Holman SWC1000 Manuale utente
2 of 20
PRODUCT CODE: SWC1000
iOS is a trademark of Apple Inc. Android is a trademark of Google LLC. The
Android robot is reproduced or modified from work created and shared by
Google and used according to terms described in the Creative Commons 3.0
Attribution License. The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Holman
Industries is under license. Other trademarks and trade names are those of their
respective owners. All other content is Copyright©HolmanIndustries2022.
Scan here for the latest manual
or visit
https://www.holmanindustries.com.au/product/
150mm-ground-light-twin-pack
4 of 20
Overview
Package Content
1. 2 × 2W RGBW Bluetooth®Mesh Ground [a] IP65
2. 2 × Ground Spikes [b]
3. 1 × Plug in Power Supply [c], for outdoor power point (GPO)
4. 1 × Inline DC Adaptor [d] IP67, 90cm from plug to inline
DC adaptor, 40cm from inline DC adaptor
to the first light connector
5. 1 × End Cap included
6. 2 × Zip Style Cable Ties (to secure cable to light spike neatly)
included
b
d
c
a
ÁNo modification or addition
to the light configuration is possible
5 of 20
Setup
Preparation
1. Ensure that the power point
is no more than 3.4m away,
there is no extension or
modification for the cable
(90cm from plug to
inline adaptor, 2.5m to
first light – 2.5m cable
between each light)
2. Put the click lock ground
spikes onto the lights. To do
this align the spike to the
base and then twisted to
lock [a]. No tools are needed
– please only use your hands
3. Place the ‘end’ cap onto
the ‘tail’ of the second
light [b]– this creates a
waterproof seal for the light
4. Plug the ground lights
into the inline adaptor and
their joining cable, before
connecting ensure the red
O-Ring is in place [c] (for
electrical protection) and that
the plug is correctly oriented
a
b
c
6 of 20
Setup (continued)
Preparation (continued)
5. Once the plugs are
connected screw down
the threaded cover onto
the plug connection
6. Plug in the power cord to
the power point (GPO) and
observe the lights, they should
be flashing white (pairing
mode). If the lights are not
flashing white, turn the power
point on/off/on/off/on to get
the lights into pairing mode
7 of 20
Setup (continued)
Installing Holman Home
1. Download Holman Home to
your mobile device via the
App Store or
Google Play
2. Open Holman Home
on your mobile device
®You may be prompted to allow
notifications–the app can
still function if you choose to
opt out
3. Tap SIGN UP
4. Read our User Agreement
and Privacy Policy and tap
AGREE if you wish to proceed
5. Follow the prompts to register
a Holman Home account
with your email address
ÁEnsure your country
details are correct at this
stage
®You must allow the
‘Discovering Nearby
Device’ permission (or
Bluetooth®permission,
depending on your phone
operating system) – this
allows Bluetooth®mesh
products to be added into
Holman Home
®You may be prompted to
allow access to your location.
This allows the app to show
weather information-it will
still function if you choose to
opt out
8 of 20
Setup (continued)
Bluetooth®Connetion
LEnsure you and your
smartphone are close to your
light kit during the connection
process - you may need to
prompt pairing mode
LYour lighting kit will
perform preset schedules
from the app, even if
your smartphone is out of
Bluetooth®connection range
(schedules must be sent
within Bluetooth®range)
9 of 20
Setup (continued)
Pairing
1. Pairing of the ground
lights is via Bluetooth®
Mesh, please ensure
you have allowed the
Bluetooth®(iOS)or
Nearby Devices (Android)
permission
2. These lights will flash
white/fast to indicate
they are ready to pair
(default/pairing mode)
3. Tap ‘Add Device’ from
the Holman Home Home
screen, you will see the
ground lights appear under
‘Discovering devices’
4. Press ‘Add’ to
commence pairing
5. When you see the blue
circle [a] appear on the
‘Add Device’ screen please
tap this (or ‘Add All’ [b])
to commence pairing
6. After 30 seconds to 1
minute the light will be
successfully added
a
b
10 of 20
Pairing (continued)
Setup (continued)
7. Tap ‘Done’ [c] to
completepairing. You will now
see the lights on the home
page. If you are still within
Bluetooth®range you will
see a power on/off icon [c]
8. If you’re out of range, the
Bluetooth®[d] symbol
will appear greyed out
c
d
