Holux GR-89 Manuale utente

No.1-1, Innovation Rd.1, HsinChu City 300, Science-based Industrial Park, aiwan

(300) 新竹市科學園區創新一路 1-1 號

EL: 03-6687000 FAX: 03-6687111

Website: www.holux.com

GR-89

SPECIFICA ION

GPS Engine Board

GR-89

GPS Module series

HE PRO NAME IN GPS

HOLUX echnology, Inc.

No.1-1, Innovation Rd.1, Hsinchu Science Park, Hsinchu, aiwan(R.O.C)

EL: 886-3-6687000 FAX:886-3-6687111 E-mail:[email protected].tw http:www.holux.com.tw

Introduction

Key Features



SiRF GSC3f/LPx chipset with embedded ARM7 DMI CPU available for

customized applications in firmware.



20-Channel GPS Receiver for fast acquisition and reacquisition.



Very compact size, only 25.4 * 25.4 * 3 mm.



200,000 effective correlators for fast ime o First Fix ( FF), even at

poor satellite signal.



Built-in WAAS/EGNOS Demodulator.



Low power consumption with Advanced rickle-Power and Push- o-Fix

mode.



Support NMEA-0183 v2.2 data protocol and SiRF binary code.



Real time navigation for location based services.



For Car Navigation, Marine Navigation, Fleet Management, AVL and

Location-Based Services, Auto Pilot, Personal Navigation or touring

devices, racking devices/systems and Mapping devices application.

Specifications



Acquisition at low signal levels:



Cold/Warm/Hot start: 42/38/1 sec. (average)



Position Accuracy :※



Autonomous: <10 meters at 2DRMS.



SBAS: <7 meters at 2DRMS, WAAS corrected.



DGPS: 1-5 meters at DGPS corrected.



Receiver:



racking : L1/CA code



Channel : 20



Max. Update rate: 1 HZ



ime Mark: Output 1 pulse/sec, aligned with GPS time+/-0.1 usec



Max. Altitude/Velocity : < 60,000 ft / < 1,000 knots※.



Protocol Support : NMEA-0183, SiRF Binary, AI3/F



Datum: WGS-84 (default), selectable for other Datum.



Processing Core



200,000+ effective correlators for fast FF and high sensitivity

acquisition.

GR-89

GPS Module series

HE PRO NAME IN GPS

HOLUX echnology, Inc.

No.1-1, Innovation Rd.1, Hsinchu Science Park, Hsinchu, aiwan(R.O.C)

EL: 886-3-6687000 FAX:886-3-6687111 E-mail:[email protected].tw http:www.holux.com.tw



Processor ype: ARM7 DMI



Processor Speeds 49 MHZ



Integrated program Flash 4Mbit



Minimum tracking signal levels: -159 dBm※



Interface : CMOS 3V



Dimension: 25.4 x 25.4 x 3 mm



Weight: 3 g



Operating emperature : -20 to +70



Storage emperature: -40 to +85



Operating Humidity: 5% to 95%, No Condensing



Power : input voltage 3.3V ~ 5.5VDC



Operational current: less than 30mA (without antenna)



RF DC power supply for active antenna max 50mA

: According to SiRF GSC3f/LP※x specification.

GR-89

GPS Module series

HE PRO NAME IN GPS

HOLUX echnology, Inc.

No.1-1, Innovation Rd.1, Hsinchu Science Park, Hsinchu, aiwan(R.O.C)

EL: 886-3-6687000 FAX:886-3-6687111 E-mail:[email protected].tw http:www.holux.com.tw

Module snapshot and pin out definition.


Mechanical dimension

GR-89

GPS Module series

HE PRO NAME IN GPS

HOLUX echnology, Inc.

No.1-1, Innovation Rd.1, Hsinchu Science Park, Hsinchu, aiwan(R.O.C)

EL: 886-3-6687000 FAX:886-3-6687111 E-mail:[email protected].tw http:www.holux.com.tw

Recommend PCB layout

Pin assignment

Pin ame

Type

Function description

VCC_IN I 3.3 ~ 5 V supply input

GND G Ground

BOOT_SEL

Boot selection. Pull high this pin at power on stage for flash

programming.

RXDA I Serial Data input A

TXDA O Serial Data Output A

TXDB O Serial Data Output B

RXDB I Serial Data input B

GPIO14 I/O

General purpose I/O. flash at 1Hz when position is fixed.

RF_ON O Indication for RF power supply. Flashes in trickle power mode.

GND G Ground

RF_IN I GPS signal input

GND I Ground

GR-89

GPS Module series

HE PRO NAME IN GPS

HOLUX echnology, Inc.

No.1-1, Innovation Rd.1, Hsinchu Science Park, Hsinchu, aiwan(R.O.C)

EL: 886-3-6687000 FAX:886-3-6687111 E-mail:[email protected].tw http:www.holux.com.tw

V_ANT_IN

I Antenna power supply input

VCC_RF_O

O Antenna power supply, 2.85V

V_BAT I R C and backup SRAM power, 2.6 ~ 3.6 VDC.

nRESET

I Reset, active low

GPIO10 I/O

General purpose I/O

GPIO1 I/O

General purpose I/O

GPIO2 I/O

General purpose I/O

GPIO0 I/O

General purpose I/O

GPIO13 I/O

General purpose I/O

GPIO15 I/O

General purpose I/O

PPS O

1 PPS output, synchronized with GPS time. IME_MARK 1 PPS

output, 1us/s

GND G Ground

GR-89

GPS Module series

HE PRO NAME IN GPS

HOLUX echnology, Inc.

No.1-1, Innovation Rd.1, Hsinchu Science Park, Hsinchu, aiwan(R.O.C)

EL: 886-3-6687000 FAX:886-3-6687111 E-mail:[email protected].tw http:www.holux.com.tw

Recommendation reflow profile

1. We strongly recommend that this module should be designed to mount on

top side of motherboard with main chip together which process the final

reflow.

2. he maximum frequency of this module to pass reflow process should be

no more than twice, including repair operation, otherwise it may cause side

effect to the performance.

3. Below is the recommend reflow profile referred to Main SiRF chipSet.

Note: 1.Please reference Pb-Free assembly

2. tp reference table 4-2 blue mark
