HL Display 3eBin Manuale utente
8. 9.
10.
1
COMPONENT OVERVEIW:
1.
3eBin™- Scoop bin assembly instructions
2. 3.
6.
4. 5.
7.
11. 12.
Components:
1. Catch tray 7. Label holder
2. Body 8. Catch tray holder
3. Scoop 9. Front
4. Scoop holder 10. Top lid
5. Consumer lid 11. Internal signage holder
6. Cord 12. Divider
6. Bend the right part of the bin body slightly outwards and
plug in consumer lid. Do this for both sides.
5. Insert consumer lid label holder into its dedicated
space. Listen for click signaling the holder has been
installed properly.
3eBin™- Scoop bin assembly instructions
PLEASE FOLLOW THE BELOW INSTRUCTIONS FOR ASSEMBLY
OF YOUR SCOOP BIN:
1. Insert scoop holder into dedicated slits on the inside
of bin front.
3. Attach bottom part of internal signage holder by
inserting it behind the two dedicated stoppers on the
inside of bin front.
2. Snap bin front into slits on both sides of bin body.
4. Press the top part of internal signage holder toward
front until it locks.
2
11. (If your bin doesn’t have a catch tray, please skip this
step.) Insert catch tray completely. Ensure catch tray sits
between the catch tray holder and the bin body.
12. Insert scoop into scoop holder. Your scoop bin is
now fully assembled.
7. Attach top lid to bin.
9. (If your bin doesn’t have a divider, please skip this
step.) Install divider by plugging it into its dedicated hole
and slit in the back of bin body and in the slit in the front
part of the bin body.
3eBin™- Scoop bin assembly instructions
8. Insert cord into its dedicated hole in scoop. Insert cord
into its dedicated hole on the side of the bin body.
10. (If your bin doesn’t have a catch tray, please skip this
step.) Insert catch tray holder from the back. Ensure it
locks into its dedicated holes.
3
