Hobie Wave Manuale utente

• 1

ASSEMBLY MANUAL

HOBIE CAT EUROPE

ZI Toulon Est, BP 250

83078 Toulon cedex 9, France

Tel : +33 (0)494 08 78 78 - Fax : +33 (0)494 08 13 99

Email : [email protected] - http://www.hobie-cat.com

• 2

ASSEMBLY MANUAL

TABLE OF CONTENT

Hull assembly............................................3

Trampoline fitting......................................4

Rudder system assembly .........................5

Mast and rigging.....................................6-7

Mainsail .....................................................8

Mainsheet...................................................9

Turbo Kit ..................................................10

Righting line.............................................11

Safety tips................................................12

LIST OF PARTS

⇒ Hulls (2)

⇒ Front crossbar

⇒ Rear crossbar

⇒ Mast

⇒ Trampoline

⇒ Rear trampoline strip

⇒ Rudder assemblies (2)

⇒ Tiller crossbar

⇒ Tiller extension

⇒ Mainsail

⇒ Jib kit

⇒ Batten set (6)

⇒ Parts bag

⇒ Ropes bag

⇒ Wire bag

It is advisable to assemble the Hobie Wave with

Two people.

CAUTION - DANGER

ALUMINIUM MAST

STAY CLEAR OF OVERHEAD WIRES

• 3

Lift the front crossbar and insert the left end into the left

hull. Lift the rear crossbar and insert the left end into the

left hull. NB : The crossbars have stops built into the un-

derside that will limit the depth the crossbars can be in-

serted.

Identify the right and the left trampoline halves and slide

the front of this in the track of the front crossbar.

Insert the rear trampoline stripe in the rear crossbar. In-

sert the right side of the front crossbar in the right hull

and the right side of the rear crossbar in the right hull.

Feed the outside edges of the trampoline halves through

the trampoline tracks attached to the inside edge of the

deck.

Lay the hulls on the ground on their sides with the bot-

toms to the center (graphics down) as in figure 1. A tarp

or pads may be desirable under the hull if the ground

surface is rough.

There is one plug in the rear of each hull (shown inset).

These plugs are used to drain the hulls. The plugs

should be in place before sailing. Remove the plugs af-

ter sailing to drain any water that may have leaked into

the hulls. It is best to travel and store the boat with the

plugs removed to allow for pressure changes due to

heating, cooling and altitude changes. This will prevent

warping of the hull surface.

Hull assembly

HULLS

• 4

NB : A tight trampoline gives the boat its rigidity.

TRAMPOLINE

Trampoline fittings

Proceed to lace the trampoline halves along the rear

first. Do not tighten.

Tighten the trampoline lacings and attach them as in-

dicated on the picture.

Thread and tighten the center trampoline lacing from

front to rear.

• 5

Locate the tiller crossbar and

identify the left and right hand

ends. NB: the tiller crossbar (1)

locates on top of the tiller/rudder

arms (2).

Locate the tiller connector kits

and install as shown on the pho-

tographs.

Identify the right and the left rudders. Green sticker for the right, red sti-

cker for the left. Attach these to the boat using the two aluminium rud-

der pins and split rings provided.

RUDDER

Rudder system assembly

Tiller crossbar and extension

Locate the tiller extension and secure it to the tiller

crossbar using the clevis pin and ring clip provided.

• 6

Remove the main and jib halyard lines from the ropes

bags. Unroll the main halyard wire that is secured at the

head of the mast. Using a bowline knot, secure the main

halyard line to the thimble at the end of the halyard wire.

Now, secure both ends at the base of the mast.

Mast and rigging

MAST

Remove all the wires from the wires bag and unroll them. Ensure that all

twists are removed.

Locate the 8 mm tang shackle and shackle the five wires to the mast

tang, as per photograph. Ensure that the shackle is tightened securely.

1. Shrouds

2. Pigtail, forestay, jib halyard/

(for Turbo model only)

With the base of the mast facing towards the front of the boat, lay

the mast on top of the boat. (place some pading under the mast

to prevent scratching).

Find the package containing the stay adjusters, twist toggles, cle-

vis pins and split rings. Assemble by pinning the twist toggle into

the bottom of the stay adjuster.

• 7

With the person on the trampoline supporting the mast, the

other person shackle the two bridles to the stay adjuster at

the end of the forestay. Now, provided all the clevis pins

have the split rings fitted, the mast is supported by the

shrouds and forestay. For the Turbo model see page (jib

assembly)

Now, ensure that the forestay wire is not twisted around any other wires and you are ready for raising the

mast.

For safety, two people should raise the mast. One person positions the hook on the mast base under the pin in

the mast step, whilst the other person supports the head of the

mast. One person stands on the trampoline supporting the mast

whilst the person supporting the top of the mast starts walking to-

wards the boat and lifting at the same time.

When the person on the trampoline can support the weight of the

mast, the second person walks around the front of the mast and

pushes down on the mast base. This provides added security and

prevents the base from popping out of the step whilst the person on

the trampoline fully raises the mast.

Raising the mast

MAST

Next, fasten the shrouds into the stay adjusters. To begin with, fasten the

shroud about half way up the adjuster. This position can be adjusted later. The

position influences mast rake. Now fasten the twist toggles to the anchor bar

pins on each side of the boat. You can pull the cover partially over the stay ad-

justers at this time. The assembly of the trapeze wires can wait until after you

have raised the mast.

• 8

Unfold the mainsail and lay on a flat clean surface. Undo the set of battens and identify

which batten goes in which batten pocket. Insert the battens into the pockets. Using the

batten ties secure each batten into it’s respective pocket (as per drawing). Push the bat-

tens in reasonably hard - sufficient to remove any wrinkles from the pocket.

NOTE : it is important to relieve the tension on the battens after each day’s sailing. This

will prolong the life of the sail.

Place the sail on the trampoline, the battens clips towards

the back. Undo the main halyard wire from the mast and

shackle it to the head board of the mainsail. Now, feed the

bolt rope at the head of the sail into the cut out in the sail

track on the mast.

Now, pull on the main halyard line whilst feeding the sail into

the track cut out.

MAINSAIL

BEFORE RAISING THE MAINSAIL, MAKE SURE THAT THE BOAT IS POINTING INTO THE WIND. IF THE

WIND CHANGES DIRECTION, MOVE THE BOAT.

When the sail is all the way up, position

the stopper on the wire halyard so that it

engages in the halyard lock. Attach the

main halyard rope to one of the white

cleat at the bottom of the mast.

Then take the downhall rope and attach it

to the sail tack grommet near the mast.

Pass the line down and through the cen-

ter of the downhaul cleat on the mast.

Run the line up

to the grommet and tie off.

• 9

These pictures show how the mainsheet system is

assembled and shackled to the traveller car and the

clew of the mainsail.

MAINSHEET

• 10

Before installing the jib on

the Hobie Wave, you must

first install the parallel bow

spreader (provided with the

turbo kit). Install bow spreader

tangs on each bow under exis-

ting bridle wire tang as shown.

Pin faces towards center. With

trampoline loosened, place bow

spreader in position on pins ins-

talled on bows.

Before stepping the mast, Install jib halyard block on pig tail and place pigtail on the shroud shackle next to fo-

restay wire. Run the halyard through the halyard block and tie off ends at lower cleat. Install halyard shackle.

Step the mast.

Clip the jib tack to the spreader pole eye strap at center of the pole. Shackle the halyard to the jib head and

hoist. Tension lightly and cleat to lower cleat on the mast.

Tie one end of the jib sheet to the jib clew. Run the sheet to (inside the shroud wire) the swivel jam through the

dead eye first and then out jaws towards center of the boat. Pass the line behind the mast to the other swivel

cleat. Run the line through jaws first then dead eye. Run line forward (inside shroud) to the jib clew and tie off.

TURBO KIT

Install jib sheet swivel jam cleat as follows : unscrew the two screws of the

trampoline track, install the swivel jam cleat plate between the hull and the

track, screw again the two screws with washer to maintain the plate. Same

operation on the opposite hull.
