HOLDEN WN Series Guida utente

WN CAPRICE HOLDEN.COM.AU

WN CAPRICE

OWNER’S HANDBOOK

GM Holden Ltd, ABN 84 006 893 232 (hereinafter Holden)

Change of name, address or ownership

If you drive a pre-owned Holden, have moved house or changed any of your details, we’d like to

hear from you!

Holden uses your details to keep your vehicle’s factory provided RoadsideAssistance and Warranty

details up to date.

It also helps us let you know if there is an existing safety recall or rework on your vehicle. To update

your details, please take a few minutes to ll in and mail the form at the back of the Service/Warranty

booklet or visit Holden’s website at: www.holden.com.au/forms/change-of-owner-details

GM Holden Ltd (Holden) is collecting the new owner’s personal information in order to process

the request for transfer for the specied vehicle. We may disclose your personal information to our

related companies and third parties who provide us with (or help us provide) products and services,

including to overseas locations such as the USA, and other countries in Europe, Oceania and Asia.

Holden’s privacy policy (available at: www.holden.com.au/privacypolicy) states how you can seek

to access or correct any personal information Holden holds about you, how to complain about a

privacy breach by Holden and how Holden will deal with a privacy complaint.

You can contact Holden on 1800 033 349 or alternatively, you may prefer to email Holden at:

[email protected]

Note: Please refer to the inside front cover of the Service/Warranty booklet for the Vehicle

Identication Certicate.

Part No. 92277337 Reproduction in whole or part is

July 2015 prohibited without written approval from

(MY16 WN Caprice. Print 1) GM Holden Ltd, ABN 84 006 893 232

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

Contents Introduction . . . . . . . . . . . . . . . . . . . . . . 2

In Brief . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Keys, Doors, and Windows . . . . . 16

Seats and Restraints . . . . . . . . . . . 36

Storage . . . . . . . . . . . . . . . . . . . . . . . . . 57

Instruments and Controls . . . . . . . 62

Lighting . . . . . . . . . . . . . . . . . . . . . . . . . 93

Infotainment System . . . . . . . . . . . . 99

Climate Controls . . . . . . . . . . . . . . 178

Driving and Operating . . . . . . . . . 185

Vehicle Care . . . . . . . . . . . . . . . . . . 225

Service and Maintenance . . . . . 278

Technical Data . . . . . . . . . . . . . . . . 280

Customer Information . . . . . . . . . 288

Index .................... 290

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

2 Introduction

Introduction

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

Introduction 3

Introduction

This Owner's Handbook provides

you with all the necessary

information to enable you to drive

your vehicle safely and efficiently.

Make sure your passengers are

aware of the possible risk of

accident and injury which may result

from improper use of the vehicle.

Using this Manual

.This manual describes all

options and features available

for this model. Certain

descriptions, including those

for display and menu

functions, may not apply to

your vehicle due to model

variant.

.The In brief section will give you

an initial overview.

.The table of contents at the

beginning of this manual and

within each chapter shows

where the information is located.

.The index will enable you to

search for specific information.

.Directional data, e.g. left or right,

or front or back, always relate to

the direction of travel.

.The Bluetooth

word mark and

logo are registered trademarks

and are owned by the Bluetooth

SIG, Inc.

.iPod

is a registered trademark

of Apple Inc.

.ESP

is a registered trademark

of Daimler AG.

Danger, Warning, and

Caution

{Danger

Text marked {Danger provides

information on risk of fatal injury.

Disregarding this information may

endanger life.

{Warning

Text marked {Warning

provides information on risk of

accident or injury. Disregarding

this information may lead to injury.

Caution

Text marked Caution provides

information on possible damage

to the vehicle. Disregarding this

information may lead to vehicle

damage.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

4 Introduction

2NOTES

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

In Brief 5

In Brief

Initial Drive Information

Remote Keyless Entry (RKE)

System . . . . . . . . . . . . . . . . . . . . . . . . 5

Door Locks . . . . . . . . . . . . . . . . . . . . . 5

Seat Adjustment . . . . . . . . . . . . . . . . 6

Head Restraint Adjustment . . . . . . 6

Seat Belts ....................... 7

Mirror Adjustment . . . . . . . . . . . . . . . 8

Steering Wheel Adjustment . . . . . 8

Instrument Panel Overview . . . . 10

Interior Lighting . . . . . . . . . . . . . . . . 11

Exterior Lighting . . . . . . . . . . . . . . . 12

Horn ........................... 13

Washer and Wiper Systems . . . 13

Climate Controls . . . . . . . . . . . . . . . 14

Transmission . . . . . . . . . . . . . . . . . . 14

Parking . . . . . . . . . . . . . . . . . . . . . . . . 14

Getting Started . . . . . . . . . . . . . . . . 14

Initial Drive

Information

Remote Keyless Entry

(RKE) System

Q: Lock and arm the alarm

K: Unlock and disarm the alarm

Y: Boot unlock

See Keys 016.

See Door Locks 023.

Door Locks

To lock, insert the key into the

driver's door lock and turn towards

the rear of the vehicle, then turn it

back to the vertical position and

remove.

This will lock all doors.

To unlock, turn the key towards the

front of the vehicle to unlock the

driver's door.

See Keys 016.

See Door Locks 023.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

6 In Brief

Seat Adjustment

The vehicle has the following levers

and switches for seat adjustment.

1. Lumbar

2. Recline

3. Forwards/backwards, up/down,

cushion tilt

See Seat Position 038.

Head Restraint

Adjustment

{Warning

The head restraint is a safety

feature.

The centre of the head restraint

should be at eye level, never at

neck level.

.Lift the head restraint up to

raise it.

.Push the locking button and

push the head restraint down to

lower it.

.Front head restraints cannot be

removed.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

In Brief 7

.To adjust horizontally, pull the

front head restraint forwards and

engage in one of three positions.

.To return to its rearmost position,

pull fully forwards and release.

The vehicle has adjustable rear

head restraints, these can be

removed.

See Head Restraints 036.

See Child Restraint Systems 052.

Seat Belts

Pull the metal tongue across your

body into the buckle, until it clicks

into place.

The belt should not be twisted.

It should lie flat and fit firmly across

your hips.

To remove, press the release button

on the buckle to allow the belt to

retract.

See Three-Point Seat Belt 044.

Holden WN Owner Manual (Holden-Localizing-Holden-9416110) - 2016 - crc -

7/16/15

8 In Brief

Mirror Adjustment

Automatic dimming rear view

mirror

The vehicle has an automatic

dimming rear view mirror.

The mirror will automatically switch

in and out of night view.

See Automatic Dimming Rear View

Mirror 030.

Exterior mirrors

Power mirrors

L: Left side mirror selected

R: Right side mirror selected

): No mirrors selected

To adjust an exterior rear view

mirror:

1. Press the switch (2) to Lor R.

2. Press the switch (1) to adjust

the mirror.

See Power Mirrors 029.

Steering Wheel

Adjustment

{Warning

Do not attempt to adjust the

steering wheel while driving.

1. Move the lever down to unlock.

2. Move the steering wheel up,

down, closer or away.

3. Move the lever up to lock.
