LARK MAX Quick Guide
V1.0.0
1
Thank you for purchasing Hollyland LARK MAX wireless microphone system. Please read
this quick guide carefully before using the product.
For more detailed information, please scan the code to view the product user manual.
Introduction
2
Product Operations
The preferred position for attaching the transmitter is the collar near the speaker’s neck area.
If the speaker’s voice is louder, position the transmitter in the upper chest area. The transmitter
can be attached via its back clip or the clip magnet.
Note:
Placement of the transmitter in dierent positions will result in recorded sound volume uctua-
tions. Avoid any obstructions of the transmitter during recording. It is recommended to use the
fur windshield to prevent audio inteerence when using the transmitter outdoors.
3
Connecting the Receiver to an iPhone
1. Connect the receiver to an iPhone using
a USB-C to Lightning cable.
2. A USB connection icon will be displayed
on the receiver touchscreen.
3. Open the recorder or camera app on the
mobile phone to sta recording.
Connecting the Receiver to an Android
Phone with a USB-C Inteace
1. Connect the receiver to an Android
phone with a USB-C inteace using a
USB-C to USB-C cable.
2. A USB connection icon will be displayed
on the receiver touchscreen.
3. Open the recorder or camera app on the
mobile phone to sta recording.
Product Operations
Note: It is recommended to use the original USB-C to Lightning and USB-C to USB-C
cables. Otherwise, compatibility issues may occur, which could result in sound distoion
or others.
4
Product Operations
Connecting the Receiver to a Camera
1. Attach the receiver to a camera via the hot shoe or cold shoe using the back clip.
2. Connect the 3.5mm audio output inteace on the receiver to the 3.5mm audio input inter-
face on the camera using a 3.5mm TRS to 3.5mm TRS cable.
3. Set the recording volume of the camera to the lowest and the output volume of the receiv-
er to the medium to ensure the best recording level.
5
Figure 2Figure 1
Product Operations
Pairing
The transmitter and the receiver are paired by default. Follow either of the following two ways
to pair the transmitter and the receiver if they are disconnected.
1. Auto pairing: Place the transmitter and the receiver in the charging case, and they will pair
automatically. (Figure 1)
2. Manual pairing: Turn on the transmitter and the receiver, and press and hold the pairing
button on the transmitter to enter the pairing mode. In this case, the transmitter status
indicator light ashes quickly. Then, select System Settings on the receiver touchscreen and
tap Pairing to sta pairing. If the transmitter status indicator light turns steady blue, pairing
is successful. (Figure 2)
6
Product Functions
Noise Cancellation
Press the noise cancellation button on the
transmitter to enable the noise cancellation
function. In this case, the transmitter status
indicator light turns green.
Recording
Press the REC button on the transmitter to
enable the recording function. In this case,
the transmitter REC indicator light turns
steady red.
7
Charging and Storage
If the transmitter status indicator light ashes red, please charge the transmitter by placing it in
the charging case or via the USB-C inteace.
Product Functions
8
It is always recommended to place the transmitter and the receiver in the charging case for
charging and storage after each use.
Batte Level Indicator Light Description of the Charging Case
Pattern Batte Level
One LED ON, flashing red Low battery. The transmitter and the receiver
cannot be charged using the charging case.
One LED ON 25%
Two LEDs ON 50%
Three LEDs ON 75%
Four LEDs ON 100%
Product Functions
9
