.
Installation, Relocation and After-sale Technical Service
Installation of the instrument shall be carried out by or under
supervision of qualified service personnel of the manufacturer or
its authorized service agent.
Before installation of the instrument, the customer is requested
to prepare necessary utilities referring to this manual.
When relocation of the instrument becomes necessary after
initial installation (delivery), please notify your local Hitachi High-
Technologies sales representative or service office.
-7-
Technical Seminars and Training for Customers
For the customers to acquire in-depth understanding of the
analytical instruments, technical seminars and customer training
courses are available at Hitachi High-Technologies Corporation
or your site. For further information, contact your local Hitachi
High-Technologies Corporation sales representative.
(The technical seminars and customer training courses are
available on a chargeable basis.)
Other Precautions
1. Handling of Chemicals and Samples
(1) The user is responsible for following relevant legal
standards and regulations in the handling, storage and
discarding of chemicals and samples used in analytical
operations of the instrument.
(2) Reagents, standard solutions and accuracy-control
samples shall be handled, stored and discarded as
instructed by the respective suppliers.
2. Notice on This Instruction Manual
(1) The information contained in this manual is subject to
change without notice for product improvement.
(2) This manual is copyrighted by Hitachi High-Technologies
Corporation with all rights reserved.
(3) No part of this manual may be reproduced or transmitted in
any form or by any means without the express written
permission of Hitachi High-Technologies Corporation.
1 -
1
1. OUTLINE
The liquid chromatograph system consists of a pump for feeding
an eluent, a sample introducing section (autosampler, manual
injector) for injecting a sample, a column for chromatographic
separation of the injected sample, a column oven for maintaining
the column at a constant temperature, and a detector section for
detecting a signal of a separated component of the sample.
In addition, a degasser for deaerating an eluent, a gradient
device for varying a mixing ratio of eluents with time, and other
optional devices are incorporated in the system.
1.1 Isocratic System
The isocratic system has a simple configuration in which single-
solvent analysis is performed.
1.1
Model L-2100/2130 pump
Model L-2300 column oven
Model L-2200 autosampler
Model L-2400 UV detector
System power supply unit
Eluent
Drain
Washing solution
Degasser
Column
1 -
2
(1) An eluent is fed by the pump through the degasser.
(2) Asample is injected from the autosampler.
(3) The injected sample is separated through the column which
is maintained at a constant temperature by the column
oven.
(4) Each component separated from the sample is then
detected as a signal by the detector.
1.1 Isocratic System
Indice
Altri manuali Hitachi Pompa dell'acqua
Manuali Pompa dell'acqua popolari di altre marche
Sykes AmeriPumps
Sykes AmeriPumps GP100M Guida alla risoluzione dei problemi
DUROMAX
DUROMAX XP WX Series Manuale utente
BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 Manuale utente
Franklin Electric
Franklin Electric IPS Manuale utente
Xylem
Xylem e-1532 Series Manuale utente
Milton Roy
Milton Roy PRIMEROYAL Manuale utente
