Rating of power supply: AC 220-240V, 50/60Hz,
Tank capacity:350ml
Max capacity of water cup: 250ml
Rated power:900-1050W
Steam pressure:0.25MPa～0.32 Mpa
Injected steam capacity: 28g/min
Temperature controller: functioning temperature: 132℃;
fuser: functioning temperature:169℃
Overall dimension: 300×150×210mm
Operation Procedures
1.Unpack the product, check the accessories and documents supplied with the product
and make sure that the product and accessories are not damaged.
2.Before use, please read the User Manual carefully. The steam cleaner is only for use in
households.
3.First, place the steam cleaner on a level platform, push down the safety cover, unscrew
the safety cap counterclockwise, and then install the funnel. The safety cap can not be
opened if there is scope of the pressure in boiler to ensure safety for users.
4.Take 175ml clean water with the measuring cup, and add the water into the tank. (Max.
capacity of the tank is 250ml. Do not overfill the tank and some space must be left in the
tank). Re-install the safety cap and tighten it in position
5.Check the power supply and socket, and confirm they comply with the requirements
given in the User Manual. Then turn on the power supply.
6.About 4 minutes after power supply is turned on, steam is ready. At this time lightly press
the steam button and check whether steam is sprayed out of the nozzle. (Do not aim the
spray nozzle at other persons or objects).
7.If there is steam sprayed out, please install suitable accessories according to your needs
after you release the button.
8.Press down the steam button again in order to carry out the operations required by you.
Installation of Accessories
1.Install the spray cup with hairbrush
Hold the pipe section of the spray cup with hairbrush in your hand, align the arrow on the
spray cup with the single-line mark on short spray nozzle on the machine body, and insert
the spray cup in position. Rotate the spray cup in clockwise direction, and align the arrow
on the spray cup with the double-line mark on short spray nozzle on the machine body, as
shown in Figure 1. Fix the spray cup on the machine body. To remove the spray cup with
hairbrush, please rotate the spray cup inversely (counterclockwise) as shown in Figure 2,
and align the arrow on the spray cup with the single-line mark on the machine body. Then
the spray cup with hairbrush can be pulled out.
TECHNICAL SPECIFICATION
OPERATING INSTRUCTIONS
5
